LevelOne

User Manual

FBR-1461
ADSL2+ Modem Router w/ QoS
V2.0 – 0809

Advertisement

Table of Contents
loading

Related Manuals for LevelOne FBR-1461

Summary of Contents for LevelOne FBR-1461

  • Page 1: User Manual

    LevelOne User Manual FBR-1461 ADSL2+ Modem Router w/ QoS V2.0 – 0809...

  • Page 2: Table Of Contents

    1.3.1 Applications of the FBR-1461 ......... 9 Chapter 2 ..................... 10 2.1 Package Contents ............. 10 2.2 Important Notes ..............10 2.3.1 The Front LEDs - FBR-1461 .......... 11 2.4.1 The Rear Ports - FBR-1461 ........... 12 2.5 Cabling ................13 Chapter 3 ..................... 14 3.1 Before Configuration ............
  • Page 3 5.4 Save Configuration to Flash ..........93 5.5 Restart ................93 5.6 Logout ................94 Chapter 6 ..................... 95 Default Settings IP Address 192.168.0.1 Admin / Password admin / password...

  • Page 4: Chapter 1

    Introduction 1.1 Introducing the FBR-1461 Thank you for purchasing the FBR-1461 Modem Router. Your new router is an all-in-one unit that combines an ADSL2/2+ modem, router and Ethernet network switch to provide everything you need to get the machines on your network connected to the Internet over an ADSL broadband connection.
  • Page 5 The FBR-1461 provides two levels of security support. First, it masks LAN IP addresses making them invisible to outside users on the Internet, so it is much more difficult for a hacker to target a machine on your network. Second, it can block and redirect certain ports to limit the services that outside users can access.

  • Page 6: Features

    1.2 Features Express Internet Access – ADSL2/2+ capable The FBR-1461 complies with ADSL worldwide standards. Supporting downstream rates of 8Mbps with ADSL, the router is capable of up to 12/24 Mbps with ADSL2/2+, and upstream rates of up to 1 Mbps. Users enjoy not only high-speed ADSL services but also broadband multimedia applications such as interactive gaming, video streaming and real-time audio which are easier and faster than ever.
  • Page 7 DDNS service such as http://www.dyndns.org/. PPP over Ethernet (PPPoE) The FBR-1461 provides an embedded PPPoE client function to establish a connection. You get greater access speed without changing the operation concept, while sharing the same ISP account and paying for one access account. No PPPoE client software is required for the local computer.
  • Page 8 Virtual Server: You can specify which services are visible to outside users. The router detects an incoming service request and forwards it to the specific local computer for handling. For example, you can assign a PC in a LAN to act as a Web server inside and expose it to the outside network. Outside users can browse inside the web server directly while it is protected by NAT.

  • Page 9: Applications Of The Fbr-1461

    1.3.1 Applications of the FBR-1461...

  • Page 10: Chapter 2

    Do not use the same power source for the FBR-1461 as other equipment.  Do not open or repair the case yourself. If the FBR-1461 is too hot, turn off the power immediately and have it repaired at a qualified service center.

  • Page 11: The Front Leds - Fbr-1461

    2.3.1 The Front LEDs - FBR-1461 Meaning PPP : Lit green when WAN port gets IP address successfully. Blinking when attempting to connect to ADSL DSLAM ADSL: Lit when successfully connected to an ADSL DSLAM Lit when connected to an Ethernet device.

  • Page 12: The Rear Ports - Fbr-1461

    2.4.1 The Rear Ports - FBR-1461 Port Description Connect the supplied power adapter to this jack. After the router is powered on, press this reset button using the end of paper clip or other small pointed object to reset the router and to restore it to factory default settings.

  • Page 13: Cabling

    The detail instruction in Reset Button 1. Recovery procedures for non-working routers (e.g. after a failed firmware upgrade flash): Hold the Reset Button on the back of the modem in. Keep this button held in and turn on the modem. Once the lights on the modem have stopped flashing, release the Reset Button. modem's emergency-reflash interface...

  • Page 14: Chapter 3

    If not, please refer to your Windows-related or other operating system manuals. Note: Any TCP/IP capable workstation can be used to communicate with or through the FBR-1461. To configure other types of workstations, please consult the manufacturer‟s documentation.
  • Page 15 Configuring a PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.
  • Page 16 Configuring a PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4.
  • Page 17 Configuring PC in Windows 98/Me 1.Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2.Select TCP/IP ->NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.Select the Obtain an IP address automatically radio button.
  • Page 18 Configuring PC in Windows NT4.0 1.Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2.Select TCP/IP Protocol and click Properties. 3.Select the Obtain an IP address from a DHCP server radio button and click OK.

