APM ABR-502401ABG Specification

ABR-502401abg
Specification
Standards Compliance
SDRAM
Flash
Radio Frequency Type
Modulation
Frequency Band
Transmission Power
Transmission Rate
Access Point Interfaces
1F, No.49, Alley 24, Lane 75, Sec 3, Kang-Ning Rd, Nei-Hu Dist, Taipei 114, Taiwan, R.O.C.
www.apm.com.tw apm.sales@msa.hinet.net
APM CO., LTD
IEEE 802.11a /b/g; IEEE802.3; IEEE802.3u; IEEE 802.3af
32 M Byte
8 M Byte
DSSS/OFDM
IEEE 802.11a : OFDM with BPSK, QPSK, 16QAM, 64QAM
IEEE 802.11b: CCK,DQPSK,DBPSK
IEEE 802.11g : OFDM with BPSK, QPSK, 16QAM, 64QAM
IEEE 802.11a:
5.15 ~ 5.25 GHz (lower band)
5.25 ~ 5.35 GHz (middle band)
5.725 ~ 5.825 GHz (hi-band)
IEEE 802.11b/g:
America/FCC ： 2.412~2.462 GHz (11 channels)
Europe CE/ETSI ： 2.412~2.472 GHz (13 channels)
IEEE 802.11a : 20 dBm
IEEE 802.11b : 20 dBm
IEEE 802.11g : 20 dBm
IEEE 802.11a : 6/9/12 /18/24/36/48/54 and 108Mbps
IEEE 802.11b : 1/2/5 .5/11Mbps
IEEE 802.11g : 6/9/12 /18/24/36/48/54 and 108Mbps
Auto sensing MDI/MDI-X Ethernet 10/100Base-TX: RJ-45
Tel: +886 2 26335543 Fax: +886 2 26330472
1 of 2
