Instructions for
Havis Protective Case
For Apple iPad
DS-DA-701 for iPad 2/3
DS-DA-702 for iPad 4
DS-DA-703 for iPad Air
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
Specifications
Power Supply Input
Dimensions
Weight
Operating Environment
Storage Environment
FCC Statement / Declaration of Conformity
This device complies with the requirements of the Code of Federal Regulations listed below:
FCC Title 47 CFR, Part 15 Class foBr a digital device.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
5V (10 Watt)
11.4" ( 28.9 cm) W x 8.7" ( 22.1 cm ) D x 0.87" ( 2.2 cm ) H
0.8 lbs ( 0.36 kg )
0° C to 35° C ( 32° F to 95° F )
-20° C to 45° C ( -4° F to 113° F )
www.havis.com
1-800-524-9900
Advertisement
Table of Contents
Related Manuals for Havis DS-DA-701
Summary of Contents for Havis DS-DA-701
-
Page 1: Specifications
Instructions for Havis Protective Case For Apple iPad DS-DA-701 for iPad 2/3 DS-DA-702 for iPad 4 DS-DA-703 for iPad Air • READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION. Specifications Power Supply Input 5V (10 Watt) Dimensions 11.4” ( 28.9 cm) W x 8.7” ( 22.1 cm ) D x 0.87” ( 2.2 cm ) H Weight 0.8 lbs ( 0.36 kg ) -
Page 2: Tools Required
Parts Included (Original Instructions) • Protective Case (Back and Front pieces) • Hand Strap (1) • Rubber Corners/Edge (5) NOTE: The Hand Strap comes pre-attached to the back of the Protective Case. If the Hand Strap will not be utilized, remove prior to assembly. •... - Page 3 Installation 1. Remove Protective Case from packaging and seperate the Back piece from the Front piece. 2. Insert the connector from the Protective Case into the Apple iPad. www.havis.com • 1-800-524-9900...
- Page 4 Installation (continued) 3. Place the iPad into the Back piece of Protective Case, ensuring the connector cable is routed as shown. 4. Place the five (5) Rubber Corners & Edge onto the Back piece of Protective Case, ensuring each one aligned properly or they will not fit securely in place.
- Page 5 Align the Headphone Port location to ensure proper orientation of two pieces 6. Holding the two pieces together, carefully turn the Protective Case over. www.havis.com • 1-800-524-9900...
- Page 6 7. Insert all twelve (12) screws and then tighten with #1 phillips screwdriver. 8. To remove your Apple iPad from the Havis Protective Case, simply remove the twelve screws, turn the case over, and lift the Front piece of Protective...
- Page 7 Charging Your Tablet NOTE: This iPad case is designed to be charged using a designated Havis Docking Station (Part # DS-APP-102). If you have the need to chargeyour tablet when not docked, use the supplied Micro-USB cable. Simply connect the Micro-USB cable to the Protective Case, then insert the other end of the cable into a 5V (10Watt) power source.
- Page 8 Related Product Havis offers a Docking Station specifically for use with the DS-DA-700 Series Protective Case. For more information or to order, please visit www.havis.com. DS-APP-102 Docking Station Docking Station for Apple iPad for in vehicle computing. Havis, Inc. 75 Jacksonville Road...
