INTERACTIVE TOY CONCEPTS Wi-Fli Instruction Manual page 2

FLYING YOUR WI-FLI HELICOPTER:
WARNING:
Check the condition of all the rotor blades prior to each flight. Do not try to operate the Wi-Fli Helicopter if any rotor
blade has been damaged. Broken or damaged rotor blades may have sharp edges or corners and they will be
spinning fast with a potential for injury! Flying the Wi-Fli Helicopter with broken rotor blades can also make the
helicopter fly in an unstable or uncontrollable manner. This may cause damage to the Wi-Fli Helicopter, furniture and
other property, as well as injury to plants, animals and people. Broken rotor blades can be easily replaced as
described in the "REPLACING DAMAGED ROTOR BLADES" section below.
Once the steps outlined in the section, "SYNCING THE WI-FLI HELICOPTER WITH YOUR WI-FI CONTROL DEVICE" have
been executed correctly, follow the next steps to fly your Wi-Fli Helicopter.
1. Select either the Control Pad Mode or the Accelerometer Control Mode by pressing the appropriate Control Mode Toggle
Button on the Wi-Fi Control Device Screen.
2. Position the Wi-Fli Helicopter on a secure flat, level launching surface.
3. Slide the Throttle Slider on the Wi-Fi Control Device upwards to start spinning the Wi-Fli Helicopter's Propellers. As you
slide the Throttle Slider higher, the Wi-Fli Helicopter will lift off from the ground. Slide the Throttle Slider until the Wi-Fli
Helicopter reaches your desired flight altitude.
4. Adjust unwanted spinning or turning of the Wi-Fli Helicopter with the Trim Control on the Wi-Fi Control Device. This should
be done until the Wi-Fli Helicopter stops unwanted spinning in the air. This adjustment will be needed every time you fly your
Wi-Fli Helicopter after charging. The trim setting will vary as the helicopter battery drains. Re-adjust trim during flight as
required.
5. A) If you are in Control Pad Mode, use the Control Pad on the Wi-Fi Control Device to turn the Wi-Fli Helicopter during
flight. Also use this Control Pad to make the Wi-Fli Helicopter fly forward or in reverse.
5. B) If you are in Accelerometer Control Mode, tilt the Wi-Fi Control Device to turn the Wi-Fli Helicopter during flight. Also tilt
the Wi-Fli Control Device to make the Wi-Fli Helicopter fly forward or in reverse. It will take a little practice to get used to this
method of flight control.
6. Congratulations! You are flying your Wi-Fli Helicopter. Enjoy!
7. To land your Wi-Fli Helicopter, gently and gradually move the Throttle Slider all the way down. This will slow the rotation of
the Main Rotors and the Wi-Fli Helicopter will land. It is very important to NOT slide the Throttle Slider all the way down
suddenly, as the Main Rotors will stop spinning instantly and the Wi-Fli Helicopter will fall and possibly sustain damage.
8 - A. To fly again, it may or may not be necessary to recharge your Wi-Fli Helicopter, depending on the charge that is
remaining in the Wi-Fli Helicopter's internal Lithium-Polymer battery. Simply follow the steps described in the "CHARGING
YOUR WI-FLI HELICOPTER" section above, to recharge your Wi-Fli Helicopter.
8 - B. If you are finished playing, land your Wi-Fli Helicopter. Slide the Wi-Fli Helicopter's On / Off Switch to the Off position to
turn it off. Then turn off the Wi-Fli Control App on your Wi-Fi Control Device in the manner that is recommended by the third
part manufacturer of your specific Wi-Fi Control Device.
FLYING TIPS!
Altitude Control - the Throttle Slider is a digital proportional system, therefore fine movement of the Throttle Slider will
produce minor changes in the Wi-Fli Helicopter's altitude.
Take time to practice controlling the altitude and getting accustomed to the throttle sensitivity.
