Microlab S331 User Manual

Download this manual

80-S331-97-0001-01 2009-01-04

S331

User Manual

Microlab Technology Company Ltd.

Made in China

SoundBar Powered Speaker

No:80-S331-97-0001-01

Before using, please read the manual carefully

All other brand and product names are trademarks of their respective holders. Actual contents may differ slightly from those shown in print. All

specifications and designs are subjected to changes without any prior notice.

Do you have a question about the S331 and is the answer not in the manual?

Page 1: User Manual
80-S331-97-0001-01 2009-01-04 S331 User Manual Microlab Technology Company Ltd. Made in China SoundBar Powered Speaker No:80-S331-97-0001-01 Before using, please read the manual carefully All other brand and product names are trademarks of their respective holders. Actual contents may differ slightly from those shown in print. All...
Page 2 80-S331-97-0001-01 2009-01-04 Important Safety Instructions Technical Information Specification Amplifier specification: AC IN 220V-240V~ 50Hz 240mA Power output 22W+9.5Wx2 RMS Speaker unit: 5 .25"+ 3 "x2 Product size(WxDxH): amplifier 255 x125x130mm Caution: To reduce the risk of electric shock, do not dismantle the apparatus and do not expose the apparatus to rain or moisture.
Page 3 80-S331-97-0001-01 2009-01-04 System Connection the apparatus is left unused for a long period of time. － 20.Serving Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Page 4 80-S331-97-0001-01 2009-01-04 Function Instruction System Connection Front view of the amplifier Front view of remote control Connection ST-BY clip SOUNDBAR SYSTEM S331 Fix stands and soundbar Connection with connection clip MUTE INPUT clip INPUT1 INPUT2 TREB BASS STANDBY INPUT-SEL VOLUME VOLUME 1.Connect soundbar and...
