APM -2400G-N Specification Sheet

APM-24005g-N
AP Specification
Standards Compliance
SDRAM
Flash
Radio Frequency Type
Modulation
Frequency Band
Transmission Power
Transmission Rate
Access Point Interfaces
Sensitivity
Antenna Type
Security Systems
Wireless Setting
1F, No.49, Alley 24, Lane 75, Sec 3, Kang-Ning Rd, Nei-Hu Dist, Taipei 114, Taiwan, R.O.C.
www.apm.com.tw apm.sales@msa.hinet.net
IEEE 802.11b
IEEE 802.3af
IEEE 802.3
IEEE 802.3u
8 M Byte
2 M Byte
DSSS / OFDM
IEEE 802.11b: CCK,DQPSK,DBPSK
IEEE 802.11g: OFDM with BPSK, QPSK, 16QAM, 64QAM
America/FCC: 2.412~2.462 GHz (11 channels)
Europe CE/ETSI: 2.412~2.472 GHz (13 channels)
IEEE 802.11b: 20 dBm
IEEE 802.11g: 20 dBm
IEEE 802.11b: 1/ 2/ 5.5/ 11Mbps
IEEE 802.11g: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54Mbps
Super G: up to 108Mbps
Auto MDI/MDI-X Ethernet 10/100Base-TX: RJ-45
-86dBm @ 11Mbps, PER < 8%; -64dBm @ 54Mbps, PER < 10%
N-tyype female / External high gain antenna ( optional )
64-bit/ 128-bit/ 152-bit WEP encryption; Wi-Fi Protected Access
(WPA)
Operation Mode – AP / Wireless Client / Repeater / Wireless Bridge
PtP and PtMP Mode
Tel: +886 2 26335543
APM CO., LTD
Fax: +886 2 26330472
1 of 2
