T
O CONNECT CABLES AND COMPONENTS AND START THE
1 Connect the following cables and components to the Fiery proServer:
1
2
6
4
2 Move the power switch to the ON ( | ) position.
3
5
F S
IERY PRO ERVER
Key:
1 Power cable
2 Network cable (straight-through Ethernet cable)
3 Monitor
4 Keyboard and mouse
5 Printer cable (optional)
6 Fiery XF dongle
