- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y 2 D r a w e r W i n e & B e v e r a g e C o o l e r V T - D R A W 2 W B C O W N E R ’...
-
Page 2: General Operating Instructions
Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. Let the unit rest UNPLUGGED for 24 hours once you have it placed in your home. -
Page 3: Table Of Contents
TABLE OF CONTENTS PARTS AND SPECIFICATIONS ..........4 IMPORTANT SAFETY INSTRUCTIONS ........5 CORD INSTRUCTIONS ............6 BEVERAGE COOLER INSTALLATION ........6 DISPLAY PANEL ..............7 TEMPERATURE CONTROL ............. 8 CARE AND MAINTENANCE ............ 9 MOVING YOUR BEVERAGE COOLER ........9 CIRCUIT DIAGRAM .............. -
Page 4: Parts And Specifications
PARTS AND SPECIFICATIONS 1. Upper door handle Lower door handle 17. Rear exhaust window 2. Upper door Lower door 18. Upper zone seal 3. Temperature switch 10. Panel 19. Lower zone seal 4. Upper zone 11. Body 20. Lower zone fan temperature control 12. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should be followed to reduce the risk of fire, electric shock, and personal injury. Use this appliance only as described in this manual. Other uses are not recommended and may cause fire, electric shock or injury. This product is intended for indoor, household use. -
Page 6: Cord Instructions
CORD INSTRUCTIONS For your protection, this unit should be properly grounded. Unit is equipped with a 3-conductor cord set that has a molded 3-prong grounding- type plug, and should be used in combination with a properly connected grounding-type outlet as shown in figure A. It is not recommended to use this beverage cooler with an extension cord or power board. -
Page 7: Display Panel
DISPLAY PANEL On the display panel in middle of the control panel, you can read the following information and adjust the temperature setting according to your condition: 1. Indicator of the whole unit’s working status. 2. Indicator of the lower zone’s working status: ※... -
Page 8: Temperature Control
TEMPERATURE CONTROL To control the upper zone temperature, use the UP and DOWN buttons on the left side to adjust the temperature by 1° increments To control the lower zone temperature, press UP and DOWN button on the right side to adjust the temperature by 1° increments. ... -
Page 9: Care And Maintenance
CARE AND MAINTENANCE Always unplug the cooler and remove any beverage containers before cleaning. Do not use benzene, scrubbing brushes or chemical cleaners as these will damage the unit. Use only a mild, nonabrasive cleanser to clean the exterior of the cabinet. -
Page 10: Troubleshooting Guide
TROUBLESHOOTING GUIDE You can solve many common cooler problems easily, saving you the cost of a service call. Try the suggestions below to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com. PROBLEM POSSIBLE CAUSE Unit does not ... -
Page 11: Terms Of Sale And Warranty
Note: Unfinished wood is subject to warping; all wood surfaces must be sealed before placing cellar into service. Improper placement of the unit will void the warranty. By Vinotemp in writing, any third party repair facility must be pre-approved before providing parts free of charge. -
Page 12: Service & Important Notice
Rancho Dominguez, CA 90221 www.vinotemp.com Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
