Stone Hearth Cooking Appliance
Gas-Fired / Wood Optional Residential Models
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Installation and
Operation Manual
mt. ChuCkanut
WS-MH-4-RFG-W
mt. adamS
WS-MH-5-RFG-W
mt. Baker
WS-MH-6-RFG-W
mt. rainier
WS-MH-7-RFG-W
Toll Free (800) 578-6836
Tel (360) 650-1111
Fax (360) 734-0223
www.woodstonehome.com
Revised November 2009
Advertisement
Table of Contents
Related Manuals for Wood Stone Mt. Chuckanut WS-MH-4-RFG-W
Summary of Contents for Wood Stone Mt. Chuckanut WS-MH-4-RFG-W
- Page 1 WS-MH-5-RFG-W Stone Hearth Cooking Appliance mt. Baker Gas-Fired / Wood Optional Residential Models WS-MH-6-RFG-W mt. rainier WS-MH-7-RFG-W Wood Stone Corporation www.woodstonehome.com Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Revised November 2009 Bellingham, WA 98226 USA Fax (360) 734-0223...
-
Page 2: Table Of Contents
INTERLOCK DIAGRAM ------------------------------------------------------------------------------------- FUELWOOD FACTS ----------------------------------------------------------------------------------------- LIMITED WARRANTY --------------------------------------------------------------------------------------- Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... -
Page 3: Mountain Series
MOUNTAIN SERIES mountain SerieS Mountain Series Installation and Operation Manual INSTALLATION ANd OPERATION MANUAL THE WOOd STONE RESIdENTIAL MOUNTAIN SERIES STONE HEARTH COOKING EQUIPMENT WS-MH-(4, 5, 6, 7)-RFG-W, MOdELS GAS-FIREd / WOOd OPTIONAL APPLIANCE AddITIONAL COPIES AvAILABLE UPON REQUEST KEEP THIS MANUAL FOR FUTURE REFERENCE. - Page 4 RETAIN THIS MANUAL FOR FUTURE REFERENCE Additional copies of this manual and prompt responses to service/maintenance questions are available from Wood Stone @ 1-800-578-6836. THIS APPLIANCE IS NOT FOR USE WITH SOLId FUEL. WHAT TO dO IF YOU SMELL GAS •...
-
Page 5: Unloading And Moving
NOT TURN THE APPLIANCE ON ITS SIdE! Contact Wood Stone if the appliance must be turned on its side for specific instructions. Moving a Wood Stone appliance can present interesting challenges to even the most experienced riggers. Take your time, use your head, secure the proper equipment and make safety your first priority. -
Page 6: Installation Clearances
CLEARANCES a. The Wood Stone MH-RFG-W should have a minimum 1'’clearance to combustibles from all sides, and 6" clearance to combustibles from the top (See page 6) If building a facade that will contact the appliance, use completely non- combustible materials*. - Page 7 CLearanCeS Mountain Series Installation and Operation Manual THE FOLLOWING CLEARANCE INFORMATION APPLIES TO ALL WOOd STONE MH SERIES (NON-STUCCO) APPLIANCES Any facade materials above and 6" to either side of the doorway of the appliance, must be NON-COMBUSTIBLE. WARNING: Do not pack required air 6"...
