mountain SerieS
Stone Hearth Cooking Appliance
Wood with Gas Assist Residential Models
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Installation and
Operation Manual
mt. ChuCkanut
WS-MH-4-W-IR
mt. adamS
WS-MH-5-W-IR
mt. Baker
WS-MH-6-W-IR
mt. rainier
WS-MH-7-W-IR
Toll Free (800) 578-6836
Tel (360) 650-1111
Fax (360) 734-0223
www.woodstonehome.com
Revised November 2009
Advertisement
Table of Contents
Related Manuals for Wood Stone Mt. Chuckanut WS-MH-4-W-IR
Summary of Contents for Wood Stone Mt. Chuckanut WS-MH-4-W-IR
- Page 1 WS-MH-5-W-IR Stone Hearth Cooking Appliance mt. Baker Wood with Gas Assist Residential Models WS-MH-6-W-IR mt. rainier WS-MH-7-W-IR Wood Stone Corporation www.woodstonehome.com Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Revised November 2009 Bellingham, WA 98226 USA Fax (360) 734-0223...
-
Page 2: Table Of Contents
TROUBLESHOOTING GUIDE--------------------------------------------------------------------- ELECTRICAL DIAGRAM ------------------------------------------------------------------------- OpERATION SEQUENCE ------------------------------------------------------------------------ INTERLOCK DIAGRAM-------------------------------------------------------------------------- FUELWOOD FACTS----------------------------------------------------------------------------- LIMITED WARRANTY --------------------------------------------------------------------------- Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... -
Page 3: Mountain Series
SerieS MOUNTAIN SERIES Mountain Series Installation and Operation Manual INSTALLATION ANd OPERATION MANUAL THE WOOd STONE MOUNTAIN SERIES STONE HEARTH COOKING EQUIPMENT WS-MH-(4, 5, 6, 7)-W-IR MOdELS WOOd / GAS COMBINATION APPLIANCE AddITIONAL COPIES AvAILABLE UPON REQUEST KEEP THIS MANUAL FOR FUTURE REFERENCE. - Page 4 NOT THROW THIS MANUAL AWAY RETAIN THIS MANUAL FOR FUTURE REFERENCE Additional copies of this manual and prompt responses to service/maintenance questions are available from Wood Stone @ 1-800-578-6836. WHAT TO dO IF YOU SMELL GAS • Do not try to light any appliance.
-
Page 5: Unloading And Moving
NOT TURN THE APPLIANCE ON ITS SIdE! Contact Wood Stone if the appliance must be turned on its side for specific instructions. Moving a Wood Stone appliance can present interesting challenges to even the most experienced riggers. Take your time, use your head, secure the proper equipment and make safety your first priority. -
Page 6: Installation Clearances
CLEARANCES a. The Wood Stone MH-W-IR should have a minimum 1'’clearance to combustibles from all sides, and 6" clearance to combustibles from the top (See page 6) If building a facade that will contact the appliance, use completely non- combustible materials*. - Page 7 CLearanCeS Mountain Series Installation and Operation Manual THE FOLLOWING CLEARANCE INFORMATION APPLIES TO ALL WOOd STONE MH SERIES (NON-STUCCO) APPLIANCES Any facade materials above and 6" to either side of the doorway of the appliance, must be NON-COMBUSTIBLE. WARNING: Do not pack required air 6"...
-
Page 8: Facade Details
FaCade detaiLS FACADE DETAILS Mountain Series Installation and Operation Manual FACAdE dETAILS FOR THE WOOd STONE MH SERIES APPLIANCES If using an exhaust hood over the appliance, make sure your facade allows for the proper access for removal of the hood filters! Removable Service panel. -
Page 9: Outdoor Installations
The appliance may be installed in a weatherproof enclosure. If so be sure to maintain all clearances and adhere to the installation requirements included in this manual. Wood Stone also offers the following options to enclose the area beneath the appliance:... -
Page 10: Gas Inlet Pressures
The Wood Stone Gas appliances are equipped with a 3/4" NpT gas connection. Have a licensed gas installer provide the hook-up and test all fittings and pipe connections for leaks. Use approved gas leak detectors (soap solutions or equivalent) over and around the fittings and pipe connections. -
Page 11: Gas Specifications
Factory specified individual burner manifold pressures for models equipped to burn Propane (LP). Model SV-1 WS-MH-4-W-IR-Lp 9” WS-MH-5-W-IR-Lp 9” WS-MH-6-W-IR-Lp 9” WS-MH-7-W-IR-Lp 9.2” Natural Gas BTU input rates for Wood Stone wood/gas appliances. Model hourly BTU Input Rate WS-MS-4-W-IR-NG 47,000 WS-MS-5-W-IR-NG 83,000 WS-MS-6-W-IR-NG 83,000 WS-MS-7-W-IR-NG 97,000 Propane BTU input rates for Wood Stone wood/gas appliances. -
Page 12: Gas Code Limitations
GaS Code LimitationS Mountain Series Installation and Operation Manual Wood Stone recommends that the appliance’s individual shutoff valve (supplied by others) be left readily accessible. Wood Stone also recommends that inspection and maintenance of the burners and gas piping connections of this appliance be performed at regularly scheduled intervals and only by professional gas appliance service agencies. -
Page 13: Electrical Specifications
If this appliance was provided with a cord, the cord is equipped with a 3 prong grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded receptacle. Do not cut or remove the grounding prong from the plug. Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. -
Page 14: Venting The Appliance
The following are the manufacturer’s recommendations for venting the Wood Stone MH (Mountain Home Series) W-IR. It is never appropriate to use “B vent” in any part of an exhaust system connected to a Wood Stone appliance. All ducting material must be Listed to UL 103 and manufactured to the specifications of a grease duct. Submit your venting plans to your local authorities before proceeding with your installation, as there may be additional requirements in your area. - Page 15 NFPA 96 and/or the applicable local and national codes. vERY IMPORTANT! WOOd STONE RECOMMENdS THAT YOU SUBMIT YOUR vENTING PLANS TO LOCAL COdE AUTHORITIES BEFORE PROCEEdING WITH INSTALLATION. Wood Stone Corporation Toll Free (800) 578-6836 1801 W.
