VB2SX20SPS User Guide

Front Panel Controls

The VB2SX20SPS can be configured using the front panel buttons, which enables configuration without the need for a computer.
'■'
From the main screen, press the
Once in the configuration screen, press the '
'■'
to select the highlighted option. Some menus contain sub-menus, for example the Analogue and Digital Output menus
contain separate menus for each parameter.
MAIN MENU
UNITS
'■' '◄' '►'
Press and then the and buttons to
change the displayed Velocity units. Then press
'■'
to confirm.
KMH or MPH
MAIN MENU cont'd
GPS OPTIMISATION
'■' '◄' '►'
Press and then use the and
to change the amount of smoothing applied to
the Velocity Channel at source by the GPS
'■'
engine. Then press to confirm.
This must be set to High Dynamics for brake
stop tests.
This option has previously been called "Velocity
Smooth".
button to enter the configuration screen.
◄' ►'
and '
buttons to highlight the next or previous choice in any menu, and press
KALMAN FILTER
'■'
Press to enter the Kalman Filter Menu.
In this menu the amount of filtering applied to the Velocity
and Positional channels can be set between 0-4.
Velocity must t be set to 0 for Brake stop tests
DIGITAL1 SETUP
'■'
buttons Press to enter the
setup menu for the
Digital output Channel
1
COLDSTART
Press
perform a GPS
cold start
DIGITAL1 SETUP ANALOGUE1 SETUP
'■' '■'
Press to enter the Press to enter the setup
setup menu for the menu for the Analogue
Digital output Channel output Channel 1
2
Page 7 of 24
DGPS MODE
'■' '■'
to Press to enter the DGPS Menu, then
'►'
to move to the desired option. Then press
to confirm. Note that 20cm and 40cm options
require access to a DGPS basestation, and 20cm
also requires a paid upgrade to the VB2SX20SPS.
ANALOGUE2 SETUP
'■'
Press to enter the setup
menu for the Analogue
output Channel 1
'◄'
and
'■'
EXIT
'■'
Press to
exit the
setup menu
and cause
the settings
to be saved
in EEPROM
