The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of un-insulated "dangerous
voltage" within the product's enclosure that may be of sufficient magnitude to
constitute a risk of electric to persons.
CAUTION
To reduce the risk of electric shock, do not remove the cover (or back). No
1.
user-serviceable parts inside. Refer servicing to qualified service personnel. Unplug
the product from the wall outlet before servicing or when it is unused for a long
period of time.
The manufacturer should not hold responsibility for the damage caused by any
2.
substitutions and modifications of the product without authorization from the
manufacturer or authorized unit.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
3.
equivalent type.
WARNING
The apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the apparatus.
Important Safety
Instructions
Advertisement
Table of Contents
Related Manuals for Prestigio GeoVision 3120
Summary of Contents for Prestigio GeoVision 3120
-
Page 1: Important Safety Instructions
Important Safety Instructions The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage”... - Page 2 Accessories Prestigio GeoVision 3120/4120/5120 – Accessories List ITEM NAME Car Charger Mounting Cradle USB Cable Touch Pen Leather Carrying Case (GeoVision 5120 Only) Driver/Documentation CD User Manual Warranty Card EN - 1...
-
Page 3: Front And Side View
View of Main Unit Front and Side View LCD Touch Screen Tap the screen with touch pen or finger to select menu commands or to enter information. Battery Status Indicator The indicator glows in bright amber color when battery is fully charged and in red color when charging. -
Page 4: View Of Main Unit
View of Main Unit Rear and Top View Speaker Emits sound, voice or music. Power Button Press to power ON/OFF device. -
Page 5: Device Connections
Device Connections NOTE: Please always make sure that the device and any other external device connected to the device are powered off and unplugged from the power supply before attempting to connect the device to any external device. Inserting microSD Card ... -
Page 6: Connecting To Earphones
Device Connections Connecting to Earphones Flip open the protective rubber cover towards the front of the device. Insert earphone jack (earphones not included) into the appropriate earphone port to switch audio output from device speaker to earphone. NOTE: Excessively loud volume is potentially detrimental to hearing. -
Page 7: Cautions On Battery Charging
Cautions on Battery Charging About Rechargeable Battery The device is equipped with a built-in rechargeable battery. Please fully charge the battery (for at least 8 hours) before initial use. The battery status indicator glows in red color when charging and turns bright amber color when charging is complete. Charging time is approximately 2 hours. -
Page 8: Using Mounting Cradle
Using Mounting Cradle NOTE: Do not operate the device while driving. Please select an appropriate location on the dashboard or windshield where the device will not obstruct driver field of vision. Device Mounting Procedures The device can be securely mounted on vehicle dashboard or windshield with the mounting cradle included. -
Page 9: Getting Started
Getting Started 1. Press and hold Power Button to turn on device. 2. Shortly after the greeting screen is shown, the main menu will be displayed. 3. Tap the corresponding buttons with touch pen included to navigate various functions. 4. Press and hold Power Button to turn off the device or to allow device to enter sleep mode. - Page 10 Initialization and Software Activation 1. Tap and language option to select system language. 2. Tap to confirm selection 3. Carefully read through Software and Database End User License Agreement. Tap to agree with the terms of use. 4. The configuration wizard will be displayed in the selected language.
- Page 11 Navigation Introduction Tap on Navigation icon to start navigation software. The options are displayed as below: Tap Destination icon to start navigation function by entering an address or selecting a Place Of Interest (POI), a location on the map, or one of Favorite destinations. Recent destinations can also be displayed from the Smart History.
-
Page 12: Destination Menu
Navigation Destination Menu In the navigation menu, tap on Destination icon to start navigation function. Enter an address as routing destination. Select a POI as routing destination. Select a location on the map to navigate to. Select a routing destination from favorite list. Navigate to the latest destination as displayed. -
Page 13: Navigating To An Address
Navigation Navigating to An Address 1. In the navigation menu, tap Destination icon and then Find Address icon. 2. Current country/state/town (location attributes) is set as default location. 3. Tap Select Street to continue or Back to return. 4. Tap location attributes desired to change its values. 5. - Page 14 Navigation Navigating to a Place Of Interest (POI) In the navigation menu, tap Destination icon and then Find Places icon. Displays a list of petrol stations along the route, around current position, or last known location Displays a list of restaurants along the route, around current position, or last known location.
-
Page 15: Map Screen
Map Screen The Map screen displays a virtual view of current position and various other information such as Vehimarker represent current position, orange line showing the recommended route, buttons and data fields assisting navigating function. Information of current location is displayed at the top of the screen when destination is not selected. -
Page 16: More Menu
More Menu prestigio.naviextras.com In the navigation menu, tap More… icon to enter menu. The options are shown as below: Tap any of the preinstalled games to start in Demo mode. Obtain an activation key to play in full version Download additional games from www.naviextras.com Tap any of the travel applications to start program. - Page 17 Settings In the navigation menu, tap and then to configure device settings. to display other settings options. Select vehicle type, road types used in route planning, and route calculation methods. Adjust sound volume, mute device, or enable warning messages. Replace current Vehimarker (position arrow) with images.
-
Page 18: Troubleshooting
Troubleshooting Take steps described in the tables below to solve simple problems before contacting customer service. NOTE: Immediately turn off the device and disconnect the power adapter if the device is not working properly. Never try to repair the unit without authorized professionals for it may damage the unit. - Page 19 Troubleshooting POSSIBLE CAUSE POSSIBLE SOLUTION PROBLEM Use the adaptor to supply The built-in rechargeable power or charge the The unit can battery is weak. battery. receive signals now but can’t The unit may be obstructed then; signals Remove the veil. by veil, such as heat received are not insulation paper.
- Page 20 PC Connection To establish connection with PC for data access and synchronization, please execute setup file included in the Driver/Documentation CD or download the file from Microsoft website to install: Microsoft Active Sync® software for operating system Microsoft XP or earlier versions (http://www.microsoft.com/windowsmobile/en-us/downloads/microsoft/activesync-dow nload.mspx)
