Summary of Contents for Dynalink ALE070
- Page 1 ADSL External Modem Quick Setup Guide ALE070...
- Page 2 ADSL External Modem Quick Set-up Guide Introduction By purchasing a Dynalink ADSL modem you have entered into the world of broadband Internet access. ADSL not only provides high speed access but also is an "always on" service. Security Exposure to potential security risks while you are online is an issue that should not be ignored.
-
Page 3: Before You Start
Before you start Please follow the steps outlined in this guide. Modem drivers are located on the supplied manufacturer’s CD. You will also find a User’s Manual that provides further information on this modem. Minimum System Requirements: Pentium ® II 233 MHz 64MB RAM Windows ®... - Page 4 ADSL External Modem Quick Set-up Guide Installing modem into computer 1. Connect the USB port of the modem to your system using the USB cable provided. 2. Connect the LINE port of the modem into your ADSL jackpoint (telephone wall socket) using the line cord provided.
- Page 5 Installing the software utility When the Welcome screen appears: 1. Click Next. Answer Yes to accept the Software License Agreement. 2. Select Other Service Provider - Next. 3. Highlight WAN driver, then Next. 4. Enter the following parameters and click Next to continue. IMPORTANT- these are essential parameters that must be used in New Zealand, independent of ISP: VPI: 0 VCI: 100 Encapsulation: RFC2364 PPPoATM NULL Encapsulation...
- Page 6 ADSL External Modem Quick Set-up Guide Going on line You will be using Windows Dial-Up Networking to make a connection to your ISP. Check the Link Status. The modem must first establish a link to the head-end equipment at your local telephone exchange.
-
Page 7: Troubleshooting
Troubleshooting Meaning of the modem indicator lights PWR: Power is being provided by your system to the modem. LINK (flashing): Connection to local telephone exchange is being established. LINK (steady): Connection is made. Now ready to go on line. Diagnostics utility Upon successful installation, a modem connectivity monitoring utility is also installed. - Page 8 Return delivery after repair will be paid for by Dynalink Modems Ltd within New Zealand. We reserve the right not to repair or replace goods that: have been mishandled, abused or not installed according to the guidelines as outlined in the instructions.
