  • Page 2 This manual includes product specifications and instructions for SQ-3500 phone operation. This manual must be read before operating the product. The SQ-3500 phone access point is required to use this product. Usage of the SQ-3500 access point provided in the full package is recommended.

  • Page 3: Safety Precautions

    Be sure to only use the designated batteries and accessories for the SQ-3500 provided by our company. If you use unauthorized batteries or accessories, it can reduce the life of the SQ-3500, cause explosions, or damage. If this occurs free servicing is avoid .
  • Page 4 Do not look at the infrared window in a direct way when using the remote control. this can cause visual impairment. Refrain from the use of SQ-3500, and leave the power cord for the charger unplugged when it is thundering and flashed lightning.

  • Page 5: Table Of Contents

    Index Safety Precautions………………………………………………………………………………..................1 Basic Components...………….…………………………………………………………………………………….….…...………………………….……4 Battery Replacement….……………………………………………………………………………………..….……………………………….……...5 Time Taking to Charge / Battery Life………………...………………………………………………………….……………………………………….6 Inserting / Removing a micro SD card…..…………………………………………………………………….…………………………………………8 Power On/Off………………………………………………………………………………………..................9 Names & Function of Device Parts……………………………………...………………………………………………………………………………10 Display Indicators…………………………………………………………………………………………………………………………………………..11 Calling Method……………………………………………………………………..………………………………………………….……………………12 Phone Book………………………………………………………………………………………………………………………………………………….20 Messaging………………………………………………………………………………………………………...…………….……………………………27 Display………………………………………………………………………………………………………………………………………………………..28 Sound Settings…………………………………………………………………………………………………………………………………...…………29 Tools………………………………………………………………………………………………………………………………………………...………..30 Multimedia…………………………………………………………………………………………………………..………………………………………31 Logs…………………………………………………….…………………………………….……………………………………………..………………..32 Settings……………..……………………….……………………………………………………………………………………………..………………..33...

  • Page 6: Basic Components

    Basic Components The Basic Components as shown below may be different from the original. For safety in use, please purchase authentic products. If you want to purchase additional batteries or chargers, contact your dealer. Phone Cradle Battery Manual Adapter...

  • Page 7: Battery Replacement

    Battery removal ① ② ② ③ ① If the battery is inserted upside down, the SQ-3500 phone will not work. Please turn off the power before removing the battery from the SQ-3500 phone. (a sudden power off can cause problems)

  • Page 8: Time Taking To Charge / Battery Life

    Time Taking to Charge / Battery Life Charge the battery Charge the battery after purchasing the product as it is not fully charged. Charging with the desktop charger Features Charging Charging Complete Charging Lamp GREEN ※ Lamp on the charger flickers? Separate the battery from the charger, and then re-fits into the charger.
  • Page 9 Time Taking to Charge / Battery Life Time Taking to Charge / Battery Life ※ Battery life varies with the environment temperature, Model Standard Model battery age and movement of the user. -Battery life is not permanent Charging time 3 hours 30 minutes Battery life Voice 6 hours...

  • Page 10: Inserting / Removing A Micro Sd Card

    Inserting / Removing the Micro SD card Inserting the micro SD card Use Only compatible micro SD cards approved by UniData for use with this device. UniData uses approved industry standards for memory cards, but some brands may not be fully compatible with this device. Incompatible cards may damage the card, the device and corrupt data stored on the card.

  • Page 11: Power On/Off

    Power On / Off If you want to turn on the power, If you want to turn off the power, keep pressing for 3 keep pressing for 3 seconds or more. seconds or more. If anything abnormal takes place, or if the power button does not work while using a Wi-Fi phone, start the phone after removing and inserting the battery.

  • Page 12: Names & Function Of Device Parts

    Names & Function of Device Parts 6 Left Selection Key 1 Send Key Used for receiving and making call 7 Right Selection Key 2 End Key 8 Mute Shortcut Used to end a call and to switch the 9 AP Search Key power ON/OFF 10 Alarm Shortcut 3 Clear Key...

  • Page 13: Display Indicators

    Display Indicators Signal strength Out of call coverage area Call trial or connection Call not available You have selected the sound setting Mute button, displayed when the volume is set to “0” Vibration Mode Silent Mode An Alarm is set You have one or more unread messages in the Inbox folder Setting to call forwarding service Remaining battery life...

  • Page 14: Calling Method

    Calling Method Voice Calls Call Connect In standby, enter the numeric keys and then press the ※ Call quality may be reduced at increased distance away from the access point.

  • Page 15: Video Calls

    Calling Method Video Calls Call connect In standby, enter the numeric keys and then press ※ Call quality may be reduced at increased distance away from the access point.