Trimming - Once flying at the desired height the Wi-Fli Helicopter may be spinning under the Rotors instead of holding a
heading. Adjust the Trim Control so that the Wi-Fli Helicopter body does not spin. If the Wi-Fli Helicopter is spinning to the left
(counter clockwise) when it shouldn't, press the "+" button. If the Wi-Fli Helicopter is spinning to the right (clockwise) when it
shouldn't, press the "-" button.
Many factors affect the Trim of the Wi-Fli Helicopter such as Internal Battery Condition, Throttle Slider setting and damage
to the rotors. It may be required to adjust the trim control more than once during a flight. Once trimmed, minor corrections can
be managed using the Turning Control in conjunction with the Trim Control.
The Wi-Fli Helicopter should never be flown with damaged rotor blades. Flying the Wi-Fli Helicopter with damaged rotor
blades is very dangerous. See "TROUBLESHOOTING" and "REPLACING DAMAGED ROTOR BLADES" sections for more
information.
Forward Flight - In Control Pad Mode, the best forward flight motion is achieved by gently moving your thumb up on the
Control Pad. In Accelerometer Control Mode, the best forward flight motion is achieved by gently tilting your Wi-Fi Control
Device's top end downwards. Either of these approaches will produce the smoothest transition from hover to moving forward
flight. Sharp or abrupt movements can cause the Wi-Fli Helicopter to "porpoise" or swing, but might be required to overcome a
slight wind or draft.
Direction Control - Direction Control convention is based as if you were sitting in the pilot's seat of the Wi-Fli Helicopter.
Control Reversal - When the Wi-Fli Helicopter is flying towards you, the steering will appear to reverse. This is normal and
just takes some practice to control.
REPLACING DAMAGED ROTOR BLADES
In the event that your main Rotor Blades or tail rotor sustain damage, they are very easy to replace by following these easy
steps. (Note, replacement main rotor blades not included)
Main Rotor Blades:
1. Locate the broken Rotor Blade and use a fine Philips screw-driver (not included) to unscrew the tiny screw that holds the
Rotor Blade in place on the Hub Mount. Be careful not to lose the screw as it is tiny.
2. Pull the damaged Rotor Blade horizontally out and away from its location on the Hub Mount.
3. Install a new Rotor Blade in the same location on the Hub Mount by sliding it in horizontally. The holes for the screw have
to align. It is very important that the correct Rotor Blade is installed as the Upper and Lower Main Rotor Blades may appear
to be similar but are in fact very different. The Wi-Fli Helicopter will not be able to fly if the incorrect Rotor Blades are installed.
4. Fasten the new Rotor Blade to its Hun Mount with the same tiny screw that was pulled out earlier. Do not over tighten the
screw as the Rotor Blade needs to be able to spin freely inside its Hub Mount. Your Wi-Fli Helicopter is ready to fly again!
Tail Rotor:
1. Locate the broken Tail Rotor on the end of the Wi-Fli Helicopter's boom.
2. Remove the broken Tail Rotor by gently pulling it upwards off of the Tail Motor's Axle Shaft.
3. Install the replacement Tail Rotor by sliding it onto the Tail Motor's Axle Shaft in the reverse process as outlined in step 2.
4. Gently press down on the replacement Tail Rotor until it is firmly in place.
REPLACING THE BALANCE-BAR-TO-UPPER-ROTOR CONNECTOR:
There is a small Connector which connects the Upper Rotor to the Balance Bar. In
the event that this Connector becomes disconnected, broken, or lost, a replacement
connector is included with your Wi-Fli Helicopter. Replacement is easy with the
following steps.
1. The Connector is attached by 2 simple ball joints. Remove the broken Connector
by pulling it away from the Axle of the Main Rotors. Once removed, the 2 ball joints
will be exposed.
2. Install the new connector following the reverse of step 1. Gently but firmly press
the connector into position, connecting the upper rotor and the balance bar. The
connector will just snap into the 2 ball joints as shown.