-
Page 16: Assembly
4. The following applies to stucco finish appliances only (Models ending with S): a. Once the appliance has been set in place, cover wire mesh and metal lathing with no less than 1 inch of stucco (see page 19 for diagram). Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. -
Page 17: Mantle Mounting
(provided). Clean up any adhesive and/or silicone before it dries! Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA... -
Page 18: Front Panel Assembly
Be sure to retighten the clamp once the throttle knob is in the desired position. Throttle Valve Cotter Key Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA... -
Page 19: Optional Lower Extension
LoWer eXtenSion OPTIONAL LOWER EXTENSION Mountain Series Installation and Operation Manual APPLIANCES EQUIPPEd WITH OPTIONAL LOWER ExTENSION Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... -
Page 20: Stucco Application
MINIMUM STUCCO APPLICATION IS 1" This figure depicts the application of stucco on a Wood Stone appliance. Use no less than 1 inch of stucco coating to cover all exposed metal lathing on the appliance. Maintain a minimum of 36 inch clearance from top and sides of appliance to all combustible surfaces. -
Page 21: Initial Startup
Never use any type of flammable liquid or fuel to start a fire in a Wood Stone appliance. Doing so could cause a dangerous situation and/or damage to the appliance ceramic. - Page 22 • Small "crazing" cracks will occur with normal heating and cooling. They will not effect the performance or durability of the appliance. If cracks of 1/8" or more develop, contact Wood Stone for evaluation. dAILY OPERATION IMPORTANT: If at any time you feel that the underfloor burner is not operating properly, TURN OFF GAS SUPPLY AT ThE INDIVIDUAL ShUTOFF VALVE and call for service.
-
Page 23: Daily Operation
Use only seasoned hardwoods with a moisture content of 20% or less. Use of soft woods, such as pine, cedar, hemlock etc., and wet or 'green' wood, will cause a build-up of residue throughout the exhaust system. (See Wood Stone's Fuel Wood Facts, or consult factory for information on what types of wood can be used for oven fuel.) - Page 24 (IR) thermometer. NOTE: Small "crazing" cracks will occur with normal heating and cooling. They will not effect the performance or durability of the appliance. If cracks of 1/8" or more develop, contact Wood Stone for evaluation. AdJUSTING THE HEARTH SET-POINT To adjust the thermostatic hearth temperature setting, simply press the arrow button corresponding to the direction in which you would like the setting to go.
-
Page 25: Controller Diagram
WAIT 5 MINUTES BEFORE RELIGHTING ATTENDRE 5 MINUTES AVANT DE RÉALLUMER 1-800-988-8103 www.woodstone-corp.com W-IR APPLIANCE CONTROLLER Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... -
Page 26: Daily Maintenance
If a Wood Stone appliance is operated at low temperatures (below 400 degrees F), it is possible that grease from food could condense on the walls and ceiling of the appliance. Adjust the Hearth Set point to the maximum setting- 700 degrees F. -
Page 27: Safety Considerations
The interior floor and dome of the appliance do not require creosote or soot removal. The appliance flue and exhaust system will require inspection and cleaning. The exhaust system should be inspected and cleaned per the manufacturer's and or local code official's recommendations. Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. -
Page 28: Troubleshooting Guide
Contact Wood Stone for assistance. Please contact Wood Stone at 1-800-988-8103 should service be necessary, or if you have any questions about your appliance. Our office hours are 8am to 4:30pm Pacific Standard Time. Follow the recorded instructions for Emergency Service if you require assistance during non-business hours. -
Page 29: Electrical Diagram
ELECTRICAL DIAGRAM Mountain Series Installation and Operation Manual RESIdENTIAL W-IR MOdEL 120 vAC Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... -
Page 30: Operation Sequence
Floor reaches set point, controller turns off power to SV1 to turn off burner. Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... -
Page 31: Interlock Diagram
No other connection to the appliance control system is condoned by Wood Stone and may affect the appliance warranty and cause damage to the appliance controls. -
Page 32: Fuelwood Facts
High-Med 3230 Difficult Good Fair *The desirability of various fragrances is largely a matter of personal preference. Wood Stone Corporation Toll Free (800) 578-6836 1801 W. Bakerview Rd. Tel (360) 650-1111 Bellingham, WA 98226 USA Fax (360) 734-0223 An ongoing program of product improvement may require us to change Info@woodstonehome.com or visit www.woodstonehome.com... - Page 33 A full cord of wood measures 4’ x 4’ x 8’ when stacked. Cost per lb = Do not use pressed wood products in Wood Stone food service equipment, they may damage the ceramics. Wood Stone Corporation Toll Free (800) 578-6836 1801 W.
-
Page 34: Limited Warranty
LIMITATIONS OF LIABILITY: In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof. Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser.