  • Page 16: Call Logs

    Calling Method Call logs Redialing recently used numbers You can make voice or video calls by dialing recently used numbers (incoming, outgoing, missed, received/sent text messages). During stand-by, press the SEND key and then select the phone number you want to call. - Select VIDEO in the menu if you want to make a video call.
  • Page 17 Calling Method Number Auto-search Press a part of the number you want to call to auto-search the phonebook and display the results. Select a phone number and press the OK key. -Press the VIDEO key to make a video call. ※...
  • Page 18 Using the Menu During a Voice Call Using the menu during a voice call Making a voice call •Refer to page 12. Mute: This function stops your caller from hearing your voice temporarily. The caller's voice can still be heard. Taking a voice call Press the SEND key to take an incoming call.
  • Page 19 Using the Menu During a Video Call Making a video call Using the menu during a video call •Refer to page 13. Change Camera: To converts the current video preview to back or front camera sight. Taking a video call Preview Off: Off the preview.
  • Page 20 Missed call If you have a missed call, press , and the last one of those calls will be answered. To see calls that have arrived in your absence from the call list, press or use the Left selection key Menu) >...

  • Page 21: Transferring A Call

    Call Transfer / Hold / Waiting Transferring a call While you are on active call, you can announce that you are transferring the active call to another party, or you can directly transfer the call. 1. Press the to put the call on HOLD. 3rd party numbers and place a new call 2.

  • Page 22: Phone Book

    Phone Book Right select key for shortcut Left selection key ( Menu > Contacts > Search contacts ) Enter a part of a name, phone number or e-mail address to search for a phone number. Search all: Search by a part (more than 1 character) of a name, phone number or e-mail address.
  • Page 23 Phone Book 1. Phone Number Search - Menu (for a saved number) 2. Phone number search – video call 1. Press the to make a video call from the phone book you have selected. - The phone number selected must be compatible with video calling.
  • Page 24 Phone Book 1. Phone Number Search - Menu (for a saved phone number) 4. Phone Number Search - Delete Press and select > Delete from Phone Book menu. Delete the selected number. 5. Phone Number Search – Selection delete Press and select >...
  • Page 25 Phone Book 2. Add new contacts ( Menu > Contacts > Name Save a name. (Up to 48 alphabet characters) Add contacts ) Add a new phone number and other details. Group Assign a group. Use direction key to assign the group. Phone Save a phone number.
  • Page 26 Phone Book You can add new number in standby mode. Dial a phone number and press SAVE during stand-by to save phone numbers.
  • Page 27 Phone Book Phone Book 3. To set speed dial, select ( Menu > Contacts > Speed dial ) Set speed dial numbers for phone numbers saved in the phone book that are frequently called (up to 99 speed dial numbers can be saved). 1.
  • Page 28 Phone Book Group Settings ( Menu > Contacts > Group Settings )+ Edit a group to assign a phone number or add a new group. Select a group to edit and change the group name and Group name: Enter a group name (24 alphabet characters) ring tone.

  • Page 29: Messaging

    Messaging In messaging, you can read, write and send messages. The messaging service can only be used if it is supported by your network or service provider Left selection key ( Menu > Messaging ) or press the shortcut key Create a text message Select Menu >...

  • Page 30: Display

    Display Display settings Select the left selection Menu > Display There are 4 options included in Display Settings Wallpaper Select Menu > Display > Wallpaper This feature enables you to set a picture as a wallpaper image in your phone‟s stand -by screen. There are fifteen built-in pictures for you to change the background image Screen To define the clock type of the time format in stand-by screen, Select...

  • Page 31: Sound Settings

    Sound Settings Bell Select left selection Menu > Sound settings > Bell to change the type of the bell type Bell mode Select menu > Sound settings > Bell mode to choose how the phone notifies you of an incoming voice call. The alert type allows you to choose between Ringing(Ringtone), Vibrating and Silent.

  • Page 32: Tools

    Tools Alarm To set an alarm, Select left selection Menu > Tools > Alarm > Speed alarm. When an alarm is activated, the alarm indicator will be displayed. To dismiss the alarm and return to standby mode, press <CRL> or <Right selection Key Unit converter To convert unit to different unit, Select menu >...

  • Page 33: Multimedia

    Multimedia Multimedia To optimize the use of Multimedia, insert a memory card in your device. To use multimedia, Select left selection Menu > Multimedia The player supports files formats such as MP4, MP3, JPG, PNG, GIF and BMP.

  • Page 34: Logs

    Logs Select left selection Menu > Logs > Call history Log information about the communication history of the device. The device registers missed , received calls and SMS history up to 100. To move to another tab press the <CRL> then use the <direction Key> Call logs info To view the total number of calls, Select Menu >...