  • Page 19: Factory Default Settings

    3.2 Factory Default Settings Before configuring the FBR-1461 router, you need to know the following default settings. Web Interface: (Username and Password) Username: admin Password: password The default username and password are “admin” and “password” respectively. Attention: If you ever forget the username/password to login to the router, you may press the RESET button up to 6 seconds then release it to restore the factory default settings.

  • Page 20: Lan And Wan Port Addresses

    3.3 LAN and WAN Port Addresses The parameters of LAN and WAN ports are preset at the factory. The default values are shown below. LAN Port WAN Port IP address 192.168.0.1 The PPPoE function is enabled to automatically get Subnet Mask 255.255.255.0 the WAN port configuration from the ISP, but you have to...

  • Page 21: Configuring With Your Fbr-1461

    3.5 Configuring with your FBR-1461 Note: 1. To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed 2. You may configure the router for Internet access in two ways: (A) Easy Sign On (B) Web Configuration...
  • Page 22 2. Choose “Auto” or “Manually” to scan ADSL settings. Note: If automatic detection does not work, please ask your ISP and enter the Protocol, VPI and VCI manually. 3. The Auto scan result is displayed 4. Please enter “Username” and “Password” as supplied by your ISP (Internet Service Provider) and click continue.
  • Page 23 5. You‟ve have completed the WAN port setup and now your Configuration will be saved. 6. Congratulations!! You‟ve completed the setup procedure and you are now ready to surf the Internet, enjoy.
  • Page 24 Open your web browser, enter the IP address of your router, which by default is 192.168.0.1, and press the “Enter” key, a user name and password window prompt appears. The default username and password are “admin” and “password”. Congratulations! You have successfully logged on to your FBR-1461 Modem Router!

  • Page 25: Chapter 4

    Chapter 4 Basic Configuration Once you have logged on to your FBR-1461 Router via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the setup pages, which include: ...

  • Page 26: Status

    4.1 Status This page shows you the current status of the FBR-1461. Device Information  Model Name: The model name of the device.  System Up-Time: Records system up-time.  Hardware Version: Device version  Software Version: Firmware version Port Status ...

  • Page 27: Quick Start

    4.2 Quick Start This wizard is similar to Easy Sign On, and will guide you through setting up your FBR-1461. Click Continue to start the wizardz.

  • Page 28: Wan

    4.3 WAN Here you can manually enter the ADSL settings provided by your Service Provider. Use this if the Easy Sign On, or Quick Start cannot successfully auto-detect your ADSL settings.  VPI/VCI: Enter the VPI and VCI information provided by your ISP. ...

  • Page 29: Chapter 5

    Chapter 5 Advance Configuration Once you have logged on to your FBR-1461 Router via your web browser, you can begin to set it up according to your requirements. On the configuration homepage, the left navigation pane links you directly to the setup pages, which include: ...

  • Page 30: Status

    5.1 Status This page shows you the current status of the FBR-1461, with advanced options such as Host Name and Time settings. Device Information  Model Name: The model name of the device.  Host Name: Provide a name for the router for identification purposes. Host Name lets you change the router name.
  • Page 31  Port: Name of the WAN connection.  Protocol VPI/VCI: Virtual Path Identifier and Virtual Channel Identifier  Operation: Current available operation.  Connection: The current connection status.  IP Address: WAN port IP address.  Netmask: WAN port IP subnet mask. ...

  • Page 32: Adsl Status

    5.1.1 ADSL Status This page shows you the current status of the FBR-1461‟s ADSL connection.  DSP Firmware Version: DSP code version  DMT Status: Current DMT Status  Operational Mode: To show the state when user select “AUTO” on connect mode.

  • Page 33: Arp Table

     MAC Address: The MAC address of internal host. 5.1.3 DHCP Table This page shows you the network clients (Notebooks or PCs) that are allocated IP Addresses by the FBR-1461‟s DHCP Server.  IP Address: The current corresponding DHCP-assigned dynamic IP address of the device.

  • Page 34: System Log

    5.1.4 System Log Display system logs accumulated up to the present time. You can trace historical information with this function.

  • Page 35: Firewall Log

    5.1.5 Firewall Log Firewall Log displays log information of any unexpected action with your firewall settings. This page displays the router‟s Firewall Log entries. The log shows log entries when you have enabled Intrusion Detection or Block WAN PING in the Configuration – Firewall section of the interface.

