User Manual: PS020A
DMX-controlled 3-CHANNEL Power Supply
■ APPENDIXES
A. Safety rules for overhead rigging (applicable if the PS020A DMX-controlled 3-
Channel power supply is mounted to any of the Multiform LS series passive RGB LED
panels):
Risk of injury: Overhead mounting requires extensive experience,
including among others calculating working load limits, good knowledge
of the installation material being used, and periodic safety inspection of
all installation material and the unit. If you lack such qualifications, do
not attempt the installation yourself. Improper installation can result in
body injury. Be sure to complete all rigging and installation procedures
before applying power to the unit.
•
The unit should be installed out of reach of people and outside areas where
persons may walk by or be seated.
•
Make sure that the installation area can hold a minimum point load of 10 times the
device's weight.
•
In fixed installations, fix the unit with self-locking screws/nuts to the mounting point.
•
When mounting the unit to truss be sure to secure an appropriately rated clamp to
the hanging yoke using a M10 screw fitted through the center hole of the hanging
yoke.
•
Always use a certified safety cable that can hold 12 times the weight of the device
when installing the unit. This secondary safety attachment should be installed in a
way that no part of the installation can drop more than 20cm if the main attachment
fails.
•
Never stand directly below the device when mounting, removing, or servicing the
fixture. Make sure the area below the installation place is free from unwanted
persons during rigging, de-rigging and servicing.
•
The operator has to make sure that the safety-relating and machine-technical
installations are approved by an expert before using them for the first time. The
installations should be inspected every year by a skilled person to be sure that
safety is still granted.
V1.00 (06-2007) © Multiform, Leigh-on-Sea, UK
16
USER MANUAL
DMX-controlled 3-Channel power supply
Updated versions of this document may be available at
WWW.MULTIFORM-LIGHTING.COM
RevA 06/2007 Order code: 12-010-0233-80100-1-01
PS020A
