Havis offers a Docking Station specifically for use with the DS-DA-700
Series Protective Case. For more information or to order, please visit
www.havis.com.
DS-APP-102
Docking Station
Docking Station for Apple iPad for in vehicle
computing.
75 Jacksonville Road
Warminster, PA 18974
www.havis.com
Havis, Inc.
1-800-524-9900
DS-DA-700-SERIES_OMN_5-15
Instructions for
Havis Protective Case
For Apple iPad
DS-DA-701 for iPad 2/3
DS-DA-702 for iPad 4
DS-DA-703 for iPad Air
DS-DA-704 for iPad Air / Air 2
• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
Specifications
Power Supply Input
5V (10 Watt)
Dimensions
11.4" ( 28.9 cm) W x 8.7" ( 22.1 cm ) D x 0.87" ( 2.2 cm ) H
Weight
0.8 lbs ( 0.36 kg )
Operating Environment
0° C to 35° C ( 32° F to 95° F )
Storage Environment
-20° C to 45° C ( -4° F to 113° F )
FCC Statement / Declaration of Conformity
This device complies with the requirements of the Code of Federal Regulations listed below:
FCC Title 47 CFR, Part 15 Class foBr a digital device.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
www.havis.com
1-800-524-9900
Advertisement
Related Manuals for Havis DS-DA-700
Summary of Contents for Havis DS-DA-700
- Page 1 DS-DA-702 for iPad 4 DS-DA-703 for iPad Air Related Product DS-DA-704 for iPad Air / Air 2 Havis offers a Docking Station specifically for use with the DS-DA-700 Series Protective Case. For more information or to order, please visit www.havis.com. DS-APP-102...
- Page 2 NOTE: This iPad case is designed to be charged using a designated • Protective Case (Back and Front pieces) Havis Docking Station (Part # DS-APP-102). If you have the need to chargeyour tablet when not docked, use the supplied Micro-USB cable. Simply connect the Micro-USB cable to the Protective Case, then insert the other end of the cable into a 5V (10Watt) power source.
- Page 3 Torque screws to 10 in-lbs (1.1Nm) ± 10%. from the Front piece. 8. To remove your Apple iPad from the Havis Protective Case, simply remove 2. Insert the connector from the Protective Case into the Apple iPad. the twelve screws, turn the case over, and lift the Front piece of Protective Case off the Back piece.
- Page 4 6. Holding the two pieces together, carefully turn the Protective Case over. not fit securely in place. Insert Rubber Edge piece (#5 below) with short edge along outside edge of Protective Case. Some slight warping will be evident if inserted incorrectly www.havis.com • 1-800-524-9900...
