Installation and
Operation Manual
GAS PLANCHA
Speciality Equipment
Countertop Model
and Optional Stand Models
4-ZONE GAS PLANCHA WS-GPL-4836-4-CT
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
www.woodstone-corp.com
Toll Free 800.988.8103
Tel 360.650.1111
Fax 360.650.1166
DOC NO M0202.00
REVISED January 2017
Advertisement
Table of Contents
Related Manuals for Wood Stone WS-GPL-4836-4-CT
Summary of Contents for Wood Stone WS-GPL-4836-4-CT
- Page 1 Installation and Operation Manual GAS PLANCHA Speciality Equipment Countertop Model and Optional Stand Models 4-ZONE GAS PLANCHA WS-GPL-4836-4-CT WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com DOC NO M0202.00...
-
Page 2: Table Of Contents
GPL-4836-4 WIRE DIAGRAMS � � � � � � � � � � � � � � � � � � � � �13 LIMITED WARRANTY � � � � � � � � � � � � � � � � � � � � � � � � � � � �19 Wood Stone Corporation Toll Free 800.988.8103 1801 W. -
Page 3: Plancha
WS-PL-4836 4-CT WS-PL-4836 4-CT Shown with optional stand Wood Stone’s Gas Plancha has been tested and approved by Intertek, and is ETL listed to ANSI Z83.11:2016, CSA 1.8b:2016 Ed. 4 and to NSF/ANSI Standard 4 - 2009e. ANSI Z83.11:2016 Ed.4 ANSI /NSF STD 4 CSA 1.8:2016 Ed.4... -
Page 4: Cautions And Warnings
CAUTIONS AND WARNINGS Gas Plancha Installation and Operation Manual WOOD STONE GAS PLANCHA INSTALLATION AND OPERATION INSTRUCTIONS RETAIN THIS MANUAL FOR FUTURE REFERENCE Additional copies of this manual and prompt responses to service/maintenance questions are available from Wood Stone @ 1-800-988-8103�... -
Page 5: Gpl-4836-4 Specs - Countertop Model
Electrical Venting Gas: 3/4 inch FNPT gas inlet The Wood Stone Gas Plancha must be vented with a Listed 120 VAC, �7 A, 50/60 Hz 110,000 BTU/hr Natural Gas (NG) Type 1 exhaust hood, or one constructed in accordance with... -
Page 6: Gpl-4836-4 Specs - Optional Stand Model
UTILITIES SPECIFICATIONS Electrical Venting Gas: 3/4 inch FNPT gas inlet The Wood Stone Gas Plancha must be vented with a Listed 120 VAC, �7 A, 50/60 Hz 110,000 BTU/hr Natural Gas (NG) Equipped with a NEMA 5-15P plug Type 1 exhaust hood, or one constructed in accordance with for use with a standard 120 VAC NFPA 96 and all relevant local and national codes�... -
Page 7: Clearances
Gas Plancha Installation and Operation Manual CLEARANCES 1. The Wood Stone Gas Plancha must have a minimum 12 inch clearance to combustible construction from sides and back, and 0 inch clearance to non-combustible construction from sides and back. 2. This appliance may be installed on a combustible or non-combustible surface�... -
Page 8: Utility Information
1/2 psi (14 inches W�C�), no external regulator is required or recommended� If incoming gas pressure is greater than 1/2 psi, an external regulator, by others, must be installed� If you must convert the Plancha to run on a different gas type, i�e� NG to LP, please contact Wood Stone to obtain the necessary parts and instructions�... -
Page 9: Basic Operation
PL-4836-4-CT 4 Heat Indicator Lights Red RESET light ON/OFF switch Grease/debris trays Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 10: Daily Use & Maintenance
4. The front, sides, and back may be wiped down with a cloth and mild detergent if needed� Do not use abrasive cleaners or scouring pads as these will scratch the stainless steel� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. -
Page 11: Troubleshooting
4. Temperature reading at each point should be within the range 490-540 °F� Please contact Wood Stone at 1-800-988-8103 should service be necessary, or if you have any questions about your Plancha. Our service hours are 8 am to 5 pm Pacific Time. Follow the recorded instructions for Emergency Service if you require assistance during non-business hours. -
Page 12: Operational Sequence
ON or OFF� Power OFF� All Gas Valves close� All Burners and Controller OFF� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 13: Gpl-4836-4 Wire Diagrams
GPL-4836-4 WIRE DIAGRAMS Gas Plancha Installation and Operation Manual IGNITION MODULE INTERCONNECT HARNESS - W6 GY/BN GY/BU GY/YE GY/OG M0202.00 January 2017... - Page 14 GPL-4836-4 WIRE DIAGRAMS Gas Plancha Installation and Operation Manual IGNITION AND POWER DISTRIBUTION GY/OG GY/YE GY/BU GY/BN WH/RD WH/RD GY/BN GY/BU GY/YE GY/OG M0202.00 January 2017...
- Page 15 GPL-4836-4 WIRE DIAGRAMS Gas Plancha Installation and Operation Manual INDICATORS AND POTENTIOMETERS M0202.00 January 2017...
- Page 16 GPL-4836-4 WIRE DIAGRAMS Gas Plancha Installation and Operation Manual THERMOCOUPLE CONNECTIONS GY/OG GY/YE GY/BU GY/BN WH/RD WH/RD GY/BN GY/BU GY/YE GY/OG M0202.00 January 2017...
-
Page 19: Limited Warranty
In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�... - Page 20 WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com An ongoing program of product improvement may require us to change specifications without notice.
