Smart Openers Smart slider Installation Manual

Sliding gate opener
Hide thumbs Also See for Smart slider:
Table of Contents

Advertisement

Quick Links

Smart Slider
Sliding Gate Opener
WARNING: IT IS VITAL FOR THE SAFETY OF ALL
PERSONS INSTALLING AND USING THIS OPENER TO
FOLLOW THE INSTALLATION INSTRUCTIONS AND
SAFETY WARNINGS. FAILURE TO COMPLY MAY RESULT
IN SERIOUS PERSONAL INJURY AND/OR PROPERTY
INSTALLATION MANUAL
DAMAGE AND FAILURE OF THE OPENER SYSTEM.
V2.08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart slider and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smart Openers Smart slider

Summary of Contents for Smart Openers Smart slider

  • Page 1 Smart Slider Sliding Gate Opener WARNING: IT IS VITAL FOR THE SAFETY OF ALL PERSONS INSTALLING AND USING THIS OPENER TO FOLLOW THE INSTALLATION INSTRUCTIONS AND SAFETY WARNINGS. FAILURE TO COMPLY MAY RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY INSTALLATION MANUAL DAMAGE AND FAILURE OF THE OPENER SYSTEM.

  • Page 2: Table Of Contents

    Technical Specifications Warranty To the extent that they may be lawfully excluded, Smart Openers Pty Ltd hereby expressly excludes all conditions and warranties, statutory or otherwise, which may be implied by law as conditions or warranties of purchase of a Smart Openers Pty Ltd Gate Opener. Smart Openers Pty Ltd hereby further disclaims...

  • Page 3: Contents

    Important Safety Warnings Description The Smart Slider gate opener described in this manual The Smart Slider gate opener requires a 240V AC 50Hz is designed for the automation of residential track or power input. The 24V DC motor can provide remote cantilever type sliding gates.

  • Page 4: Operating Controls

    3. MODE Button - Save setting and exit to normal operation mode. 4. MENU Button - Function/Peramater select. Welcome to LEARN 5. SET Button - Save changes and move to next Smart Openers function. Circuit Board Connectors 6. Connector for motor 1. 7. Connector for motor 2. MODE MENU 8.
  • Page 5 Remember the unit has mains voltage running through it 10. When installing the Smart Slider opener, strictly follow (electrocution hazard, fire hazard, etc). all the instructions given in the instruction manual. If some points or procedures in this manual are not very 4.
  • Page 6 4. The gate must be properly balanced and must be RACK easily moved by hand. 5. Install a 240V, adequately protected 3-pin socket near where the Smart Slider opener is going to be installed. PINION Positioning The Opener 1. Measure the width of the rack (Smart Openers rack is 40mm) If using third party rack make sure it is Module 4.

  • Page 7: Electrical Connection

    Electrical Connection Single Leaf Gate Set Up LEARN For single leaf gate the opener is prewired ready for set up. Go to page 8 for set up procedure. Motor Connection for Two Leaf Gate For a two leaf gate a master and slave drive unit is MODE MENU required with connection via a 5-core cable.

  • Page 8: Quick Reference Guide

    Powering Up 1. Inspect the power cable for damage. Ensure that the cable will not interfere with the moving gate or the drive unit. Sliding Gate 2. Connect to power. The opener will perform a software SC Vx.xx check before displaying the firmware version (Fig. 5). 3.
  • Page 9 Fig. 10 stored codes have now been deleted. Transmitter Button Allocation The Smart Slider is factory preset with TX Button 1 operating full access (PB) and Button 2 for Pedestrian Mode (PD). PB PD OP CL Note: The following procedure alters these settings for ALL 04 00 00 coded transmitters.

  • Page 10: Setting Limits

    Setting Limits – Single Leaf Gate Setting Motor Installation 1. Press SET for 3 secs to enter set up. The display will show Right Hand Installation (default). Right Hand If this is correct (when standing inside the driveway Installation looking out) press SET to confirm. Otherwise press MENU to change to Left Hand, then press SET to confirm (Fig.
  • Page 11 Dual Motor Installation 1. Press MENU for 3 secs to enter parameter set up. The display will show Single Motor (default). Press MENU to cycle through to Dual Motor. Press MODE save and exit to main screen. Dual Motor 2. Press SET for 3 secs to enter set up mode. The display will show Motor 1 (the master which has the controller on board) as Right Hand Installation (default).

  • Page 12: Setting Pedestrian Mode

    Setting Pedestrian Mode Pedestrian Mode allows the gate to open partially (or only one leaf) to allow a person to enter without the need to open the gate fully as for vehicular access (Factory Pedestrian Default = Off). Mode On 1.

  • Page 13: Setting Motor Open/Close Speed

    OFF see page 15. Photo Beam Photo Beam Mode allows the gate to close once the beam has been tripped and restored. Smart Openers strongly recommend the installation of a PE safety beam to protect persons and property (Factory Default = Off).

  • Page 14: Setting Auto-Close Mode

    Setting Auto-Close Mode Auto-Close Mode allows the gate to close automatically once the PE safety beam has been tripped and the preset time has elapsed. This function is only available Auto Close with the addition of a functioning photo-electric safety beam (Factory Default = Off).

  • Page 15: Manual Disengagement

    3. Press SET to confirm or MODE to save and exit. Manual Disengagement The Smart Slider opener is equipped with a manual disengagement device to enable you to open and close the gate in case of electrical failure, system malfunction or fire.

  • Page 16: Maintenance

    It is important for the installer to show their clients correct operational use of the Smart Slider including the use of the manual disengagement lever. Inform the owner about the need for regular and accurate maintenance, especially regarding a regular check of the safety and reversing devices.

  • Page 17: Warranty

    13. This warranty is not transferable. 14. Where the Product is retailed by any person other than Smart Openers , except for the warranty set out above, such person has no authority from Smart Openers to given any warranty or guarantee on Smart Openers behalf in addition to the warranty set out above.
  • Page 18 Notes -18-...
  • Page 19 Notes -19-...
  • Page 20 © September 2009 Smart Openers Pty Ltd. All rights reserved. Smart Slider is a registered trademark of Smart Openers Pty Ltd. In an ongoing commitment to ® product quality and innovation Smart Openers reserves the right to change and alter specifications and model numbers and types without notice. D/N: SLIM208170909...
