INTERACTIVE TOY CONCEPTS BladeRunner Storm-Wolf Instruction Manual

REPLACING DAMAGED ROTOR BLADES -Continued:
Main Rotor Blades:
1. Locate the broken Rotor Blade and use a fine Philips screw-driver (not included) to unscrew the tiny screw that
holds the Rotor Blade in place on the Hub Mount. Be careful not to lose the screw as it is tiny.
2. Pull the damaged Rotor Blade horizontally out and away from its location on the Hub Mount.
3. Install a new Rotor Blade in the same location on the Hub Mount by sliding it in horizontally. The holes for the
screw have to align. It is very important that the correct Rotor Blade is installed as the Upper and Lower Main
Rotor Blades may appear to be similar but are in fact very different. The Storm-Wolf Helicopter will not be able to
fly if the incorrect Rotor Blades are installed.
4. Fasten the new Rotor Blade to its Hub Mount with the same tiny screw that was pulled out earlier. Do not over
tighten the screw as the Rotor Blade needs to be able to spin freely inside its Hub Mount. Your Storm-Wolf
Helicopter is ready to fly again!
Tail Rotor:
1. Locate the broken Tail Rotor on the end of the Storm-Wolf Helicopter's boom.
2. Remove the broken Tail Rotor by gently pulling it upwards off of the Tail Motor's Axle Shaft.
3. Install the replacement Tail Rotor (Included with the Storm-Wolf) by sliding it onto the Tail Motor's Axle Shaft in
the reverse process as outlined in step 2.
4. Gently press down on the replacement Tail Rotor until it is firmly in place.
REPLACING THE BALANCE-BAR-TO-UPPER-ROTOR CONNECTOR:
There is a small Connector which connects the Upper Rotor to the Balance Bar. In the event that this Connector
becomes disconnected, broken, or lost, it will need to be reconnected or replaced. A replacement Balance-Bar-
To-Upper-Rotor Connector is not included with the Storm-Wolf Helicopter. A replacement connector can be
purchased separately as part of the Storm-Wolf Replacement Parts Kit. Replacement is easy with the following
steps.
1. The Connector is attached by 2 simple ball joints. Remove the broken Connector by disconnecting it from the
Upper Rotor Hub Mount and the Balance Bar and pull it away. Once removed, the ball joints will be exposed. A
ball joint will be visible on both sides of the Upper Rotor Hub Mount, and a ball joint will be visible on both sides of
the Balance Bar. There will be a total of 4 ball joints visible!
2. Install the new connector following the reverse of step 1. The connector only needs to connect 2 of the 4 ball
joints. The Connector must connect a set of ball joints that are in vertical alignment only. Gently but firmly press
the Connector into position, connecting the Upper Rotor and the Balance Bar. The Connector will just snap into
the 2 ball joints as shown.
STORING THE STORM-WOLF HELICOPTER:
It is a good idea to store the Storm-Wolf Helicopter, IR Controller and this Instruction Manual together so no
components become misplaced or lost. Please respect the below points to extend the operational life of your
Storm-Wolf Helicopter during storage.
1. Product may be damaged or performance may be adversely affected if the Storm-Wolf Helicopter is not prop-
erly stored.
2. Never place any items on top of any components of the Storm-Wolf Helicopter.
3. Always keep your Storm-Wolf Helicopter in a cool dry place. Do not allow your Storm Wolf Helicopter to get
wet as it is not water resistant.
4. Keep the Storm-Wolf Helicopter away from pets and other household animals.
5. Do not rest your Storm-Wolf Helicopter on any potential heat source such as electronic equipment or a radiator.
TROUBLESHOOTING
ISSUE:
CAUSE:
CORRECTIVE ACTION:
Storm-Wolf Helicopter will 1. Storm-Wolf Helicopter is not 1. Turn Storm-Wolf Helicopter on.
not start, LED on turned on. 2. Charge Internal Storm-Wolf Helicopter Battery.
Storm-Wolf Helicopter is 2. Battery is not charged. 3. Ensure Storm-Wolf Helicopter is off and charge
off. 3. Storm-Wolf Helicopter was not set Internal Storm-Wolf Helicopter Battery.
to off during charging. 4. Slide Storm-Wolf Helicopter's On / Off Switch to Off,
4. Rotors locked for overload then switch it On again.
protection.
