INTERACTIVE TOY CONCEPTS Squeeler Instruction Manual

STORING YOUR SQUEELER:
If you will be storing your Squeeler for a longer period of time, remove the 9-Volt Battery from the controller and
the 9.6V NIMH Rechargeable Battery Pack from the Squeeler. This will prolong the operational life of the Batter-
ies. It is a good idea to store the Squeeler, Controller, Charger, Battery Pack, Tire Inflation Needle, this Instruction
Manual and Tire Inflation Gauge Template together so no components become misplaced or lost. Please respect
the below points to extend the operational life of your Squeeler during storage.
1. Product may be damaged or performance may be adversely affected if your Squeeler is not properly stored.
2. Never place any items on top of any components of the Squeeler.
3. Always keep your Squeeler in a cool dry place.
4. Keep Squeeler away from pets and other household animals.
5. Do not rest your Squeeler on any potential heat source such as electronic equipment or a radiator.
6. Store the 9.6V NIMH Rechargeable Battery Pack in a safe location out of the reach of children and at room
temperature. Do not store any batteries inside the Squeeler or Controller for longer periods of time.
7. It is a good idea to deflate the Squeeler's tires during storage. This is easily accomplished by gently inserting
the Tire Inflation Needle into each tire (without an air pump) and allowing the pressurized air to drain out of each
tire.
8. Do not allow your Squeeler to get wet or come in contact with water or any other liquids. The Squeeler
is NOT water resistant.
TROUBLESHOOTING
ISSUE:
CAUSE:
Squeeler will not start. 1. Squeeler is not turned on. 1. Turn the Squeeler on by sliding the On / Off Switch
2. Battery Pack is not charged. to the On position.
3. The Controller is not turned on. 2. Charge the battery pack as described in this
4. The Squeeler has gotten wet or manual.
has been in water. 3. Turn the Controller on by sliding the On / Off Switch
to the On position.
4. Allow your Squeeler to completely dry out before
attempting to use it again. Ensure that the Battery
Pack has not sustained water damage. It is very likely
that the Squeeler has been permanently damaged by
getting wet. If this is the case, such damage is not
covered under warranty.
The Body of the Squeeler 1. The Tires are underinflated or not 1. Inflate the Tires properly as described in this manual.
is getting scratched or inflated evenly
damaged.
When the Squeeler is 1. This is a normal phenomenon 1. There is no need to correct this as this is a normal
driving towards you, the called "Control Reversal". phenomenon. If this causes difficulties in controlling the
controls appear to reverse. Squeeler, the only solution is more practice.
PLEASE! DO NOT RETURN THIS PLEASE! DO NOT RETURN THIS
PRODUCT TO ANY RETAIL STORE! PRODUCT TO ANY RETAIL STORE!
For any questions or problems with this product please contact us at:
Email: info@interactivetoy.com
Phone: Inside North America: +1-416-444-6873
Outside North America: 1-866-214-2220
Address: Interactive Toy Concepts,
17 Vulcan Street, Toronto, Ontario, Canada. M9W 1L3
Web site: www.interactivetoy.com
Keep the Squeeler away from face, eyes and hair at all times. Keep fingers away from spinning Tires and
the spinning Body of the Squeeler. Do not drive the Squeeler near or at other people or animals. Use
caution when operating the Squeeler. Make sure people around you know that you are playing with the
Squeeler. Recommended for use outdoors and indoors. When playing outdoors avoid operating your
Squeeler near roads, trees, or other hazardous areas. Do not play with your Squeeler during, rain or any
other form of precipitation or harsh weather. Also make sure that your Squeeler is not operated in a wet
area such as snow, water, or mud. When operating the Squeeler indoors, only play in rooms without
obstacles, or breakable objects. The Charger provided in this package is for charging the 9.6V NIMH
Rechargeable Battery Pack ONLY. Do not use any other source to charge the Battery Pack. Do not
attempt to overcharge your Battery Pack as this may damage it. Follow the charging instructions provided
in this instruction manual.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received including interference that may cause undesired
operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment. The manufacturer is not responsible
CORRECTIVE ACTION: for any radio or TV interference caused by unauthorized modifications to this equipment. Such
modifications could void the user's authority to operate the equipment. Note: This equipment has been
tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC
Rules. These Limits are designed to provide reasonable protection against harmful interference in a
residential installation. This generates, uses and can radiate radio frequency energy and if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turn the
equipment off and on, the user is encouraged to try and correct the interference by one or more of the
following measures: •Reorient or relocate the receiving antenna • Increase the separation between the
equipment and receiver • Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected • Consult the dealer or an experienced radio/TV technician for help.
