Page 1: Table Of Contents
Table of Contents Introduction……………...………………………………………... 1 Package Content………...………………………………………… 1 System Requirement……………………………………………… 2 Dimensions……………...………………………………………… 2 Installation………………………………………………………… 3 Formatting………………………………………………………… 8 Extra power cable……….………………………………………… 8 FAQ……………………...………………………………………… 9... -
Page 2: Introduction
Enermax JAZZ EB207U Introduction Jazz EB207U is a slim, compact and outstanding looking IDE to USB 2.0 2.5” HDD enclosure. The case is made of aluminum and steel mesh as one of the coolest enclosures available. It’s also small enough to fit in your pocket, making it extremely convenient to carry anywhere;... -
Page 3: System Requirement
Enermax JAZZ EB207U System Requirement a. Hardware: PC or MAC with USB interface b. OS requirement: Windows 2000, Windows XP, Windows ME, Windows Vista （ No driver needed） Windows 98/SE (please log on www.enermax.com for 98SE’s driver) Mac OS 8.6 or higher Dimensions Dimensions: 138.8mm x 78.3mm x 17mm / 5.46”... -
Page 4: Installation
Enermax JAZZ EB207U Installation a. Unlock 2 screws and remove the cover (See Figure A) Figure A - 3 -... - Page 5 Enermax JAZZ EB207U b. Connect your hard drive to the IDE PCB connector (See Figure B) Figure B - 4 -...
- Page 6 Enermax JAZZ EB207U c. Place your HDD（with PCBA）on the base. (See Figure C) Figure C - 5 -...
- Page 7 Enermax JAZZ EB207U d. Put the cover on the base and please notice the triangle mark should be always toward the right direction. Lock the enclosure with screws. (See Figure D) Figure D - 6 -...
- Page 8 Enermax JAZZ EB207U e. Stick rubber feet enclosed in the package. (See Figure E) Figure E - 7 -...
-
Page 9: Formatting
Enermax JAZZ EB207U Formatting Please have the hard disk formatted before the first time use. Extra power cable If the following two situations happened, JAZZ enclosure may need extra power support. Please connect the USB-DC Jack cable to your PC/NB for extra power support. -
Page 10: Faq
HDD has been formatted. © Copyright 2007 Enermax Technology Corporation. All Rights Reserved. The information contained in this manual is believed to be accurate and reliable. Enermax Technology Corporation assumes no responsibility for any errors contained in this manual. Enermax Technology Corporation reserves the right to make changes in the specifications and/or design of this product without prior notice.
