nMedia HTPC 3000B Quick Installation Manual

Home theater pc chassis

Advertisement

Quick Links

DISCLAIMER
No warranty or representation, either expressed or implied, is made with respect to the content of this documentation, its quality, performance,
merchantability, or fitness for a particular purpose. Information presented in this documentation has been carefully checked for reliability; however,
no responsibility is assumed for inaccuracies. The information contained in this documentation is subject to change without notice.
In no event will nMedia will be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use this product
or documentation, even if advised of the possibility of such damages.
TRADEMARKS
All trademarks used in this user guide are the property of their respective owners.
COPYRIGHT
© 2004-2008 by NMEDIA SYSTEM, INC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language in any form by any means without the written permission of NMEDIA SYSTEM, INC.
TECHNICAL SUPPORT
If a problem arises with your system and no solution can be obtained from this user guide, please contact your place of purchase or local dealer.
REVISION HISTORY
V 1.0
July, 2008
Note:
This user guide is designed to provide the user a quick reference for chassis setup. We assume you need the information regarding how to assemble
the system, such as Motherboard, CPU, RAM Memory, Hard Drive, DVD ROM, Operating System..., etc. Based on this assumption, we make this user
guide of quick installation guide. Please follow the description step by step to install the components. If you have any question in assembling the system,
please refer your questions to the appropriate Technical Support of the component vendors.
Overview
Standard Components Equipped
HTPC 3000 chassis
Static (Non-programmable) LCD Module
2 x 80mm silent case fan; 1 x 120mm silent HDD fan
Front connectors (onboard connectors required)
USB 2.0 x 3; IEEE 1394 x 1
o
HD or AC97 MIC & HeadPhone x 1
o
eSATA x 1
o
SDHC 2.0 compiance all in one card reader x 1
o
Tight cables, screws, installation guide
Other Suggested Components
Vista Home Premium or Ultimate Operation System
ATX and or Micro ATX Motherboard
ATX Power Supply
CPU / Quiet Cooler
Hard Drive (SATA is recommended)
RAM Memory
Optical Drive (DVD Burner is recommended)
Keyboard with trackball (nMEDIAPC 2.4GHz RF wireless
keyboard is recommended)
Suggested upgrades
Sound Card
Video Graphic Card
TV Tuner Card (MCE certified is recommended)
HOME THEATER PC CHASSIS
Model: HTPC 3000B & 3000S
Color: Black & Silver
Quick Installation Guide
(U.S. & Canada Only)
Version 1.0
