80V 1-MAN/2-MAN
BRUSHLESS AUGER
POWERHEAD
270-1935/270-1936
2900594ME/2900794ME
EAB401
OPERATOR'S MANUAL
CAUTION
To Reduce The Risk Of Injury, User Must Read
And Understand Operator's Manual. Save These Instructions For
Future Reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 270-1935 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MasterForce 270-1935

  • Page 1 80V 1-MAN/2-MAN BRUSHLESS AUGER POWERHEAD 270-1935/270-1936 2900594ME/2900794ME EAB401 OPERATOR’S MANUAL CAUTION To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Symbols ......................Page 2 Safety Instructions ...................... Page 3 Overview ........................Page 7 Specifications ......................Page 7 Assembly ........................Page 8 Operation ........................Page 10 Maintenance / Troubleshooting ................. Page 11 Exploded Views ......................Page 12 Notes ........................
  • Page 3: Safety Symbols

    SAFETY SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. Symbol Name Designation / Explanation Volts Voltage Amperes...
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS The purpose of safety symbols is to attract our attention to possible dangers. The safety symbols, and the explanations with them, deserve your careful attention and understanding. The symbol warnings do not by themselves eliminate any danger. The instructions and warnings they give are no substitutes for propper accident prevention measures.
  • Page 5 SAFETY INSTRUCTIONS GENERAL POWER TOOL SAFETY he power tool. Keep cord away from heat, oil, sharp edges or moving parts. WARNINGS Damaged or entangled cords increase the risk of electric shock. „ When operating a power tool outdoors, READ ALL INSTRUCTIONS BEFORE use an extension cord suitable for USING (THIS POWER TOOL) outdoor use.Use of a cord suitable for...
  • Page 6 SAFETY INSTRUCTIONS „ If devices provided be performed. Use of the power tool for connection of dust extraction and operations different from those intended collection facilities, ensure these are could result in a hazardous situation. connected and properly used. Use of „...
  • Page 7 SAFETY INSTRUCTIONS SERVICE • Stay alert, and turn the machine off if a child or any other person enters the working area. „ Have your power tool serviced by a • Use extreme care when approaching qualified repair person using only blind corners, doorways, shrubs, trees, identical replacement parts.
  • Page 8: Overview

    OVERVIEW Battery Release Button Safety Lock-Out Switch Powerhead Ring Pin Forward/Reverse Switch Trigger Bit (sold separately) SPECIFICATIONS Type Cordless, battery operated SPECIFICATIONS Motor Weight (Without Battery) 18.63 lbs (8.45 kg) Forward: 210 min -1 /Reverse: 50 min -1 No-load Speed BAB726,BAB727,BAB728,BAB729 and Battery Model other BAB series...
  • Page 9: Assembly

    ASSEMBLY UNPACKING • Open the ring pin. • Insert the ring pin through the holes. • Close and lock the ring pin to secure the bit to the auger shaft. • Carefully remove the product and any accessories from the box. Make sure that FIG.
  • Page 10 ASSEMBLY THE BATTERY PACK WARNING F o l l o w t h e s e instructions in order to avoid injury and to reduce the risk of electric shock or fire: • Replace the battery pack or the charger immediately if the battery case or charger cord is damaged.
  • Page 11: Operation

    OPERATION STARTING / STOPING THE MACHINE DRILLING A HOLE Before drilling a hole, always look to see what To start position the forward/reverse switch is in. 1. Press the safety lock-out switch. • Push the forward/reverse switch to "F" for 2.
  • Page 12: Maintenance / Troubleshooting

    MAINTENANCE CLEAN THE MACHINE CAUTION • Clear the unwanted material out of the air Do not let brake vent with a vacuum cleaner. fluids, gasoline, petroleum-based materials • Do not spray the air vent or put the air vent touch the plastic parts. Chemicals can in solvents.
  • Page 13: Exploded Views

    EXPLOPDED VIEW Part No. Description R0202466-00 Ring Pin Page 12...
  • Page 14: Notes

    NOTES Page 13...
  • Page 15: Warranty

    WARRANTY 4-YEAR LIMITED WARRANTY This MASTERFORCE™ brand power tool carries our famous No Hassle 4-Year Limited Warranty to the original purchaser. If, during normal use, this MASTERFORCE™ power tool breaks or fails due to a defect in material or workmanship within four (4) years from the date of original purchase, simply bring the tool with the original sales receipt back to your nearest MENARDS ®...
  • Page 16 © 2020 Menard, Inc., Eau Claire, WI 54703 12/2020 Page 15...
