- Page 1 APPENDIX A Pro-Command Installation Manual Page | 1...
-
Page 2: Installation Manual
Manual Edition J51613H No part of this document may be reproduced in any form, electronic or mechanical, for any purpose without written consent from Image Vault®, LLC. Information contained within this document is subject to change without notice. THE INFORMATION IN THIS PUBLICATION IS PROVIDED AS-IS WITHOUT ANY WARRANTY OF ANY KIND. THE ENTIRE RISK ARISING OUT OF THE USE OF THIS INFORMATION REMAINS WITH THE RECIPIENT. -
Page 3: Table Of Contents
Image Vault® Pro-Command version 9.4.3 Installation Manual Table of Contents Introduction Technical Notes Package Contents Facilities Front Panel Rear Panel Connectivity Mounting DVR Power Input Devices Monitor Network Connections Alarm Connections Capture Cards Connecting a PTZ POS and Data Connectivity... -
Page 4: Introduction
Installation Manual Introduction Welcome to Image Vault®. This manual is intended for proper installation of the Image Vault® DVR and to serve as a reference guide for troubleshooting if a problem occurs. Only trained installers should attempt installing this product. -
Page 5: Technical Notes
Installation Manual Technical Notes Ensure that the power switch located on the back left of the Image Vault® is switched to the OFF position before plugging into a power source. Do not remove the power ground pin from the power connector. Grounding is essential to the proper performance of the DVR and UPS and will void manufacturer’s warranty if removed. -
Page 6: Package Contents
Image Vault® Pro-Command version 9.4.3 Installation Manual Package Contents The Image Vault® package contents are: Quick Reference Guide (page 28) Audio Disclaimer (page 25) Installation Considerations (page 26) IVPTZAOC connection diagram (page 24) Warranty Document (page 27) ... -
Page 7: Facilities
Image Vault® Pro-Command version 9.4.3 Installation Manual Facilities This section provides detailed information about common hardware components. Front Panel Diagram 7.1 Front Panel A. Front Ventilation. The front panel air vent cover is removable for easy filter cleaning. A monthly cleaning of the filter is recommended. -
Page 8: Rear Panel
Image Vault® Pro-Command version 9.4.3 Installation Manual Rear Panel 16/480 Unit C D E Diagram 8.1 Rear Panel A. AC Power Input. Standard 3-prong IEC inlet. B. Power Supply Switch. Use this switch to completely remove power. Turning this switch on does not automatically start the recorder (refer also to Front Panel Power Switch). - Page 9 Image Vault® Pro-Command version 9.4.3 Installation Manual G. Network Interface Card. For connection to the network. H. USB Port(s). For connection of USB devices such as keyboards, mice, USB thumb drives, etc. I. Alarm Output. For connection of watchdog and secondary alarm relay(s) output(s).
- Page 10 Image Vault® Pro-Command version 9.4.3 Installation Manual Rear Panel 32/240 Unit C D E Diagram 9.1 Page | 10...
-
Page 11: Connectivity
This section provides detailed information about connecting power, keyboard, mouse, VGA monitor, video, audio, and data devices. Mounting The Image Vault® is a 4U rack mountable DVR, which can be installed as a free-standing unit. For suspended mounting you will require the optional mounting bracket part # IVBRACK4SP. Power Make sure the power switch (B –Diagram 8.1) is in the off position. -
Page 12: Alarm Connection
Connect the Image Vault® alarm outputs in accordance with the provided IVPTZAOC wiring diagram (APPENDIX B). The Image Vault® DVR allows up to 16 alarm inputs. To connect external inputs you will need a DB25 cable, or DB25 pin out connector. The pin out is in numerical order. Pin 1 is input 1, pin 2 is input 2. -
Page 13: Capture Cards
Image Vault® Pro-Command version 9.4.3 Installation Manual Capture Cards PROC16480-XX: The PROC16480 model can connect up to 16 cameras at an accumulative capture rate of up to 480 frames per second. Use a provided whip cable to connect cameras 1-8 to the (K diagram8.1) DB15 port on the capture card. - Page 14 Image Vault® Pro-Command version 9.4.3 Installation Manual PROC32240-XX: The PROC32240 model can connect up to 32 cameras at an accumulative capture rate of up to 240 frames per second. Use a provided whip cables to connect the DVI ports on the back of the DVR and connect cameras.
