  • Page 1 ™ Z-Wave Home Gateway ® FG2200 (LAN to Z-Wave Home gateway) ® FG3200 (WiFi to Z-Wave Home gateway) User's Manual...

  • Page 2: Table Of Contents

    ......2 NSTALLATION AND ONNECTION ..........3 ACKAGE ONTENTS PRODUCT OVERVIEW........4 FG2200 ............4 FG3200 ............5 SPECIFICATION ..........6 FG2200 ............6 FG3200 ............8 ANDROID AND IOS APP DOWNLOAD ....11 HOME GATEWAY INSTALLATION AND SETUP ... 12...
  • Page 3 FAQ ..............50 ..... 50 OME GATEWAY FIRMWARE UPDATE ......53 HOME GATEWAY TIME SETTING WHAT TO DO IF YOUR ARE FAILED TO LOGIN BUTLER ..............57 . 61 OW TO REMOVE THE GHOST NODE OF THE DEVICE REGULATORY COMPLIANCE ......64 FCC C ..........

  • Page 4: Safety Instructions

    Before attempting to connect, operate or adjust this product, please save and read the User's Manual completely. The style of the product shown in this User's Manual may be different from the actual unit due to various models. Safety Instructions Always read the safety instructions carefully: ■...

  • Page 5: Introduction

    Connect your Z-Wave Home Gateway with a router using your LAN cable and start the controller. From now on Z-Wave Home Gateway will be visible to all devices within your local area network (LAN). Make the connection with the mobile phone and...

  • Page 6: Package Contents

    Package Contents FG2200 Adapter FG3200 Z-Gate Built-in Antenna (FG3200 only) 5V/2.5A Adapter...

  • Page 7: Product Overview

    Product Overview FG2200 Item Description Mounts the device to the wall 1 Wall Mount Hole Connects to an Ethernet 2 RJ45 port 3 DC-in jack Connects to the power adapter 4 Reset Restores to the default settings 5 LED Power (Red); LAN / WAN (Green);...

  • Page 8: Fg3200

    2 Wall Mount Hole Mounts the device to the wall 3 RJ45 port Connects to an Ethernet Connects to the power adapter 4 DC-in jack Restores to the default settings 5 Reset Power (Red); LAN / WAN (Green); 6 LED ® Z-Wave (Blue)

  • Page 9: Specification

    Specification FG2200 Main Function 400MHz CPU Clock Rate Core 64M Bytes DDR2 SDRAM 8M Bytes Flash Interface RJ-45 Ethernet Standard IEEE802.3 Speed 10/100Mbps For Bridge or Wireless ISP Mode For Gateway Mode ® RF Frequency 908.42 MHz (US) Z-Wave 868.42 MHz(EU) 922.5 MHz (JP)
  • Page 10 TF Card Support up to ver. 2.0 (SDHC) Micro SD Slot (Option) Compatible with ver. 3.0 (SDXC) Power Input 5VDC DC Jack Input AC 100-240V Power Adapter Output DC 5V/2.5A Normal Mode 1.15W Power Consumption Housing Material ABS (Plastic) Physical Properties Dimension 104 x 50 x 17.5 mm...

  • Page 11: Fg3200

    2.412, 2.442, 2472GHz in 802.11 b/g Channels and 802.11n HT20 modes 2.422, 2.437, 2.452, in 802.11n HT40 mode Interface RJ-45 Ethernet Standard IEEE802.3 Speed 10/100Mbps For Bridge or Wireless ISP Mode For Gateway Mode ® RF Frequency 908.42 MHz (US) Z-Wave 868.42 MHz(EU)
  • Page 12 -97 dBm @40 kbit/s -93 dBm @100 kbit/s Power LED Indicator Display Green LAN / WAN ® Blue Z-Wave TF Card Support up to ver. 2.0 (SDHC) Micro SD Slot (Option) Compatible with ver. 3.0 (SDXC) Power Input 5VDC DC Jack...
  • Page 13 Operation 0~60 degree Working Temperature Environment Storage -20~85 degree Temperature Relative 5~90% (Non-condensing) Humidity CE, FCC Compliance...

  • Page 14: Android And Ios App Download

    NOTE: Before using APP, please activate the Wi-Fi function of Android/iOS mobile device. The device should be able to locate the network FG2200/FG3200R1, please input the default password 89191200, and make sure it is successfully connected.

  • Page 15: Home Gateway Installation And Setup

    Home Gateway Installation and Setup How to make FG3200 Home Gateway support Intranet and Internet Step1. Connect LAN cable first and then power on Home Gateway.
  • Page 16 Step 2. Install Z-Butler app. Search Wi-Fi signal FG3200R1.
  • Page 17 Step 3. Connect FG3200R1 with access code 89191200.
  • Page 18 Step 4. Start Z-Butler app. Follow the instruction to Add New Gateway. You can search gateway signal.
  • Page 19 Step 5. Click the pop-up gateway information bar.
  • Page 20 Step 6. Setup name, account and password. Account and password default as “admin”/ “1234”.
  • Page 21 Step 7. Start the device inclusion.
  • Page 22 Step 8. To verify if the Internet works ok. Please switch Wi-Fi signal to Internet-available signal or switch to 3G/4G signal only.
  • Page 23 Step 9. Get into Z-Butler app. On seeing device list, all is ready for us.

