6 Button Interface

The button control panel and the LCD are designed to be the normal user
interface. The LCD is used to display each of the menu items, the current
operating state, the progress of the current command, and to acknowledge the
command status information. The button panel consists of the following three
buttons:
Button Function
Yellow Menu
Green Enter
Red Cancel
The button command menu is organized into a series of levels and parameter
values. When displayed, the command information is displayed on the top line of
the LCD and the parameter information on the next line. The level information is
separated from the command information using a colon (e.g., [1:System Test]
refers to level 1, and a command of "System Test"). Each of the parameters
associated with a particular command (e.g., Wipe Enabled, Wipe Disabled) are
displayed under the command once it has been selected. The prompting
hierarchy used to organize the set of supported commands follows:
Level Prompt
1 System Test
2 Clone Drive
SHA Disabled
SHA Re-Verify
Wipe Enabled
Wipe Disabled
3 Verify Drives
4 Wipe Drives
5 Remove HPA
6 Remove DCO
Whenever commands are entered from the button control panel, all status
information must be acknowledged by the operator. A special arrow character
Description
This button is designed to step through each of the
menu or parameter items. It always steps in a
forward direction.
This button is designed to either select a menu or
parameter item, or acknowledge status information.
This button is designed to either abort the entering of
a new command or the execution of the previous
command.
Description
Perform a system test.
Perform a clone drive operation.
Disables the verification of each target drive
after the clone operation has finished (default).
Enables the verification of each target drive after
the clone operation has finished.
Enables wiping the unused area of a target drive
(default).
Disables wiping the unused area of a target
drive.
Verify all drives contain the same data.
Perform a wipe drive operation.
Remove HPA from target drives.
Remove DCO from target drives.
11