-
Page 8: Facade Details
FACADE DETAILS FaCade detaiLS Mountain Series Installation and Operation Manual FACAdE dETAILS FOR THE WOOd STONE MH SERIES APPLIANCES If using an exhaust hood over the appliance, make sure your facade allows for the proper access for removal of the hood filters! Removable Service panel. -
Page 9: Outdoor Installations
The appliance may be installed in a weatherproof enclosure. If so be sure to maintain all clearances and adhere to the installation requirements included in this manual. Wood Stone also offers the following options to enclose the area beneath the appliance:... -
Page 10: Gas Inlet Pressures
The Wood Stone Gas appliances are equipped with a 3/4" NpT gas connection. Have a licensed gas installer provide the hook-up and test all fittings and pipe connections for leaks. Use approved gas leak detectors (soap solutions or equivalent) over and around the fittings and pipe connections. -
Page 11: Gas Specifications
Factory specified individual burner manifold pressures for models equipped to burn Propane (LP). Model SV-2 WS-MH-4-RFG-W-Lp 7” WS-MH-5-RFG-W-Lp 8” WS-MH-6-RFG-W-Lp 8” WS-MH-7-RFG-W-Lp 9.5” hourly Natural Gas BTU input rates for Wood Stone gas appliances Model hourly BTU Input Rate WS-MH-4-RFG-W-NG 115,000 WS-MH-5-RFG-W-NG 188,000 WS-MH-6-RFG-W-NG 188,000 WS-MH-7-RFG-W-NG 222,000... -
Page 12: Gas Code Limitations
GaS Code LimitationS Mountain Series Installation and Operation Manual Wood Stone recommends that the appliance’s individual shutoff valve (supplied by others) be left readily accessible. Wood Stone also recommends that inspection and maintenance of the burners and gas piping connections of this appliance be performed at regularly scheduled intervals and only by professional gas appliance service agencies. -
Page 13: Electrical Specifications
If this appliance was provided with a cord, the cord is equipped with a 3 prong grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded receptacle. Do not cut or remove the grounding prong from the plug. Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. -
Page 14: Venting
The following are the manufacturer’s recommendations for venting the Wood Stone MH (Mountain Home Series) RFG-W. It is never appropriate to use “B vent” in any part of an exhaust system connected to a Wood Stone appliance. All ducting material must be Listed to UL 103 and manufactured to the specifications of a grease duct. Submit your venting plans to your local authorities before proceeding with your installation, as there may be additional requirements in your area. - Page 15 Note that the notch of the hood is even with the front edge of the appliance. The hood should be installed in accordance with the hood manufacturer's instructions, and with NFPA 96 and/or the applicable local and national codes. vERY IMPORTANT! WOOd STONE RECOMMENdS THAT YOU SUBMIT YOUR vENTING PLANS TO LOCAL COdE AUTHORITIES BEFORE PROCEEdING WITH INSTALLATION. Wood Stone Corporation Toll Free (800) 578-6836 1801 W.
-
Page 16: Assembly
4. The following applies to stucco finish appliances only (Models ending with S): a. Once the appliance has been set in place, cover wire mesh and metal lathing with no less than 1 inch of stucco (see page 19 for diagram). Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. -
Page 17: Mantle Mounting
(provided). Clean up any adhesive and/or silicone before it dries! Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA... -
Page 18: Front Panel Assembly
Be sure to retighten the clamp once the throttle knob is in the desired position. Throttle Valve Cotter Key Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA... -
Page 19: Assembly Diagram
ASSEMBLY DIAGRAM aSSemBLY diaGram Mountain Series Installation and Operation Manual APPLIANCES EQUIPPEd WITH OPTIONAL LOWER ExTENSION Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... -
Page 20: Stucco Application
MINIMUM STUCCO APPLICATION IS 1" This figure depicts the application of stucco on a Wood Stone appliance. Use no less than 1 inch of stucco coating to cover all exposed metal lathing on the appliance. Maintain a minimum of 36 inch clearance from top and sides of appliance to all combustible surfaces. -
Page 21: Initial Startup
2. push ON/OFF button. Using the Throttle Knob pointer, turn the radiant flame to its highest setting. The appliance should stabilize at your desired temperature typically within 1-2 hours. Go to www.woodstone-corp.com for detailed information on cooking in your Wood Stone appliance. CLEANING THE APPLIANCE 1. - Page 22 (IR) thermometer. NOTE: Small "crazing" cracks will occur with normal heating and cooling. They will not effect the performance or durability of the appliance. If cracks of 1/8" or more develop, contact Wood Stone for evaluation. Wood Stone Corporation Toll Free (800) 578-6836 1801 W.
