M A N U A L
Mounting parallel bench srew
mountingsystem
Vacuum tube collector CVSKC - 10
6 9 0 8 2 3 / version 2006.10

Advertisement

Table of Contents
loading

Summary of Contents for FireBird CVSKC-10

  • Page 1: Mounting Parallel Bench Srew Mountingsystem

    M A N U A L Mounting parallel bench srew mountingsystem Vacuum tube collector CVSKC - 10 6 9 0 8 2 3 / version 2006.10...
  • Page 2: Table Of Contents

    Contents Safety information ..................3 Transport note ....................4 Assembly instructions - Collector..............5 Overview of tools ..................6 Overview of materials ..................7 Suggenstion for attachment points..............8 Mounting parallel bench srew mountingsystem ..........9 T echnical data - Collector................12 Operating tips - Solar power system .............. 13 General Information..................
  • Page 3: Safety Information

    Safety information Safety precautions: Before commencing mounting work on roofs, it must be ensured in all cases that the non-personal fall protection and fall-arrest Safety harnesses should be fixed above the users systems required by DIN 18338 (Roof Covering and whenever possible.
  • Page 4: Transport Note

    Transport note ATTENTION: Do not lift collectors by the connections or the screw threads!
  • Page 5: Assembly Instructions - Collector

    Assembly instructions - Collector Instructions for installation and transport The installation may only be carried out by qualified personnel. Only the supplied material should be used for the installation. Please inform yourself about the applicable local norms and regulations before mounting and operating the solar system.
  • Page 6: Overview Of Tools

    Overview of tools Measuring tape Drill 8 mm twist drill (wood) 14 mm stone drill (brick) Hex spanner Angle grinder Hacksaw Installation wrench...
  • Page 7: Overview Of Materials

    Overview of materials Bench screw M12*350 Rubber seal M12 washer M12 hex nut Ř 13 mm clamping piece Support rail Connecting piece M8*30 hex bolt M8 washer Flat gasket M8 hex nut...
  • Page 8: Suggenstion For Attachment Points

    Suggenstion for attachment points CVSKC-10 Atachment Collectors Total lenght points 235 cm 352 cm 469 cm 588 cm 705 cm 826 cm 947 cm ..Attachment points...
  • Page 9: Mounting Parallel Bench Srew Mountingsystem

    Mounting parallel bench srew mountingsystem The attachment points (on the rafter) must be measured precisely for this type of installation. 1: A = 171cm Generally, the following applies: two supports per collector. 2: Drill tiles 14mm 3: Drill rafters 4: Fasten bench screw, minimum screw depth ≥ 100mm...
  • Page 10 Mounting parallel bench srew mountingsystem 5: Attach the rubber seal and tighten Sequence: rubber seal - washer - nut 6: Set the clamping pieces to a common height and secure them (distance from top edge of the brick to bottom edge of the clam- ping piece approx.
  • Page 11 Mounting parallel bench srew mountingsystem 8: Insert the collectors and attach them to the support rails with screws. Sequence: screw - washer - support rail - collector 9: Connecting other support rails Sequence: screw - washer - connecting piece - nut 10:Connect the collectors to one another.
  • Page 12: T Echnical Data - Collector

    Information about the collector Technical data Gross area 1,84 Weight Net area 1,69 Contents 1,63 Apertur 1,60 max. Pressure...
  • Page 13: Operating Tips - Solar Power System

    Operating tips - Solar power system Flushing and filling For safety reasons, you should only fill the collectors when there is no direct irradiation from the sun (or cover the collectors). Especially in regions exposed to frost, you should use non-mixable, premixed antifreeze. Recommended antifreeze for evacuated tube collectors: FSV It may not be possible to completely empty collectors once they have been filled.
  • Page 14 Operating tips - Solar power system Connecting the collectors to one another The diagram below is an example of how the collectors can be connected to one another. However, the actual connection may be different depending on structural conditions. A maximum of 8 collectors may be connected in a series! If a collector panel is made up of more than 8 collectors, the panel must be connected several times in parallel.
  • Page 15: General Information

    General Information Guarantee and Warranty No liability is accepted for incorrect use, unauthorized changes to the assembly components, or the resulting con- sequences. All information and instructions in this manual refer to the current state of development. Please always use the re- spective assembly instructions supplied with the collectors.