This radiocommunication device complies with all the requirements and limits of Industry Canada Standard RSS-310.
Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device
must accept any interference received, including interference that may cause undesired operation.
Field Strength and measurement distance: 27.145MHz – 55.49 dBµV/m at 3 meter.
Only use the Charger provided with the Interactive Toy Concepts Squeeler, Do not use any other source to charge the
rechargeable Battery Pack. Never leave the Charger unattended in the presence of children. The Charger must be
periodically examined by an adult or a parent for conditions that may result in the risk of fire, electric shock, or injury to
persons. In the event that such conditions should arise, the Charger should not be used until properly repaired.
Limited 30-day warranty
Product is warranted by Interactive Toy Concepts Limited against
manufacturing defects in material and workmanship under normal use
for (30) days from the date of purchase.
Warranty is validated upon receipt of proof or purchase
and confirmation of UPC code.
IMPORTANT SAFETY INFORMATION
FCC NOTE: U.S. ONLY
Industry Canada Notice: Canada only.
Proof of Purchase
Squeeler is a trademark of Interactive Toy Concepts Ltd. © 2011 All Rights Reserved.
Manufactured by and distributed by Interactive Toy Concepts Ltd.
Conforms to Safety Standards ASTM F963-03 Regulatory Requirements.
Products and colors may vary. MADE IN CHINA.
INS-44072-110609-US
TM
Congratulations on the purchase of your Squeeler
off-road stunt RC vehicle! The Squeeler is a radical new
ground vehicle that will conquer just about every terrain! With
inflatable tires, the Squeeler bounces, jumps and flips like nothing else
out there! To make the stunts even more spectacular, the Squeeler also
twists its body along its lateral axis. Available in radio-control frequency 27
MHz, the Squeeler comes in 2 different bands: A and B. The Squeeler also
has a radical RC controller which twists to control the twisting action of the
vehicle! The operational range of the Squeeler is 80' (24 M) from the controller.
The Squeeler can travel at actual speeds of up to 9.3 MPH (15 KM/H). That is a scale
speed of up to 168 MPH (270 KM/H)!!! Do not throw away this instruction manual as it
contains valuable information for the operation of your Squeeler as well as warranty information. The
helpful tips in this user's manual will improve your skill and enhance your experience.
Look for these TIP! symbols for extra help.
INSTRUCTION MANUAL INSTRUCTION MANUAL
UNPACKING YOUR SQUEELER:
WARNING:The Squeeler is a rugged machine. However, improper operation of this toy can still result in
damage. Before removing the Squeeler from the packaging please read the instructions!
To prevent damage during shipping, the Squeeler is securely fastened in the package. Please ensure that all of
the fastening locations are unfastened before attempting to remove the Squeeler from the package. Be very
careful when removing the Squeeler to prevent damaging the vehicle and its components.
COMPLETE PACKAGE CONTENTS AND COMPONENT BREAKDOWN:
Body Twist Section
Left Stick
- Controls Forward /
Rear Spoiler
Reverse speed on
left side wheels of
Squeeler (also adds
minimal thrust on
Main body
right side wheels)
Power On LED
On / Off Switch
Inflatable Tires
Radio Controller & Antenna
Tire Inflation Point
Squeeler Off-road Stunt RC Vehicle
8+
Item# 44072
Antenna
Right Stick
- Controls Forward /
Reverse speed on
9.6V NI-MH
right side wheels of Rechargeable
Battery Pack
Squeeler (also adds
minimal thrust on
left side wheels) Charger
with Cable
Twist Control
- Controls twisting
of Squeeler
Tire Inflation
Needle
Tire Inflation Gauge Template
