User's Guide
LAN Port
3
The RJ-45 LAN port with eight pins is larger than the RJ-11 Modem port and supports a standard Ethernet
cable for connection to a local network. The built-in connector allows convenient use without additional
adapters.
Modem Port
4
The RJ-11 modem port is smaller than the RJ-45 LAN port and supports a standard telephone cable. The
internal modem supports up to 56Kbps transfers. The built-in connector allows convenient use without
additional adapters.
IMPORTANT!
The built-in modem does not support the voltage used in digital phone systems. Do not connect the modem port to a
digital phone system or else damage will occur to the Notebook PC.
5
5 Antenna Input (on selected models)
The antenna input is for TV or FM Radio (on selected models) frequency signal and allows for use with the
provided digital TV/FM antenna or input from subscription television services. The provided antenna can
receive digital TV or FM radio. Cable service connection can receive digital TV, analog TV, or FM radio
depending on paid services. Note: Use the provided adapter for use with coaxial connectors.
6 Power (DC) Input
The supplied power adapter converts AC power to DC power for use with this jack. Power supplied through this
jack supplies power to the Notebook PC and charges the internal battery pack. To prevent damage to the
Notebook PC and battery pack, always use the supplied power adapter. CAUTION: MAY BECOME WARM TO
HOT WHEN IN USE. BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM YOUR BODY.
Knowing the Parts
2-13