  • Page 35: Settings

    Settings Press the shortcut key to set to Wi-Fi Left selection key ( Menu) > Setting > Wi-Fi Wi-Fi Settings. If you select Wi-Fi, the following display will appear: 1. Display registered Wi-Fi profile (Top) • SQ-3000 can be registered Wi-Fi up to 4 •...
  • Page 36 WLAN Settings Wi-Fi Menu lists • Refresh: Refresh the scanned AP • Detail: Detail information of selected AP • Profile add: Add new profile. • Delete: Delete selected item ( It will be displayed on the menu when you select the registered AP list ) •...
  • Page 37 WLAN Settings Wi-Fi Settings. 2. Add profile from AP list Select 1) SSID setting: Enter SSID name 2) Security setting: You can configure security to use. (WEP/WPA-PSK/WPA-EAP/WPA2-PSK/WPA2-EAP) 3) Account/Password: You can configure the ID/PWD and Mode(MD5/PEAP/TTLS) for authentication 4) STUN: You can configure server and port of NAT 5) Networking setting : You can set Network DHCP or manually 3.
  • Page 38 User Settings Reset to default Left selection key ( Menu) > Settings > User settings > Reset to default ) To reset all preference settings and delete all personal data, such as contacts, message, WLAN and SIP information...
  • Page 39 You can use the SQ-3500 as a Digital Photo Frame when it‟s on the cradle. To make a digital photo frame with the SQ-3500, copy images to the Micro SD card and insert Micro SD card into the SQ-3500. Left selection key ( Menu) >...

  • Page 40: Ntp Server

    Time-zone NTP server Time-zone To update the time, date, and time zone information To define your time zone, select Left selection key Menu) > Settings > Time-zone) with the NTP server automatically, select Left selection key Menu) > Settings > System > NTP server) You can select country and city of the country.

  • Page 41: Call Forwarding

    Call Forwarding Call Forwarding To set the divert setting to on, select Left selection key ( Menu) > Settings > Call Forwarding) With call forwarding, you can direct your incoming calls to another number. Select the forwarding option you want from Unconditional(when you want to divert all incoming calls), Busy(when your number is busy) to No Answer (when you don‟t answer an incoming call).

  • Page 42: Network Info

    Information Left selection key ( Menu) > Settings > Information) You can see the setting information of Wi-Fi phones. Network info. Basic Info. Displays the IP address, netmask, gateway and DNS My phone number, Firmware version, MAC address address. Wi-Fi Info. Displays the access point or wired/wireless router the Wi-Fi phone is connected to.

  • Page 43: Sip Settings

    System Settings SIP Settings Left selection key ( Menu) > Settings > System > SIP You can set the information of the SIP server. SIP Account. * You can select symbol in Phone number, User name, Domain, Proxy. If you select SIP, the following options will appear: Left selection key ( Menu) >...

  • Page 44: Firmware Upgrade

    System Settings NTP server Please refer to page 38. Settings > System > NTP Server Select Left selection key ( Menu) > Provision Settings To download the new firmware via our Auto Provisioning Sever, Settings > System > Provision > Enable Select Left selection key ( Menu) >...

  • Page 45: Before Going To Service Center

    Before going to Service Center Wi-Fi phone cannot start. The battery is full, but the phone keeps turned off? Check whether it is correctly installed • Separate the battery from the phone, and then, re-fits into • Check whether battery is fully charged •...
  • Page 46 Before going to Service Center Calls are not made If calls are not made on Wi-Fi phones after installing AP, check Internet connection, and then the following. If Wi-Fi phone screen displays , check the following • If Wi-Fi phone displays in signal strength, check if the wireless condition indicator of AP, lights of its lamp, and turn off and on the power of Wi-Fi phone after temporarily maintaining a distance of 1.5-3 meters between AP and Wi-Fi phone.
  • Page 47 Specification Product Specification 인증번호: UDC-SQ-3500-VA(B) FCC ID: SQMSQ-3500 6303A-SQ-3500 Certified 2400MHz ~ 2483.5MHz 802.11b/g UniData Communication Systems, INC. Frequency Company 5150MHz ~ 5250MHz (A band) Band Wireless Data Communication system 802.11a Device Name 5725MHz ~ 5850MHz (D band) wireless appliance Ch1 ~ Ch 13 802.11b/g...
  • Page 48 Please make sure that the request includes the model number and the software version number. UniData Communication Systems, Inc. 3F,BuRim-Bldg, 837-6, BangBae-Dong, SeoCho-Gu, Seoul, 137-835, Korea The UniData website www.udcsystems.com/opensource...
  • Page 49 http://www.udcsystems.com...
