Installation instructions, accessories - Subwoofer
Installation instructions, accessories - Subwoofer
Volvo Car Corporation Göteborg, Sweden
Volvo Car Corporation Göteborg, Sweden
XC90
XC90
XC90 2003, XC90 2004, XC90 2005, XC90 2006, XC90 2007, XC90 2008, XC90 2009, XC90 2010
XC90 2003, XC90 2004, XC90 2005, XC90 2006, XC90 2007, XC90 2008, XC90 2009, XC90 2010
© VolvoCar Corporation, 2004 Printed in Sweden
© VolvoCar Corporation, 2004 Printed in Sweden
Section Group Weight(Kg/Pounds) Year
Section Group Weight(Kg/Pounds) Year
3
3
39
39
Replaces issue: 2002 05
Replaces issue: 2002 05
Month
Month
2004 04
2004 04
9162298
9162298
Page 1 of 20

Advertisement

loading
Need help?

Need help?

Do you have a question about the XC90 2003 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Volvo XC90 2003

  • Page 1 2004 04 2004 04 XC90 2003, XC90 2004, XC90 2005, XC90 2006, XC90 2007, XC90 2008, XC90 2009, XC90 2010 XC90 2003, XC90 2004, XC90 2005, XC90 2006, XC90 2007, XC90 2008, XC90 2009, XC90 2010 Replaces issue: 2002 05 Replaces issue: 2002 05 ©...
  • Page 2 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Required tools A0000162 A0801178 A0000161 R8802817 R3903989 © VolvoCar Corporation, 2004 Printed in Sweden © VolvoCar Corporation, 2004 Printed in Sweden...
  • Page 3 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden R3904979 Any comments on this publication? Please contact your nearest dealer. Thank you! Publication no: MA 9162298, Issue: 2004-04 Comments:......................
  • Page 4 Work on the SRS/SIPS systems or related components must always be order of operation is repeated in the text section carried out by an authorised Volvo workshop. Cut out the text page in order to follow the illustrations and text at Is the car equipped with SRS (supplemental restraint system)? the same time.
  • Page 5 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden CAUTION! The air bag inflation areas must not be obstructed. Never place any objects, such as upholstery or accessories, within these areas.
  • Page 6 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Preparatory work Move the left front seat as far forward as possible Turn the ignition key to position 0 Disconnect the battery negative lead.
  • Page 7 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Preparatory work Remove the side floor hatch (A) and the folding side panel (B) on the left-hand side in the cargo compartment.
  • Page 8 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Preparatory work Remove the panel for the front mounting on the left-hand seat in the second row of seats by pressing down the catch (1) on top and detaching the panel by pulling it forward Remove the screw underneath.
  • Page 9 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Use a weatherstrip tool. Illustration A Continue to pull off the sill trim panel until the remaining clips release Unhook the sill trim panel from the B-post panel. Place the sill trim panel in the cargo compartment Remove the seat.
  • Page 10 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Pull the panel backwards to release it. Preparatory work Pull off the left-hand D-post panel starting at the top edge. Then pull downwards until the three clips on the inside have released.
  • Page 11 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Preparatory work Illustration A Remove the rear electronic module (REM). First release the catch (1) on the top of the module Fold the module forwards.
  • Page 12 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Preparatory work Take the left side panel and carefully cut away the insulation on its reverse to expose an area in front of the subwoofer.
  • Page 13 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Cable routing and connecting to the fusebox and Subwoofer Take the red cable from the cable harness. Install the cable on the reverse of the fusebox in position 13 and socket 2 as illustrated Take the 15 Amp fuse from the kit.
  • Page 14 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Cable routing and connecting to the fusebox and Subwoofer Connect the two connectors on the cable harness to the two sockets underneath the amplifier section of the subwoofer.
  • Page 15 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Press down the catch on top of the largest connector (1) (14-pin). Pull it off the connector in the connector bridge.
  • Page 16 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Connect the two bound connectors on the cable harness to the two sockets underneath the amplifier section of the subwoofer.
  • Page 17 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Note! Make a note of the position number of the connector. The position numbers are located on the ends of the connector and in the bottom of the fuse holder.
  • Page 18 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Remove the fibre cable (1) from the connector (2). First carefully pry up the locking tab (3) and at the same time pull off the fibre optic cable.
  • Page 19 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Finishing work Reinstall the fibre optic cables and secure the two loose connectors at the existing cable harness. Use tape or tie straps from the kit.
  • Page 20 Installation instructions, accessories - Subwoofer Installation instructions, accessories - Subwoofer Volvo Car Corporation Göteborg, Sweden Volvo Car Corporation Göteborg, Sweden Note! Check that the seat belt is securely positioned by jerking the belt upwards. (Applies to cars up to and including model year -2004 (CH -133999)) Re-position the seats Reinstall the folding panel.