Storm-Wolf Helicopter will 1. Storm-Wolf Helicopter's infrared 1. Push Left Stick (Throttle) completely UP, then back
not start, LED on link is not established with the IR DOWN to initialize infrared link and throttle control.
Storm-Wolf Helicopter is Controller. 2. Turn on IR Controller.
ON. 2. IR Controller is not turned on. 3. Ensure Storm-Wolf Helicopter is off and charge
3. Storm-Wolf Helicopter's battery is Internal Storm-Wolf Helicopter Battery.
low.
Storm-Wolf Helicopter will 1. Motor stall protection is activated. 1. Reset the Storm-Wolf Helicopter by turning its power
not start, LED on 2. Storm-Wolf Helicopter's Internal off and on.
Storm-Wolf Helicopter is Battery power is low. 2. Ensure the Storm-Wolf Helicopter is Off and
flashing. recharge the Internal Battery.
Storm-Wolf Helicopter is 1. You need to reduce the Throttle 1. Push the Left Stick (Throttle) gradually down.
flying too high Input.
Storm-Wolf Helicopter is 1. Needs more power (Throttle Input). 1. Push the Left Stick (Throttle) gradually up.
flying too low. 2. The battery in the Storm-Wolf 2. Ensure the Storm-Wolf Helicopter is off and charge
Helicopter is low. the Internal Storm-Wolf Helicopter Battery.
Storm-Wolf Helicopter 1. The Storm-Wolf Helicopter drifts 1. Push the right stick up or down to compensate and
doesn't hover. forwards/backwards. hold the Storm-Wolf Helicopter in position.
Helicopter doesn't fly 1. The Storm-Wolf Helicopter is not 1) If desired, add a small amount of weight to the
forward fast enough. designed for fast flight as it is an bottom front area of the body by taping a paper clip or
indoor toy. something similar in weight and size onto it. However,
note that this will reduce the ability of the Storm-Wolf
Helicopter to fly backwards.
Storm-Wolf Helicopter 1. The Storm-Wolf Helicopter only 1. Aerodynamics make flying backwards more difficult
doesn't fly backwards flies backwards briefly then spins to fly than flying forwards and this flight pattern is normal.
forward. Practice flying backward and control the left / right
turning motion of the Storm-Wolf Helicopter to keep the
tail pointed in the direction you desire.
Storm-Wolf Helicopter is 1. Needs more power (Throttle Input). 1. Push the Left Stick (Throttle) gradually up.
flying too low. 2. The battery in the Storm-Wolf 2. Ensure the Storm-Wolf Helicopter is off and charge
Helicopter is low. the Internal Storm-Wolf Helicopter Battery.
Storm-Wolf Helicopter 1. The Internal Battery charge is 1. Turn the Storm-Wolf Helicopter off and charge the
doesn't move forward fast getting low. Internal Storm-Wolf Helicopter Battery.
enough. 2. The Tail Rotor is damaged. 2. Replace the Tail Rotor with a new one included with
3. The Storm-Wolf Helicopter center your Storm-Wolf Helicopter, or from the Storm-Wolf
of gravity is no longer correct. Replacement Part Kit (available in stores)
3. Use light adhesive tape to mount a clip on the front
bottom of the Storm-Wolf Helicopter to add weight and
adjust the center of gravity. See also "Storm-Wolf
Helicopter doesn't hover" issue.
TROUBLESHOOTING -Continued
ISSUE:
CAUSE: CORRECTIVE ACTION:
Storm-Wolf Helicopter 1. Trim Control is not set correctly. 1. Adjust the Trim Control Knob on the IR Controller.
always turns. 2. The Main Rotor Blades have 2. Replace the damaged Rotor Blades! It is danger-
sustained damage / or wear from use. ous to fly with damaged Rotor Blades! Replacement
Rotor Blades are not included, but can be purchased
separately as part of the Storm-Wolf Replacement Part
Kit.
The Main Rotor Blades 1. The Balance-Bar-to-Upper-Rotor 1. Install a new Connector using the instructions in the
spin erratically causing Connector is either broken or missing. "REPLACING THE BALANCE-BAR-TO-UPPER-
unpredictable flight ROTOR CONNECTOR" section. Replacement Connec-
characteristics. tors are not included, but can be purchased separately
as part of the Storm-Wolf Replacement Part Kit.