  • Page 36: Quick Start

    5.2 Quick Start This wizard is similar to Easy Sign On, and will guide you through setting up your FBR-1461. Click ”Continue” to start the wizard.  Connect mode: ADSL  Protocol: The current ATM protocol in the device  VPI / VCI: The current value of VPI / VCI in the device...

  • Page 37: Configuration

    5.3 Configuration Click this item to access the following sub-items that configure the ADSL router: LAN, WAN, System, Firewall, QoS, Virtual Server, Time Schedule and Advanced. These functions are described in the following sections. 5.3.1 LAN (Local Area Network) A Local Area Network (LAN) is a shared communication system to which many computers are attached and is limited to the immediate area, usually the same building or floor of a building.
  • Page 38 5.3.1.1 Ethernet The router supports more than one Ethernet IP addresses in the LAN, and with distinct LAN subnets through which you can access the Internet at the same time. Users usually only have one subnet in their LAN. The default IP address for the router is 192.168.0.1. ...
  • Page 39 5.3.1.6 DHCP Server You can disable or enable the DHCP (Dynamic Host Configuration Protocol) server or enable the router‟s DHCP relay functions. The DHCP protocol allows your router to dynamically assign IP addresses to PCs on your network if they are configured to obtain IP addresses automatically.
  • Page 40  DHCP Server Mode: DHCP Relay If you check DHCP Relay and then you must enter the IP address of the DHCP server which assigns an IP address back to the DHCP client in the LAN. Use this function only if advised to do so by your network administrator or ISP.

  • Page 41: Wan (Wide Area Network)

    5.3.2 WAN (Wide Area Network) A WAN (Wide Area Network) is an outside connection to another network or the Internet. There are two items within the WAN section: WAN Profile and ADSL Mode.
  • Page 42 5.3.2.1 WAN Profile Profile Port--ADSL PPPoE Connection PPPoE (PPP over Ethernet) provides access control in a manner similar to dial-up services using PPP.  Description: A user-definable name for this connection.  VPI/VCI: Enter the VPI and VCI information provided by your ISP. ...
  • Page 43  IP Address: Your WAN IP address. Leave this at 0.0.0.0 to automatically obtain an IP address from your ISP.  Auth. Protocol: Default is Auto. Your ISP advises on using Chap or Pap.  Obtain DNS Automatically: Select this check box to use DNS. ...
  • Page 44 PPPoA Connection PPPoA stands for Point to Point Protocol over ATM Adaptation Layer 5 (AAL5). It provides access control and billing functionality in a manner similar to dial-up services using PPP.  Description: User-definable name for the connection.  VPI/VCI: Enter the VPI and VCI information provided by your ISP. ...
  • Page 45  Connection:  Always on: The router will establish a PPPoA session when starting up and to automatically re-establish the PPPoA session when disconnected by the ISP.  Connect to Demand (un-select Always On): If you want to establish a PPPoA session only when there is a packet requesting access to the Internet (i.e.
  • Page 46 MPoA Connection  Description: Your description of this connection.  VPI and VCI: Enter the VPI and VCI information provided by your ISP.  Encap. method: Select the encapsulation format, the default is LLC. Select the one provided by your ISP. ...
  • Page 47 Pure Bridge Connections  Description: A user-definable name for this connection.  VPI/VCI: Enter the VPI and VCI information provided by your ISP.  Encap. method: Select the encapsulation format, this is provided by your ISP.
  • Page 48 5.3.2.3 ADSL Mode FBR-1461A (Annex A)  ADSL Mode: There are four modes “Open Annex Type and Follow DSLAM’s Setting”, ”Annex A”, ”Annex L”, ”Annex M” and “Annex J” that user can select for this connection.  Modulator: There are seven modes “AUTO”,”ADSL multimode”,”ADSL2”,”ADSL2+”, “G.Lite:”, “T1.413”...
  • Page 49 FBR-1461B (Annex B) FBR-1461B is Annex B only.  Modulator: There are two modes”ADSL2” and”ADSL2+” that user can select for this connection.

  • Page 50: System

    5.3.3 System There are six items within the System section: Time Zone, Firmware Upgrade, Backup/Restore, Restart, User Management and Mail Alert.

