INSTALLATION AND OPERATION MANUAL
7000
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION REQUIREMENTS IN YOUR AREA.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET FUEL-
BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN
PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3
INSTALLATION BY A PROFESSIONAL IS STRONGLY RECOMMENDED
This manual is available for free download on the manufacturer's web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may update this manual from time to
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources
Printed in Canada
www.osburn-mfg.com
Stove Builder International Inc.
Tel: (418) 878-3040
READ AND KEEP THIS MANUAL FOR REFERENCE
Safety tested according to ULC S627,
UL1482 and ASTM E1509 by Intertek
Testing Services.
Fax: (418) 878-3001
.
45723A
12-06-2014
