Home Theater PC Chassis
DISCLAIMER
No warranty or representation, either expressed or implied, is made with respect to the content of this documentation, its quality, performance, merchantability,
or fitness for a particular purpose. Information presented in this documentation has been carefully checked for reliability; however, no responsibility is
assumed for inaccuracies. The information contained in this documentation is subject to change without notice.
In no event will nMedia will be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or
documentation, even if advised of the possibility of such damages.
COPYRIGHT
© 2006 by NMEDIA SYSTEM, INC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language in any form by any means without the written permission of NMEDIA SYSTEM, INC.
TECHNICAL SUPPORT
If a problem arises with your system and no solution can be obtained from this user guide, please contact your place of purchase or local dealer.
REVISION HISTORY
V 2.0
October, 2006
Note:
This user guide is designed to provide the user a quick reference for chassis setup. We assume you need
the information regarding how to assemble the system, such as Motherboard, CPU, RAM Memory, Hard
Drive, DVD ROM, Operating System..., etc. Based on this assumption, we make this user guide of quick
installation guide. Please follow the description step by step to assemble the components. If you have any
question in assembling the system, you can contact your dealer or our technical support.
Model: HTPC 100 BA & SA
Color: Black & Silver
Quick Installation Guide
(U.S. & Canada Only)
Version 1.0
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for nMedia HTPC 100 SA
Summary of Contents for nMedia HTPC 100 SA
-
Page 1: Quick Installation Guide
The information contained in this documentation is subject to change without notice. In no event will nMedia will be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. -
Page 2: Safety Warning
Safety Warning Turn down the CPU Cooler Fan Speed through the Front Controller may create vital damage to CPU. Adjust Fan Controller (CPU F.R.S.) appropriately according to the CPU instruction. (Minimum Fan Speed at 2000 is recommended) “RESET” button is for LCD Module only (CPU Fan Speed is default to minimum speed of 1800 to prevent CPU damage) Overview Standard Components Equipped... -
Page 3: Installation Flowchart (Basic Procedures)
For upgrades: Sound Card Video Graphic Card (Fanless model is recommended) TV Tuner Card (MCE certified is recommended) Installation Flowchart (Basic Procedures) Open Box Read Installation Guide Remove Top Cover Remove Optical Drive Bracket Take Off Power Supply Install Motherboard Perform a chassis quality check Connect Cables... - Page 4 Step 2: Connect cables Install motherboard Connect front panel / LCD cables a) Connect Front USB 2.0, IEEE 1394 and Audio Connectors b) Connect PWR Switch c) Connect Card Reader internal USB cable d) Connect LCD cables e) See below table for more details (Reference picture only) Front USB 2.0, IEEE 1394 and Audio Connectors See Motherboard User Manual for location and connection.
- Page 5 Connect Card Reader USB cable See Motherboard User Manual for onboard USB port location and connection. And see above referenced picture. Connect LCD Cables (Some of these steps follow after CPU & Cooler installation) 1. Place the case heat sensor anywhere that you want 2.
- Page 6 Step 5: Install memory module Step 6: Install the power supply Install the power supply Connect power cables a) to hard drive b) to motherbaord 20/24 pin main c) to motherborad 4 pin +12V d) to LCD PWR e) to optical drive Step 7: Install the optical drive (Reference picture only)
-
Page 7: Other Component Installation
LCD Module Set Up LCD will display the CPU & Case Temp. reading / CPU Cooler Fan Speed reading Alarm Features CPU Alarm Temperature When CPU temperature hits 65ºC or 149F, the temperature reading will flash constantly until the temperature drops below the alarm degree. CPU Fan Alarm When the fan stops running for whatever reason during working mode, the CPU fan speed reading will flash constantly in “0000”... -
Page 8: Safety Instructions
• Carefully re-packaging is needed to avoid shipping damages • All warranties are subject to properly uses. Any human power damages return may be rejected according to warranty terms and conditions Copyright © 2006 NMEDIA SYSTEM, INC. All Right Reserved.
