- Page 1 Fixed Mount CCD Barcode Scanner - User Manual...
- Page 2 Fixed Mount CCD Barcode Scanner - User Manual Introduction This CCD Bar Code scanner module is well designed with high quality components. The improved digitizer provides very accurate barcode scanning signal to decoders. With different scanning ranges, It’s ideal to meet the application requirement.
-
Page 3: Electrical Characteristics
Fixed Mount CCD Barcode Scanner - User Manual Electrical Characteristics Supply Voltage DC +5V +5% Output Voltage (Typ.) Output Voltage (Min.) 4.5V Logic High Space/Bar (Optional) Logic Low Bar/Space (Optional) Power Consumption Stand by (Max.) 40mA Operation (Max.) 140mA Power Enable Control... -
Page 4: Physical Characteristics
Fixed Mount CCD Barcode Scanner - User Manual Physical Characteristics Weight: 33g Material: PC + Fiber Dimension: Unit:mm P a g e... -
Page 5: Pin Assignment
Fixed Mount CCD Barcode Scanner - User Manual Environment Operating Temperature 0°C to 45°C Storage Temperature -20°C to 60°C Relative Humidity 20% to 85% (Mon-condensing) Shock 1 meter drop on Concrete Surface Performance Scan Rate 100 scans / sec (signal directional) Width of Field 47.5 mm + 0.59... -
Page 6: Decode Zone
Fixed Mount CCD Barcode Scanner - User Manual Decode Zone Test Conditions: Code 39, PCS 0.9 P a g e... - Page 7 Fixed Mount CCD Barcode Scanner - User Manual More Information - Decoded symbologies; Code 39, Code 32, Interleaved 2 of 5, Industrial 2 of 5, IATA , Matrix 2 of 5, China postage, Code 128, Code 11, Code 93, MSI-PLESSY, Codebar/NW7, Code 4, EAN-13/JAN-13, UPC-A, EAN-8/JAN-8,...