-
Page 23: Appliance Operation
Mountain Series Installation and Operation Manual APPLIANCE OPERATION NOTE: The ceramic materials used in the construction of your Wood Stone oven will absorb moisture if exposed to high humidity or damp conditions during shipment from the factory or extended periods of storage before installation. -
Page 24: Daily Operation
For additional operational and cooking information please visit www.woodstone-corp.com or call Wood Stone. NIGHT dOORS The door(s) are used for nighttime heat retention. Do not operate the appliance with doors in place. -
Page 25: Controller Diagram
ATTENDRE 5 MINUTES AVANT DE RÉALLUMER 1-800-988-8103 www.woodstone-corp.com THIS CONTROL PANEL IS ALSO SUPPLIEd ON CURRENT CONvERSION REAdY APPLIANCES THAT HAvE (-C) IN THE MOdEL NUMBER. Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA... -
Page 26: Flame Height Control
Each flame height corresponds to a saturated floor temperature. Several factors need to be accounted for in order to determine this relationship for each oven. FLAME HEIGHT INdICATOR SCALE FOR WOOd STONE MOUNTAIN SERIES OvENS heat Up Flame- Set Throttle Knob pointer at ‘5’ (highest setting) on the Flame Height Index Scale until desired temperature is reached. -
Page 27: Use Of Wood In The Appliance
Mountain Series Installation and Operation Manual When burning wood in a Wood Stone RFG-W model appliance, the fire should be placed to one side of the chamber, as close to the door opening as is possible (this is often described as the 8 o'clock or 4 o'clock position). Burn a maximum of 15 lbs. -
Page 28: Daily Maintenance
COOKING CHAMBER Wood Stone recommends the use of a long-handled, brass bristled brush for sweeping aside excess food particles that will accumulate on the ceramic floor of the appliance during use. The floor can be cleaned with a damp rag. DO NOT USE ICE OR EXCESSIVE WATER ON ThE FLOOR. -
Page 29: Periodic Thermal Cleaning
Mountain Series Installation and Operation Manual THERMAL CLEANING Wood Stone appliances are typically operated at temperatures which preclude the need for cleaning of the interior walls and ceiling (the dome) of the appliance. If however, you routinely operate the appliance at floor temperatures lower than 450 degrees Fahrenheit (F), you may notice a buildup of soot on the interior walls and/or ceiling of the appliance. -
Page 30: Safety Considerations
The interior floor and dome of the appliance do not require creosote or soot removal. The appliance flue and exhaust system will require inspection and cleaning. The exhaust system should be inspected and cleaned per the manufacturer's and or local code official's recommendations. Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. -
Page 31: Troubleshooting Guide
Contact Wood Stone for assistance. Please contact Wood Stone at 1-800-578-6836 should service be necessary, or if you have any questions about your appliance. Our office hours are 8am to 4:30pm Pacific Standard Time. Follow the recorded instructions for Emergency Service if you require assistance during non-business hours. -
Page 32: Electrical Diagram
ELECTRICAL DIAGRAM eLeCtriCaL diaGram Mountain Series Installation and Operation Manual RESIdENTIAL RFG-IR-W MOdEL 120 vAC Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... -
Page 33: Operational Sequence
Touchpad style controllers dome flame light comes on Burner remains on until appliance control is turned off Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA... -
Page 34: Interlock Diagram
No other connection to the appliance control system is condoned by Wood Stone and may affect the warranty and cause damage to the controls. -
Page 35: Fuelwood Facts
High-Med 3230 Difficult Good Fair *The desirability of various fragrances is largely a matter of personal preference. Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... - Page 36 A full cord of wood measures 4’ x 4’ x 8’ when stacked. Cost per lb = Do not use pressed wood products in Wood Stone food service equipment, they may damage the ceramics. Wood Stone Corporation Toll Free (800) 578-6836 1801 W.
-
Page 37: Limited Warranty
LIMITATIONS OF LIABILITY: In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof. Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser.
