User Manual: PS020A
DMX-controlled 3-CHANNEL Power Supply
A16 Hard switch turquoise-pink
A17 Hard switch red-green-blue
A18 Hard switch red-yellow-green-turquoise-blue-pink
A19 Random speed red-yellow (Fire)
A20 Random speed green-blue (Ocean)
A21 Random speed red-blue
A22 Random speed red-green-blue (RGB)
A23 White strobe
A24 Red strobe
A25 Green strobe
A26 Blue strobe
A27 Strobe chase red-green-blue
"C" Colour Mode
Press the MODE button (5) until the first digit on the display shows "C", indicating
operation in "C" (COLOUR) mode. Then choose by using the UP/DOWN buttons (6/7)
one of the 19 preset colours as shown in the list below. Changing the setting becomes
effective directly. Knob (1) determines the dimming level.
In "C" mode, the unit does not receive any values from the DMX input but generates
related DMX values on the output according to the selected pattern, so that other
similar units from the Multiform LS series of LED devices can show the same colour if
they are connected by DMX signal cables and set to Slave Mode "SLA".
NOTE: The "C" Mode is automatically disabled and can not be chosen when an
external DMX signal is received [DMX indicator LED (3) is lit].
If you leave mode "C" for any reason and come back later into mode "C", the unit will
recall the last chosen colour (even if the unit was switched off in between).
Available colour presets:
C 0 all off
C 1 Red
C 2 Green
C 3 Blue
C 4 Yellow
C 5 Pink
C 6 Turquoise
C 7 Lime
C 8 Orange
C 9 Marine
V1.00 (06-2007) © Multiform, Leigh-on-Sea, UK
Sound-to-light, Speed
Sound-to-light, Speed
Sound-to-light, Speed
None
None
None
None
Sound-to-light, Speed
Sound-to-light, Speed
Sound-to-light, Speed
Sound-to-light, Speed
Sound-to-light, Speed
C10 Frog
C11 Lavender
C12 Candy
C13 Peach
C14 Aqua
C15 Leaf
C16 Purple
C17 Barbie
C18 Breeze
C19 White
User Manual: PS020A
■ Getting started: choosing a location
Risk of fire: The PS020A DMX-controlled 3-Channel power supply has
been designed to work in dry indoor environments at environmental
temperatures up to 40 degrees Celsius. For proper operation, the
PS020A DMX-controlled 3-Channel power supply must be operated
with its heatsink side up, and unobstructed air convection to the
heatsink.
Do not:
- Operate
environments with more than 40 degrees environmental temperature or more
than 80% humidity.
- Operate the PS020A DMX-controlled 3-Channel power supply in any position
inclined or reclined more than 45 degrees from being upright (heatsink on top).
- Operate the PS020A DMX-controlled 3-Channel power supply in any closed
environment smaller than 10cbm, unless forced air convection is provided.
10
V1.00 (06-2007) © Multiform, Leigh-on-Sea, UK
DMX-controlled 3-CHANNEL Power Supply
the PS020A DMX-controlled 3-Channel power supply in
