AvaControl-100 User Manual

Thank you for purchasing
AvaControl-100
Model: AvaControl-100
Please read this manual carefully
before installing.
Page.1 of 17
7/24/2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AvaControl-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Z-Wave AvaControl-100

Summary of Contents for Z-Wave AvaControl-100

  • Page 1: Avacontrol-100 User Manual

    2014-07-24 AvaControl-100 User Manual Thank you for purchasing AvaControl-100 Model: AvaControl-100 Please read this manual carefully before installing. Page.1 of 17 7/24/2014...

  • Page 2: Table Of Contents

    AvaContorl-100 Explain the functionality ..............9 Create room - To distinguish Z-Wave devices ............. 9 Scene Setting - Control Z-Wave devices ..............10 Set schedule - timed Z-Wave devices work arrangements ......... 12 III. Use the report-Z-Wave devices use electricity ............12 Appendix - mobile &...

  • Page 3: Avacontrol-100 Z-Wave Controller Gateway

    A. AvaControl-100 Z-Wave Controller Gateway Congratulations on your purchase! Your AvaControl-100 is ready to put you in control of your home. Please take a few minutes to read through this guide to familiarize yourself with the steps required to set up your Z-Wave network and your AvaControl-100.

  • Page 4: Items List

    USB adaptor AC/DC adaptor Product Image III. AvaContorl-100 Initial Setup After you’ve created your Z-Wave network, you’ll need to install your AvaContorl-100. Follow these steps: 1. AvaContorl-100 Hardware Installation step 1. Connect the Ethernet cable to your AvaContorl-100 and to a network port on your internet router.
  • Page 5 Step 1 Connect the Ethernet cable to WAN port Step 1 & 2 finish plan Step 4 Flash can be used AvaContorl-100 had three platforms are available, including Web platform, Android platform and iOS platform, and the specification by the Webpage sections shows, and other mobile phone sections can also be turned to the appendix - mobile &...

  • Page 6: Webpage Sections - To Establish A Connection

    2. Webpage sections - to establish a connection step 1. Enter the setup.myehome.my in the browser step 2. To apply for a new account password step 3. Enter the account number and password, to access interface. step 4. Since then logged into this account and password step 1.

  • Page 7: Z-Wave Device Network Settings

    AvaContorl-100 mainly in the control and monitoring of the room, that requires Z-Wave device to complete the task. You need to add the Z-Wave devices to AvaContorl-100, that can be used to monitor and control the functions of the device. Or has not used the device can be removed.

  • Page 8: Remove The Z-Wave Device

    Step6 You can use the new Z-Wave Step5 You can modify the name and room  Note: Z-Wave devices from different manufacturers can add all use, and connection settings, please refer to the manual for this Z-Wave devices. II. Remove the Z-Wave device step 1.

  • Page 9: Avacontorl-100 Explain The Functionality

    This part of illustrates how to use the function AvaContorl-100's because of the new Z-Wave device can only operate a single object, and the function AvaContorl-100 Z-Wave devices can be classified and integrated use of its features include room, situational triggers, scheduling and reporting, the following will be introduced one by one.

  • Page 10: Scene Setting - Control Z-Wave Devices

    Meeting room configuration device I. Scene Setting - Control Z-Wave devices You can control a number of Z-Wave devices combine together again, and performed together after the completion of the operation set by a key operation is complete. step 1.
  • Page 11 Step 4 Click on usage scenarios To set the monitor entry based Z-Wave devices function when the device is triggered, the alarm can be launched. Figure 1 alarm settings. Z-Wave control connection monitoring situations, a combination of two functions set. Figure 2 people into the lights up.

  • Page 12: Set Schedule - Timed Z-Wave Devices Work Arrangements

    II. Set schedule - timed Z-Wave devices work arrangements You can set up a schedule for regular monitoring of home security. When setting the home nobody, automatically turn on monitoring items Z-Wave devices. Set schedule III. Use the report-Z-Wave devices use electricity This feature requires multi Smart Energy Switch device can monitor the amount of current.

  • Page 13: Appendix - Mobile & Tablet Sections

    D. Appendix - mobile & tablet sections AvaControl-100 can be used on iOS and android operating system, can be online at Play Store & apple store search AvaControl download. I. Establish a connection - Mobile Register step 1. With WIFI connection step 2.

  • Page 14: Add / Remove The Device

    Click "Settings" and then click "Add / Remove Device", "add device" or "Remove Device" step 2. In this case, manual operation of the Z-Wave device linkages step 3. Successful there will be "new device, the operation was successful", your device will add better.
  • Page 15 Click on "Remove Device" screen will appear "Add device: user operations sent, please wait. " step 3. At this point, the connection key manual Z-Wave devices step 4. Success will be "to remove the device, the operation was successful", your device will be removed as well.

  • Page 16: Room

    Increase control this scenario Z-Wave devices step 3. Setting the action performed by each device step 4. You can click on to set a good situation, the corresponding Z-Wave devices can be used Step 1 Add Scene Step 2 Add Z-Wave devices and settings Step 3 can use Page.16 of 17...

  • Page 17: Trigger Set

    V. Trigger Set step 1. Click the "trigger" and then click Add step 2. Set the trigger name and trigger sources (that is Z-Wave devices) step 3. Connected together to set the context Step 1 Add Step 2 Set the trigger...