  • Page 51: Time Zone

    5.3.3.1 Time Zone The router does not have a real time clock on board; instead, it uses the Simple Network Time Protocol (SNTP) to get the current time from an SNTP server outside your network. Choose your local time zone, click Enable and click the Apply button. After a successful connection to the Internet, the router retrieves the correct local time from the SNTP server you have specified.
  • Page 52 5.3.3.2 Firmware Upgrade Your router‟s “firmware” is the software that allows it to operate and provides all its functionality. Think of your router as a dedicated computer, and the firmware as the software it runs. Over time this software may be improved and modified. Your router allows you to upgrade the software it runs to take advantage of these changes.
  • Page 53 5.3.3.3 Backup / Restore These functions allow you to save and backup your router‟s current settings to a file on your PC, or to restore a previously saved backup. This is useful if you wish to experiment with different settings, knowing that you have a backup handy in the case of any mistakes. It is advisable to backup your router‟s settings before making any significant changes to your router‟s configuration.
  • Page 54 5.3.3.4 Restart Router Click Restart with option Current Settings to reboot your router and save the current configuration to device. If you wish to restart the router using the factory default settings (for example, after a firmware upgrade or if you have saved an incorrect configuration), select Factory Default Settings to reset to factory default settings.

  • Page 55: Mail Alert

    You are strongly advised to change the password on the default “admin” account when you receive your router, and any time you reset your configuration to Factory Defaults. 5.3.3.6 Mail Alert Send a log via email, if WAN IP is changed or if intruders accessing your computer without permission...

  • Page 56: Firewall

    5.3.4 Firewall Firewall and Access Control Your router includes a full SPI (Stateful Packet Inspection) firewall for controlling Internet access from your LAN, as well as helping to prevent attacks from hackers. In addition to this, when using NAT (Network Address Translation) the router acts as a “natural” Internet firewall, since all PCs on your LAN use private IP addresses that cannot be directly accessed from the Internet.
  • Page 57  Firewall Security and Policy (General Settings): Inbound direction of Packet Filter rules prevent unauthorized computers or applications accessing your local network from the Internet.  Intrusion Detection: Enable Intrusion Detection to detect, prevent, and log malicious attacks.  MAC Filter rules: Prevents unauthorized computers accessing the Internet. ...
  • Page 58  Rule Name: Users-define description to identify this entry. The maximum name length is 32 characters, and then can choose application that they want from listbox.  Internal IP Address / External IP Address: This is the Address-Filter used to allow or block traffic to/from particular IP address(es).

  • Page 59: Mac Filter

     Edit: Check the Rule No. you wish to edit, and then click “Edit”. Delete: Check the Rule No. you wish to delete, and then click “Delete”. Attention: If the DHCP server option is enabled, you must be very careful in assigning IP addresses of a filtered private IP range to avoid conflicts because you do not know which PC in the LAN is assigned which IP address.

  • Page 60: Intrusion Detection

    5.3.4.3 Intrusion Detection Check Enable if you wish to detect intruders accessing your computer without permission. The router automatically detects and blocks a DoS (Denial of Service) attack if a user enables this function. This kind of attack is not to access confidential data on the network; instead, it aims to disrupt specific equipment or the entire network.
  • Page 61 For SYN Flood, ICMP Echo Storm and ICMP flood, IDS will just warn the user in the Event Log but it will not be able to protect against such attacks. Hacker attack types recognized by the IDS Type of Block Intrusion Name Detect Parameter Blacklist Drop Packet Show Log...
  • Page 62 Max ICMP Count ICMP Flood (Default 100 c/sec) Max PING Count ICMP Echo (Default 15 c/sec) Src IP: Source IP Src Port: Source Port Dst Port: Destination Port Dst IP: Destination IP 5.3.4.4 Block WAN PING Check Enable if you wish to exclude outside PING requests from reaching this router.

  • Page 63: Url Filter

    5.3.4.5 URL Filter URL (Uniform Resource Locator – e.g. an address in the form of http://www.example.com filter rules allow you to prevent users on your network from accessing particular websites from their URL. There are no pre-defined URL filter rules; you can add filter rules to meet your requirements.
  • Page 64 Domains Filtering: Checks the domain name in URLs accessed against your list of domains to block or allow. If it matches, the URL request is sent (Trusted) or dropped (Forbidden). The checking procedure is: 1. Check the domain in the URL to determine if it is in the trusted list. If yes, the connection attempt is sent to the remote web server.
  • Page 65 Time Schedule: It is self-defined time period. You may specify a time schedule for your prioritization policy. For setup and detail, refer to Time Schedule section. Log: Click “Log” if you wish to generate logs when the filer rule is applied to the URL Filter.