-
Page 15: Connecting A Ptz
Image Vault® Pro-Command version 9.4.3 Installation Manual Connecting a PTZ Camera To attach a PTZ camera use the included IVPTZAOC wiring diagram (also located in Appendix B). POS and Data Device Connectivity Point of sale (POS) and data devices can be connected utilizing serial or network connections. There are three methods of serial connections and four methods of network connections. - Page 16 Image Vault® Pro-Command version 9.4.3 Installation Manual Example 1 Single Data Device: Example 2 Multi-Device Server: Page | 16...
- Page 17 Image Vault® Pro-Command version 9.4.3 Installation Manual Example 3 IV Quad: Serial Port 2 Serial Port 2 is for an additional direct Point of Sale (POS) or data device serial connectivity. Serial Port 2 doubles the connectivity options serially. For example, you can have 2 IV Quads for connection of up to 8 single data devices.
- Page 18 Installation Manual Network Data Device Connections The Image Vault® can connect to POS or data devices via the network using the aforementioned methods. Capturing POS data from a network print server does not require any additional cables. The DVR must be connected to the same local network as the POS data source.
-
Page 19: Booting Up Dvr
Once you have successfully logged into the software start you configuration. Only shut down the DVR using the software. Do not shut down the DVR by removing AC power. Only use the reset button or power rocker switch when advised by Image Vault® technical support. Page | 19... - Page 20 Image Vault® Pro-Command version 9.4.3 Installation Manual Notes Page | 20...
-
Page 21: Technical Support
Image Vault® Pro-Command version 9.4.3 Installation Manual Technical Support 1-888-462-4382 Monday –Friday 8AM-5PM EST Image Vault LLC 101 Security Parkway New Albany IN 47150-0559 Phone (888) 462-4382 Fax (812) 296-0038 www.image-vault.com Image Vault® is a member of FKI Security Group Page | 21... -
Page 22: Appendix A
APPENDIX A Additional Data Device Parts List Part # Description Chapter 1 IV-9 Chapter 2 9 Pin POS Cable - Comes with IV-DB9F IV-25 25 Pin POS Cable - Comes with IV-DB9F IV-G RJ-45 Gilbarco POS Cable - Comes with IV-DB9F IV-DB9F Female 9 Pin DVR cable IV-RK... -
Page 23: Appendix B
APPENDIX B Addition Installation Documents In this Section Follow this page. Page | 23... -
Page 25: Important Notice
Neither Image Vault, LLC, as the manufacturer, nor any entity from or through which this equipment and software was purchased, can accept any responsibility... - Page 26 Following steps are taken to reduce the possibility of failures when Installing the Image Vault in a harsh environment. Image Vault, LLC reserves the right to void the manufacturer’s warranty on products that show evidence of a harsh environment installation.
- Page 27 Image Vault will ship the repaired unit via standard ground freight to the original install location. Image Vault, LLC reserves the right to have its representative inspect any product or component to honor any claim and to receive a purchase receipt or other proof of purchase before warranty service is performed.
- Page 28 Quick Reference Guide D I G I T A L D I G I T A L VIDEO SECURITY VIDEO SECURITY LIVE MONITOR SCREEN THIS SCREEN IS USED TO VIEW LIVE VIDEO AS IT IS BEING CAPTURED Click and drag to change camera order. Change the layout and number of cameras displayed. Show or hide camera names, POS data, and motion detection grids.
-
Page 29: Playback Screen
Quick Reference Guide D I G I T A L D I G I T A L VIDEO SECURITY VIDEO SECURITY PLAYBACK SCREEN THIS SCREEN IS USED TO VIEW RECORDED VIDEO, SEARCH AND DISPLAY DATA, AND CONFIGURE THE DVR Camera windows may be shown with borders on or off. Click and drag to sync one camera to another. Zoom, show motion grids, show associated POS data, and play audio with the video as desired. - Page 30 APPENDIX A Pro-Command...