STORING YOUR WI-FLI HELICOPTER:
It is a good idea to store the Wi-Fli Helicopter, USB Charge Cable and this Instruction Manual together so no components
become misplaced or lost. Please respect the below points to extend the operational life of your Wi-Fli Helicopter during
storage.
1. Product may be damaged or performance may be adversely affected if your Wi-Fli Helicopter is not properly stored.
2. Never place any items on top of any components of the Wi-Fli Helicopter.
3. Always keep your Wi-Fli Helicopter in a cool dry place. Do not allow your Wi-Fli Helicopter to get wet as it is not water
resistant.
4. Keep the Wi-Fli Helicopter away from pets and other household animals.
5. Do not rest your Wi-Fli Helicopter on any potential heat source such as electronic equipment or a radiator.
TROUBLESHOOTING
ISSUE:
CAUSE: CORRECTIVE ACTION:
Wi-Fli Helicopter will not 1. Wi-Fli Helicopter not turned on. 1. Turn Wi-Fli Helicopter on and sync it with your Wi-Fi
Control Device.
start, Wi-Fli Helicopter's 2. Battery is not charged.
2. Charge Internal Wi-Fli Helicopter Battery.
Dual Color LED is off. 3. Wi-Fli Helicopter was not set to off
3. Ensure Wi-Fli Helicopter is off and charge Internal Wi-Fli
during charging.
Helicopter Battery.
4. Rotors locked for overload
4. Slide Wi-Fli Helicopter's On / Off Switch to Off, then switch
protection.
it On again and Sync it with your Wi-Fi Control Device.
TROUBLESHOOTING -Continued
ISSUE:
CAUSE: CORRECTIVE ACTION:
Wi-Fli Helicopter will not 1. Wi-Fli Helicopter is not properly 1. Sync your Wi-Fli Helicopter properly with your Wi-Fi
start, Wi-Fli Helicopter's synced with your Wi-Fi Control Device. Control Device.
Dual Color LED is On and
lit up Red.
Wi-Fli Helicopter will not 1. Wi-Fli Helicopter's battery is low. 1. Ensure Wi-Fli Helicopter is off and charge Internal
start, Wi-Fli Helicopter's
Wi-Fli Helicopter Battery.
Dual Color LED is blinking
Red.
Wi-Fli Helicopter is flying 1. You need to reduce the Throttle 1. Slide the Throttle Slider gradually down.
too high. Input.
Wi-Fli Helicopter is flying 1. Needs more power (Throttle Input). 1. Slide the Throttle Slider gradually up.
too low. 2. The battery in the Wi-Fli Helicopter 2. Ensure the Wi-Fli Helicopter is off and charge the
is low. Internal Wi-Fli Helicopter Battery.
Wi-Fli Helicopter doesn't 1. The Wi-Fli Helicopter drifts 1. Adjust the Forward / Reverse control depending on
hover. forwards/backwards. which Control Mode you are employing as described in
the "GETTING TO KNOW THE WI-FLI CONTROL APP
INTERFACE" section of this manual.
Wi-Fli Helicopter doesn't 1. The Wi-Fli Helicopter only flies 1. Aerodynamics make flying backwards more difficult
fly backwards. backwards briefly then spins to fly than flying forwards and this flight pattern is normal.
forward. Practice flying backward and control the left / right
turning motion of the Wi-Fli Helicopter to keep the tail
pointed in the direction you desire.
Wi-Fli Helicopter doesn't 1. The Internal Battery charge is 1. Turn the Wi-Fli Helicopter off and charge the Internal
move forward fast enough. getting low. Wi-Fli Helicopter Battery.
2. The Tail Rotor is damaged. 2. Replace the Tail Rotor with a new one included with
3. The Wi-Fli Helicopter center of your Wi-Fli Helicopter, or from the Replacement Rotor
gravity is no longer correct. Kit (available in stores)
3. Use light adhesive tape to mount a clip on the front
bottom of the Wi-Fli Helicopter to add weight and adjust
the center of gravity. See also "Wi-Fli Helicopter doesn't
hover" issue.