  • Page 66: Qos (Quality Of Service)

    5.3.5 QoS (Quality of Service) Quality of Service Introduction If you‟ve ever found your „net‟ speed has slowed to a crawl because another family member is using a P2P file sharing program, you‟ll understand why the Quality of Service features in the routers is such a breakthrough for home users and office users.
  • Page 67 Application: A name that identifies an existing policy. Direction: The traffic flow direction to be controlled by the QoS policy. There are two settings to be provided in the Router:  LAN to WAN: You want to control the traffic flow from the local network to the outside world.
  • Page 68 DSCP Mapping Table ADSL2+ Router Standard DSCP Disabled None Best Effort Best Effort (000000) Premium Express Forwarding (101110) Gold service (L) Class 1, Gold (001010) Gold service (M) Class 1, Silver (001100) Gold service (H) Class 1, Bronze (001110) Silver service (L) Class 2, Gold (010010) Silver service (M) Class 2, Silver (010100)
  • Page 69 Priority: Specify the priority for the bandwidth that is not used. For examples, you may specify two different QoS policies for different applications. Both applications need a minimal bandwidth and need more bandwidth, beside the assigned one, if there is any available/non-used one available.

  • Page 70: Connection Diagram

    QoS example for your Network Connection Diagram VoIP HTTP web Normal PCs browsing users Restricted PC ADSL Subscription Rate Upstream: 256 kbps Downstream: 2048 Mbps Example QoS Plan Application IP or Ports Control Flow Data Rate Time Schedule VoIP User 192.168.1.1 Outgoing Minimal 20% with high priority...
  • Page 71 Example QoS Setup VoIP application Voice is latency-sensitive application. Most VoIP devices are used SIP protocol and the port number will be assigned by SIP module automatically. Better to use fixed IP address for catching VoIP packets as high priority.

  • Page 72: Virtual Server

    5.3.6 Virtual Server In TCP and UDP networks a port is a 16-bit number used to identify which application program (usually a server) incoming connections should be delivered to. Some ports have numbers that are pre-assigned to them by the IANA (the Internet Assigned Numbers Authority), and these are referred to as “well-known ports”.
  • Page 73 Examples of well-known and registered port numbers are shown below, for further information, please see IANA‟s website at: http://www.iana.org/assignments/port-numbers Well-known and Registered Ports Port Number Protocol Description FTP Data FTP Control TCP & UDP SSH Remote Login Protocol Telnet SMTP (Simple Mail Transfer Protocol) TCP &...
  • Page 74 5.3.6.1 Port Mapping  Application: Select the service you wish to configure  Protocol: Automatic when you choose Application from listbox or select a protocol type which you want.  External Port & Internal Port: Enter the public port number & range you wish to configure.
  • Page 75 For example, if you set the port number 80 (Web/HTTP) to be mapped to the IP Address 192.168.1.2, then all incoming HTTP requests from outside users are forwarded to the local server (PC) with the IP address of 192.168.1.2. If the port is not listed as a predefined application, you need to add it manually.
  • Page 76 5.3.6.2 DMZ DMZ: The DMZ Host is a local computer exposed to the Internet. When setting a particular internal IP address as the DMZ Host, all incoming packets are checked by the Firewall and NAT algorithms, it is then passed to the DMZ host when a packet received does not use a port number in use by any other Virtual Server entries.

  • Page 77: Time Schedule

    5.3.7 Time Schedule The Time Schedule supports up to 16 time slots which helps you to manage your Internet connection. In each time profile, you may schedule specific day(s) i.e. Monday through Sunday to restrict or allowing the usage of the Internet by users or applications. This Time Schedule correlates closely with router‟s time, since router does not have a real time clock on board;...

