User Manual: PS020A
DMX-controlled 3-CHANNEL Power Supply
"P" DMX Preset Mode
If you want to run the pre-programmed patterns and scenes by an external DMX-
controller you can use the DMX Preset Mode. Press the MODE button (5) until the
display shows "P", indicating operation in "P" (DMX Preset) mode. Set the DMX starting
address by simply using the UP/DOWN buttons (6/7). The chosen DMX-address comes
effective approximately 3 seconds later and will show up on the display (2) in
alternation to the "P".
The unit receives DMX values on a packet of four channels and mirrors the received
data on the DMX output (13). If a DMX signal is present the DMX LED (3) will turn on.
The four channels control the unit as follows:
If DMX-value of channel 3 is lower than 50 the unit works with static colours:
DMX Channel
Value Range
CH1
000-255
CH2
000-255
CH3
000-049
CH4
000-049
050-255
Colour presets can be activated by means of CH1 whilst the chosen colour can be
dimmed by weighting the colour balance with CH2. If the value of CH4 is above 50 the
unit is set to strobe mode.
The strobe speed for any fixed colour chosen on the first
channel can be adjusted from zero (value <50) to 23 flashes per second (value 255).
If DMX value of channel 3 is equal or higher than 50 the unit works in pattern mode:
CH1
Pattern
000-015
Soft fade red-green
016-030
Soft fade green-blue
031-045
Soft fade green-blue
046-060
Soft fade red-yellow
061-075
Soft fade candy-lime
076-090
Soft fade pink-blue
091-105
Soft fade turquoise-pink
106-120
Soft fade red-green-blue
121-135
Hard switch red-green
DMX
Value range
CH2
000-255
CH3
050-255
CH4
000-049
050-255
V1.00 (06-2007) © Multiform, Leigh-on-Sea, UK
Function
Colour choice from presets (see "C" mode)
Dimmer
Static colour mode active
Strobe off
Strobe (050=slow / 255=max. speed 23 Hz)
CH1
Pattern
136-150
Hard switch green-blue
151-165
Hard switch red-blue
166-180
Hard switch red-yellow
181-195
Hard switch candy-lime
196-210
Hard switch pink-blue
211-225
Hard switch turquoise-pink
226-240
Hard switch red-green-blue
241-255
Hard switch red-yellow-green
-turquoise-blue-pink
Function
Dimmer
Chase speed
Strobe off
Strobe (050=slow / 255=max. speed 23 Hz)
User Manual: PS020A
■ Functional advice
This unit is immune to the presence of electromagnetic disturbances – both conducted
and radiated - up to a certain level. Under peak conditions, the unit is classified to show
a "class C" performance criteria and may encounter temporary degradation or loss of
function which may need manual help to recover. In such case, disconnect the AC
power from the unit and reconnect it again to recover.
■ Environmental advice
This unit is build to conform to the ROHS standards and the WEEE
directive 2002/96/EC of the European Parliament and of the Council of
the European Union. Under these regulations, the product shall not be
discarded into regular garbage at the end of its life, but shall be returned
to authorized recycling stations.
■ Unpacking
Please check that the box contains the following items:
Main parts:
Accessory parts:
If any part is missing, please contact your dealer immediately for replacement.
Note: Your dealer may have chosen to pre-assemble this product with any suitable of
Multiform's LS series passive RGB LED panels for you. In this case, the above
accessory parts have already been used during assembly.
■ Getting started: connecting/assembly
In case your dealer did not pre-connect/assemble the unit for you with any of
Multiform's LS series passive RGB LED panels, you need to connect/assemble it
before use.
Risk of electric shock: Do not connect the mains cable before the
following steps are accomplished!
For assembly, there are two basic choices:
12
V1.00 (06-2007) © Multiform, Leigh-on-Sea, UK
DMX-controlled 3-CHANNEL Power Supply
1 pcs. PS020A main unit
1 pcs. mains cable
1 pcs. operation manual
1 pcs. Mounting cover
2 pcs. Mounting screw
1 pcs. connection cable to panel
5