Wi-Fli Helicopter always 1. Trim Control is not set correctly. 1. Adjust the Trim Control on the Wi-Fi Control Device.
turns. 2. The Main Rotor Blades have 2. Replace the damaged Rotor Blades! It is dangerous
sustained damage / or wear from use. to fly with damaged Rotor Blades!
The Main Rotor Blades spin 1. The Balance-Bar-to-Upper-Rotor 1. Install a new Connector (Included in this package)
erratically causing Connector is either broken or missing. using the instructions in the "REPLACING THE
unpredictable flight BALANCE-BAR-TO-UPPER-ROTOR CONNECTOR"
characteristics. section.
IMPORTANT SAFETY INFORMATION
Keep the Wi-Fli Helicopter away from face, eyes and hair at all times. Keep fingers away from moving Rotors or Propellers. Do not
fly the Wi-Fli Helicopter near or at other people or animals. Use caution when flying. Make sure people around you know that you
are playing with the Wi-Fli Helicopter. The WI-Fli Helicopter is recommended for use outdoors. When flying outdoors avoid
operating your Wi-Fli Helicopter near power-lines, trees, or roof-tops. Do not fly your Wi-Fli Helicopter during windy conditions, rain
or any other form of precipitation or harsh weather. Also make sure that your Wi-Fli Helicopter does not have the opportunity to land
in a wet or hazardous area such as snow, water, mud, or dangerous rocks. The USB Charge Cable provided in this package is for
charging the Wi-Fli Helicopter ONLY. Do not use any other source to charge the Wi-Fli Helicopter. Do not attempt to overcharge
your Wi-Fli Helicopter. Follow the charging instructions provided in this Instruction Manual.
PLEASE! DO NOT RETURN THIS PLEASE! DO NOT RETURN THIS
PRODUCT TO ANY RETAIL STORE!
PRODUCT TO ANY RETAIL STORE!
For any questions or problems with this product please contact us at:
Email: info@interactivetoy.com
Phone: Inside North America: +1-416-444-6873 Outside North America: 1-866-214-2220
Address: Interactive Toy Concepts, 17 Vulcan Street, Toronto, Ontario, Canada. M9W 1L3
Web site:www.interactivetoy.com
FCC NOTE: U.S. ONLY
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment. The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the equipment. Note: This equipment has
been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These Limits are
designed to provide reasonable protection against harmful interference in a residential installation. This generates, uses and can radiate
radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turn the equipment off and on, the user is encouraged to
try and correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna • Increase the
separation between the equipment and receiver • Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected • Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Notice: Canada only.
This radiocommunication device complies with all the requirements and limits of Industry Canada Standard RSS-310.
Operation is subject to the following two conditions: 1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation. Field Strength
and measurement distance: 27.145MHz – 61.35 dBµV/m at 3 meter. 49.860MHz - 59.69 dBµV/m at 3 meter.
Limited 30-day warranty
Product is warranted by Interactive Toy Concepts Limited against manufacturing
defects in material and workmanship under normal use for thirty (30) days from
the date of purchase.
Warranty is validated upon receipt of proof or purchase and
confirmation of UPC code.
iPhone, iPod touch, iPad, Apple, and App Store are trademarks of Apple Inc.
registered in the U.S. and other countries. IOS is a trademark or
Proof of Purchase
registered trademark of Cisco in the U.S. and other
Lithium Polymer Rechargeable
countries and is used under license. Android is a Trademark of Google Inc.
Batteries must be recycled or
Wi-Fi is a trademark of the Wi-Fi Alliance. disposed of properly.
Interactive Toy Concepts © 2011 All Rights Reserved.
Manufactured by and distributed by Interactive Toy Concepts Ltd.
Conforms to Safety Standards ASTM F963-03 Regulatory Requirements.
Products and colors may vary. MADE IN CHINA.
INS-50600-110607-US
LOOK FOR THESE OTHER
GREAT PRODUCTS FROM
INTERACTIVE TOY CONCEPTS
