- Page 1 HAMMERHEAD 12.0 Volt Lithium Ion Auto-Hammer CHARGE BATTERY BEFORE FIRST USE 241-0306 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator's Manual. Save These Instructions For Future Reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols For Your Tool...................Page 3 Rules For Safe Operation....................Page 4 Description.........................Page 8 Assembly...........................Page 9 Operation...........................Page 9 Maintenance........................Page 13 Warranty..........................Page 15 INTRODUCTION SAVE THESE INSTRUCTIONS! This auto hammer has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate. -
Page 3: Safety Symbols For Your Tool
SAFETY SYMBOLS FOR YOUR TOOL The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures. -
Page 4: Rules For Safe Operation
RULES FOR SAFE OPERATION GENRAL SAFETY RULES If operating a power tool in a damp location is unavoidable, use a WARNING: Read all safety ground fault circuit interrupter (GFCI) warnings and instructions. Failure to protected supply. Use of a GFCI follow the warnings and instructions reduces the risk of electric shock. - Page 5 4) Power tool use and care When the battery pack is not in use, keep it away from other metal objects, Do not force the power tool. Use the such as paper clips, coins, keys, nails, correct power tool for your application. screws or other small metal objects The correct power tool will do the job that can make a connection from one...
- Page 6 Use clamps or another practical way Do not charge a battery-operated tool to support and secure the workpiece in a damp or wet location. Following this to a stable platform. Holding the work rule will reduce the risk of electric shock. by hand or against your body leaves it For best results, your battery-operated unstable, and may lead to loss of control.
- Page 7 Use of an attachment not recommended Do not operate the charger if it has or sold by the battery-charger received a sharp blow, been dropped, manufacturer may result in a risk of fire, or has otherwise been damaged electric shock or injury to persons. in any way.
-
Page 8: Description
DESCRIPTION WARNING: KNOW YOUR AUTO HAMMER The safe use of (Fig.1) this product requires an understanding of the information included on the tool and in this operator’s manual, as well Before attempting to use this auto hammer, as knowledge of the project you are familiarize yourself with all of its operating attempting. -
Page 9: Assembly
HAMMER HEAD The sleeve retracts at the end of nail driving to allow the hammer head to drive the nail head flush to the workpiece. The hammer head impacts the nails automatically when the tool is turned on and LED WORKLIGHT the head is pressed against a nail head. - Page 10 Remove the battery pack from the tool when FIG. 2 convenient for you and your job. “Top off” the battery pack charge by charging it for a time before starting a big job or long period of use. Due to Lithium-Ion fade-free properties, the only time it is necessary to charge the Lithium-Ion battery pack is when the pack has reached the end of its charge.
- Page 11 CHARGING A HOT BATTERY PACK TO ATTACH BATTERY PACK (Fig. 4) FIG. 4 If the battery pack is above the normal temperature range, the red LED will illuminate and the green LED will be off. When the battery pack cools down to approximately 104°F (40°C), the charger will automatically begin charging.
- Page 12 TRIGGER SWITCH (Fig. 5) ELECTRIC BRAKE To stop the hammer head, release the trigger FIG. 5 switch and allow the hammer head to come to a complete stop. The electric brake quickly stops the hammering action. This feature engages automatically when you release the trigger switch.
-
Page 13: Maintenance
Recommended Nailing Materials for the Recommended Nails to Use Auto Hammer The Auto Hammer is versatile for use with a The Auto Hammer can be used for driving variety of nails. Nails with a diameter of less nails into all types of woods, wood-like than 7/16”(11mm) and a length equal to or materials, and plaster board. -
Page 14: Troubleshooting
BATTERIES: WARNING: Upon removal of the battery pack for disposal or recycling, The battery pack is equipped with Lithium- cover the battery pack’s terminals Ion rechargeable batteries. The duration of with heavy-duty adhesive tape. Do not use from each charge will depend on the attempt to destroy or disassemble battery type of work performed. -
Page 15: Warranty
This MASTERFORCE brand power tool carries our famous No Hassle 3-Year Limited ® Warranty to the original purchaser. If, during normal use, this MASTERFORCE power ® tool breaks or fails due to a defect in material or workmanship within three (3) years from... - Page 16 © 2011 Menard, Inc., Eau Claire, WI 54703 06/2011...