  • Page 24: Z-Butler App Manipulate And Setup

    Z-Butler APP Manipulate and Setup Step 1. Select Scene settings from function bar.
  • Page 25 Step 2. Give the name to the scene task.
  • Page 26 Step 3. Click SelectSensor from Start Condition.
  • Page 27 Step 4. Select Door Sensor from Sensor Device. Select On from Sensor Status. Click New Perform_ Action to implement.
  • Page 28 Step 5. Click SelectZWave device from Perform_Actions.
  • Page 29 Step 6. Choose Siren from Action Device. Select On from Sensor Status.
  • Page 30 Step 7. Press OK.
  • Page 31 Step 8. Please Click “+” if you want to add more scene setting.
  • Page 32 Step 9. Give a name to the new scene.
  • Page 33 Step 10. Click SelectSensor from Start Condition.
  • Page 34 Step 11. Choose Door Sensor from Sensor Device. Click OFF from Sensor Status. Click New Perform_Action.
  • Page 35 Step 12. Click SelectZWave Device from Perform _ Actions.
  • Page 36 Step 13. Select Siren from Action Device. Click OFF from Sensor Status. Press OK.
  • Page 37 Step 14. Press OK.
  • Page 38 Step 15. You will see all the scene setting that you have made from the list.

  • Page 39: Open Notification In Z- Butler App

    Open “Notification” in Z-Butler APP Step 1. After finishing installing Z-Butler app in Android mobile, go to Settings and click Apps. (the user of iOS system please skip step 1-7)
  • Page 40 Step 2. Click Z-Butler.
  • Page 41 Step 3. Click Show notifications.
  • Page 42 Step 4. In Z-Butler app, match up with TS2001Z1 Door Sensor.
  • Page 43 Step 5. Click Notification Settings in the setting section.
  • Page 44 Step 6. Check Push notification sound and Push notification vibrate.
  • Page 45 Step 7. Exit Z-Butler app to mobile desktop or mobile standby screen. When TS2001Z1 Door Sensor is triggered, your mobile will receive “Door Sensor is triggered” message and vibration.
  • Page 46 Step 8. After finishing installing Z-Butler in iOS mobile, click Settings> General.
  • Page 47 Step 9. Click Notification.
  • Page 48 Step 10. Open Allow Notifications, Show in Notification Center, Sounds, Badge App Icon and Show on Lock Screen.
  • Page 49 Step 11. Match up with TS2001Z1 Door Sensor in Z-Butler app.
  • Page 50 Step 12. Check Push notification sound and then exit to mobile desktop or mobile standby screen. When TS2001Z1 Door Sensor is triggered, your mobile will receive “Door Sensor is triggered” message.

  • Page 51: Application And Diagram

    After receiving the signal, Z-Wave Home Gateway will send commands to both Z-Wave Siren and the mobile phone connected. As a result, Z-Wave Siren will sound the alarm, while the mobile phone APP will notify to alert the user and keep records.

  • Page 53: Faq

    Home Gateway Firmware Update Step 1. Connect computer to FG3200R1 by using network cable. Then go to Control Panel > Network and Internet > Network and Sharing Center > Change Adapter Settings > Ethernet (right-click the mouse) > Properties > Internet Protocol Version 4 (TCP/IPv4) > Properties.
  • Page 54 Step 2. Open IE Browser and key in 192.168.0.254 in the IP address. Step 3. Click Management > Upgrade Firmware.
  • Page 55 Step 4. Click SelectFile to find FG3200R1 Firmware and select it. Then, click Upload. Step 5. “Change Setting Successfully” message will show on the screen and need to wait for 107 seconds. After 107seconds, the Home Page shows up which means the update is completed.

  • Page 56: Home Gateway Time Setting

    Home Gateway Time Setting Step 1. Login the Web Portal of FG3200 Home Gateway Web Portal by entering IP address 192.168.1.254 in your IE. Select Time Zone Setting from left function column.
  • Page 57 Step 2. Set the time in manual or through NTP server.
  • Page 58 Step 3. Please select time zone and input time. Please remember to click Apply Change and Reboot Now separately to ensure the setting take effect.
  • Page 59 Step 4. You can choose to set time from NTP server if FG3200 Home Gateway is connected with Internet. Please tick the box and select the corresponded time zone. Remember to click Apply Change and Reboot Now.

  • Page 60: What To Do If Your Are Failed To Login Butler

    What to do if you are failed to login Z-Butler? Please follow the steps below: Step 1. Find the Z-Butler from Application Manager of setting.
  • Page 61 Step 2. Execute Clear Data.
  • Page 62 Step 3. Connect to Home Gateway FG3200R1 (Intrenet only) or your home AP router (with Internet connection).
  • Page 63 Step 4. Open Z-Butler app. Input the default account “admin” and password “1234”.

  • Page 64: How To Remove The Ghost Node Of The Device

    How to remove the ghost node of the device? Step 1. Select Node.
  • Page 65 Step 2. Select Remove Device.
  • Page 66 Note: Removing Ghost node does not indicate that this device excludes successfully. Users need to re-execute inclusion/exclusion and then you can use the device normally.

  • Page 67: Regulatory Compliance

    Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 Class B of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received and include interference that may cause undesired operation.
  • Page 68 Z-Wave Home Gateway User's Manual V3.1...
