APM ALINE-5801A+G Specification Sheet

ALINE-5801a+g
AP Specification
Standards Compliance
SDRAM
Flash
Radio Frequency Type
Modulation
Frequency Band
Transmission Power
Transmission Rate
Access Point Interfaces
Sensitivity
Antenna Type
Security Systems
22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
www.apm.com.tw
IEEE 802.11a / b/ g
IEEE 802.3
IEEE 802.3u
IEEE 802.3af
32 M Byte
4 M Byte
DSSS/ OFDM
IEEE 802.11a : OFDM with BPSK, QPSK, 16QAM, 64QAM
IEEE 802.11b: CCK,DQPSK,DBPSK
IEEE 802.11g : OFDM with BPSK, QPSK, 16QAM, 64QAM
IEEE 802.11a:
5.15 ~ 5.25 GHz (lower band)
5.50 ~ 5.70 GHz (middle band)
5.725 ~ 5.85 GHz (hi-band)
IEEE 802.11b/g:
2.4~2.4835GHz
Up to 100mW (software provisionable)
108(Turbo mode)/54/48/36/24/18/12/9/6Mbps auto fallback
Auto sensing MDI/MDI-X Ethernet 10/100Base-TX: RJ-45
Radio Wave: Antenna N-Male
6Mbps:-88dBm;9Mbps:-87dBm;12Mbps:-86dBm;
18Mbps:-84dBm;24Mbps:-81dBm;36Mbps:-72dBm;
48Mbps:-76dBm;54Mbps:-68dBm
Dual external high gain antenna
64/128/152-bit WEP encryption, WPA/TKIP/AES/ACL,
802.1x authentication control, MAC filtering
apm.sales@msa.hinet.net
APM CO., LTD
Tel: +886 2 89431966 Fax: +886 2 89434944
1 of 2