IMPORTANT SAFETY INFORMATION
Keep the Storm-Wolf Helicopter away from face, eyes and hair at all times. Keep fingers away from moving
rotors or propellers. Do not fly the Storm-Wolf Helicopter near or at other people or animals. Use caution when
flying, make sure people around you know that you are playing with the Storm-Wolf Helicopter. Recommended
for use indoors only in rooms without obstacles, breakable objects or fans. The IR Controller's built-in Charger
provided in this package is for charging the Storm-Wolf Helicopter ONLY. Do not use any other source to charge
the Storm-Wolf Helicopter. Do not attempt to overcharge your Storm-Wolf Helicopter. Follow the charging
instructions provided in this Instruction Manual. Do not attempt to replace the Internal Lithium Polymer Recharge-
able Battery inside the Storm-Wolf Helicopter! The Storm-Wolf Helicopter's Lithium Polymer Rechargeable
Internal Battery is sealed inside the unit and is not replaceable. Any attempts to repalce the Storm-Wolf Helicop-
ter's Lithium Polymer Rechargeable Internal Battery will void the warranty.
PLEASE! DO NOT RETURN THIS PLEASE! DO NOT RETURN THIS
PRODUCT TO ANY RETAIL STORE! PRODUCT TO ANY RETAIL STORE!
For any questions or problems with this product please contact us at:
Email: info@interactivetoy.com
Phone: Inside North America: +1-416-444-6873
Outside North America: 1-866-214-2220
Address: Interactive Toy Concepts,
17 Vulcan Street, Toronto, Ontario, Canada. M9W 1L3
Web site: www.interactivetoy.com
Limited 30-day warranty
Product is warranted by Interactive Toy Concepts Limited against
Proof of Purchase
manufacturing defects in material and workmanship under normal use
for (30) days from the date of purchase.
Warranty is validated upon receipt of proof or purchase
and confirmation of UPC code.
BladeRunner is a registered trademark of Interactive Toy Concepts Ltd. © 2011 All Rights Reserved.
Storm-Wolf is a trademark of Interactive Toy Concepts Ltd. © 2011.
Manufactured by and distributed by Interactive Toy Concepts Ltd. Conforms to Safety Standards ASTM F963-03 Regulatory Requirements.
Products and colors may vary. MADE IN CHINA.
INS-55078-110614-US
TM
TM
Congratulations on the purchase of your BladeRunner
Storm-Wolf Helicopter. The Storm-Wolf brings advanced,
3-Channel, hobby-level flying technology to flyers who are
looking for great performance from an indoor Helicopter. The Storm-Wolf
has built-in advanced gyroscope technology for providing an ultra-smooth flight
and balance control assistance. In addition, the Storm-Wolf Helicopter has digital
proportional control. The Storm-Wolf is available in Infrared Control Channels A and
B. The compact and stylish design of the IR Controller has an integrated charging mechanism
so that only 6 AA Batteries in total are required to charge and operate the Storm-Wolf Helicopter.
Do not throw away this instruction manual as it contains valuable information for the operation of
your Storm-Wolf Helicopter as well as warranty information. The helpful tips in this Instruction
Manual will improve your skill and enhance your experience. Look for these symbols for
extra help.
INSTRUCTION MANUAL INSTRUCTION MANUAL
UNPACKING YOUR BLADERUNNER STORMWOLF HELICOPTER:
WARNING: The Storm-Wolf is a delicate machine, before removing it from the packaging please read the
instructions! To prevent damage during shipping, the Storm-Wolf is securely fastened in the package.
Please ensure that all of the tie-down and fastening locations are unfastened before attempting to remove
the Storm-Wolf Helicopter from the package. Be very careful when removing the Storm-Wolf to prevent
damaging the Helicopter.
COMPLETE PACKAGE CONTENTS AND COMPONENT BREAKDOWN:
1. BladeRunner Storm-Wolf Helicopter
2. IR Controller Balance bar
3. Instruction Manual
4. 1 Replacement Tail Rotor
IR Control Emitter Window
Left Stick
- Up / Down - Throttle
Trim Control Knob
Right Stick
- Left / Right Steering
Direction Control
Charge
LED
On / Off Switch
(other side)
Charging Port
Power Button LED Light
and Power LED
Charge Cable
Landing Gear
Compartment Door
8+
Item# 44072
Top Rotor
Bottom Rotor
Tail Rotor
Tail Boom
Tail Motor
