Specifications - K-array Piccolo User Manual

13. Specifications

Frequency range
Maximum SPL
Type
Power to mid-high
Power to subwoofer
Dynamic limiter, over current, over temp, short circuits
Protection
Mid-high (each) 4 x 0.5" Neodymium cone driver with 0.5" voice coil
1 x 6" Neodymium magnet with double 1.5" voice coil
Subwoofer
Operating range
I nominal
Peak power
Max power conumption
Dimensions
Weight
rev.C
Piccolo
Acoustics
32 HZ - 18 KHz
92 dB
Amplifiers
2 x class D – DSP controlled
50 W x 2 (100 W total)
110 W
Transducers
1 x 6" passive radiator
AC Power
85 - 132 Vac 50 Hz (Auto-switching)
170 - 264 Vac 60 Hz (Auto-switching)
2 A / 115 Vac - 1 A / 230 Vac
2 x 220 W / 120 ms max
150 W
Physical
9.2 x 2.1 x 1.6 cm (mid-high)
13 x 22.5 x 20.2 cm (subwoofer)
20.5 x 22.5 x 20.2 cm (amplifier)
57 g (mid-high)
4.6 Kg (subwoofer)
3.3 Kg (amplifier)
Piccolo
19
