- Page 1 CHC-1224-xx User Manual Revision 1.0 windynation Solar Panel Charge Controller CHC-1224-10 CHC-1224-30 User’s Manual Page 1 of 1 windynation 07/19/2013...
-
Page 2: Table Of Contents
CHC-1224-xx User Manual Revision 1.0 Table of Contents Introduction ..............................3 Features ............................3 System Diagram ..........................3 Safety Information ..........................4 Specifications ............................ 4 1.4.1 Electrical Specifications......................... 4 ... -
Page 3: Introduction
CHC-1224-xx User Manual Revision 1.0 1 INTRODUCTION The WindyNation Solar Panel Charge Controller provides a reliable charging and power management solution for solar power battery systems with many of the features that you would expect in a much higher priced controller. This is made possible by the board microprocessor and embedded intelligent software control. -
Page 4: Safety Information
Solar panels produce power when exposed to light. Use caution when handling copper wiring. Do not use with equipment that exceeds the rated power for this device. 1.4 S PECIFICATIONS 1.4.1 Electrical Specifications Parameter CHC-1224-10 CHC-1224-30 Rated Charge Current 10 Amps 30 Amps Rated Load Current 10 Amps... -
Page 5: Mounting
CHC-1224-xx User Manual Revision 1.0 avoid touching components on the circuit boards. The risk of electrostatic damage is highest when relative humidity is below 40%. 2.2 M OUNTING Mounting is optional; however, the environment must be dry and protected from water. 1. -
Page 6: Operation
CHC-1224-xx User Manual Revision 1.0 1) Connect the Battery Connect the battery wiring to the battery terminals on the charge controller. Note the polarity on the screw- down terminals. The charge controller self-protection feature will prevent damage from reverse polarity connections, but the charge controller will not function until the battery is connected properly. -
Page 7: Led Indicators
CHC-1224-xx User Manual Revision 1.0 3.2 LED I NDICATORS State Description No Charge (Nighttime) Charge Solid Green Solar power is charging the battery Blinking Green The system is over voltage Solid Green Battery level is in the right range Slow Flash Green Battery level is full Battery Solid Yellow... -
Page 8: Load Led
CHC-1224-xx User Manual Revision 1.0 When the battery voltage goes down continuously into an over-discharge condition, the Battery LED will turn red and the Load output will switch off. The system will automatically resume normal operation and switch on the load output and when the battery voltage recovers to the over-discharge return voltage. -
Page 9: Common Controller Mode
CHC-1224-xx User Manual Revision 1.0 3.3.4 Common Controller Mode The controller will work as a common controller, without light and time control, and no ON and OFF delay time. The load turns on immediately when there is no light, and off immediately when light is present on the PV panel. -
Page 10: Troubleshooting And Support
CHC-1224-xx User Manual Revision 1.0 5 TROUBLESHOOTING AND SUPPORT The Controller requires minimal care. It is recommended to inspect all the connections at least two times per year for insulation damage or corrosion and to ensure all connections are tight and secure. 5.1 M &... -
Page 11: Warranty
5.4.1 Restrictions No warranty will apply if the Product (i) has been altered or modified except by Windy Nation; (ii) has not been installed, operated, repaired, or maintained in accordance with instructions supplied by Windy Nation; (iii) has been subjected to abnormal physical, thermal or electrical stress, misuse, negligence, or accident. If Windy Nation determines that the problem with the Product is not due to a manufacturing defect in Windy Nation’s workmanship or materials, or otherwise does not qualify for warranty repair, then the Customer will... -
Page 12: Limitation Of Liability
Some states do not allow the exclusion or limitation of incidental or consequential damages, so these limitations may not apply to you. Neither Windy Nation nor its affiliates or suppliers will be held liable or responsible for any damage or loss to any items or products connected to, powered by or otherwise attached to the Product.