  • Page 78: Advanced

    5.3.8 Advanced Configuration options within the Advanced section are for users who wish to take advantage of the more advanced features of the router. Users who do not understand the features should not attempt to reconfigure their router, unless advised to do so by support staff.
  • Page 79 5.3.8.1 Static Route  Destination: The destination subnet IP address.  Netmask: Subnet mask of the destination IP addresses based on above destination.  Gateway: The gateway IP address to which packets are forwarded.  Interface: Select the interface through which packets are forwarded. ...
  • Page 80  Disable: Check to disable the Dynamic DNS function.  Enable: Check to enable the Dynamic DNS function. The fields following are activated and required.  Dynamic DNS Server: Select the DDNS service you have established an account with.  Wildcard: Select this check box to enable the DYNDNS Wildcard. ...
  • Page 81  LAN Group Name: The name you will give to this VLAN.  VLAN ID: The ID tag you will give to this VLAN.  Ethernet Port: Select the Port that you want to tag.  WLAN: Select this if you also want the wireless network to have this tag. ...
  • Page 82 Embedded Web Server: HTTP Port: The port number of the router‟s embedded web server (for web-based configuration uses. The default value is the standard HTTP port, 80. You may specify an alternative if, for example, you are running a web server on a PC within your LAN. For Example: User A changes HTTP port number to 100, specifies their own IP address of 192.168.0.55, and sets the logout time to be 100 minutes.
  • Page 83 Installing UPnP in Windows 98 Example Follow the steps below to install the UPnP in Windows Me. Step 1: Click Start and Control Panel. Double-click Add/Remove Programs. Step 2: Click on the Windows Setup tab and select Communication in the Components selection box.
  • Page 84 Step 3: In the Communications window, select the Universal Plug and Play check box in the Components selection box. Step 4: Click OK to go back to the Add/Remove Programs Properties window. Click Next. Step 5: Restart the computer when prompted. Follow the steps below to install the UPnP in Windows XP.
  • Page 85 Step 4: Select Networking Service in the Components selection box and click Details. Step 5: In the Networking Services window, select the Universal Plug and Play check box. Step 6: Click OK to go back to the Windows Optional Networking Component Wizard window and click Next.
  • Page 86 Auto-discover Your UPnP-enabled Network Device Step 1: Click start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Step 2: Right-click the icon and select Properties. Step 3: In the Internet Connection Properties window, click Settings to see the port mappings that were automatically created.
  • Page 87 Step 5: Select Show icon in notification area when connected option and click OK. An icon displays in the system tray Step 6: Double-click on the icon to display your current Internet connection status.
  • Page 88 Step 3: Select My Network Places under Other Places. Step 4: An icon describing each UPnP-enabled device shows under Local Network. Step 5: Right-click on the icon of your FBR-1461 and select Invoke. The web configuration login screen displays. Step 6: Right-click on the icon of your FBR-1461 and select Properties. A properties window...
  • Page 89 5.3.8.5 IGMP IGMP, known as Internet Group Management Protocol, is used to management hosts from multicast group. IGMP Proxy: Accepting multicast packet. Default is set to Disable. IGMP Snooping: Allowing switched Ethernet / Wireless to check and make correct forwarding decisions. Default is set to Disable. 5.3.8.6 SNMP Access Control Software on a PC within the LAN is required in order to utilize this function –...
  • Page 90 Write Community: Specify a name to be identified as the Write Community, and an IP address. This community string will be checked against the string entered in the configuration file. Once the string name is matched, users from this IP address will be able to view and modify the data.
  • Page 91 From RFC1650 (EtherLike-MIB):  dot3Stats From RFC 1493 (Bridge MIB):  dot1dBase group  dot1dTp group  dot1dStp group (if configured as spanning tree) From RFC 1471 (PPP/LCP MIB):  pppLink group  pppLqr group From RFC 1472 (PPP/Security MIB): ...
  • Page 92 5.3.8.7 Remote Access Remote Access Control: Enable: Select Enable to allow management access from remote side (mostly from internet). Duration: Set how many minutes to allow management access from remote side. Zero means always on. Allowed Access IP Address Range: Valid: Select Valid to allow remote management from these IP ranges.

  • Page 93: Save Configuration To Flash

    5.4 Save Configuration to Flash After changing the router‟s configuration settings, you must save all of the configuration parameters to FLASH to avoid losing them after turning off or resetting your router. Click “Save Config“ and click “Apply” to write your new configuration to FLASH. 5.5 Restart Click Restart with option Current Settings to reboot your router (and restore your last saved configuration).

  • Page 94: Logout

    5.6 Logout To exit the router‟s web interface, choose Logout. Please ensure that you have saved the configuration settings before you logout. Be aware that the router is restricted to only one PC accessing the configuration web pages at a time. Once a PC has logged into the web interface, other PCs cannot get access until the current PC has logged out of the web interface.

  • Page 95: Chapter 6

    Chapter 6 Troubleshooting If your ADSL Router is not functioning properly, you can refer first to this chapter for simple troubleshooting before contacting your service provider support. This can save you time and effort but if symptoms persist, consult your service provider. Problems starting up the router Problem Corrective Action...
  • Page 96 Frequent loss of Ensure that all other devices connected to the same ADSL linesync telephone line as your router (e.g. telephones, fax machines, (disconnections). analogue modems) have a line filter connected between them and the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and ensure that all line filters are correctly installed and the right way around.
