Remote Starter Integration for the 2007 Toyota Camry equipped
with the Smart Key System with Push Button Start
1.0 Material required:
-
Remote Car Starter
-
Xpresskit : XK05-PKT2 or Bypasskit :PKT2
-
One 5-wire relay for auto lamp circuit
Key required for programming: 1
Average installation time: 2.5 hours
Difficulty level: Medium
2.0 Preparation:
-Remove the driver's side under dash, as well as the knee airbag bolts. Move the Airbag
aside, but DO NOT DISCONNECT the Airbag connector in order to avoid setting any
vehicle codes.
-Remove the driver's side floor heating duct, in order to access the vehicle IMI & IMO
wires easily.
3.0 Installation:
Advertisement
Table of Contents
Related Manuals for Toyota 2007 Camry
Summary of Contents for Toyota 2007 Camry
- Page 1 Remote Starter Integration for the 2007 Toyota Camry equipped with the Smart Key System with Push Button Start 1.0 Material required: Remote Car Starter Xpresskit : XK05-PKT2 or Bypasskit :PKT2 One 5-wire relay for auto lamp circuit Key required for programming: 1 Average installation time: 2.5 hours...
- Page 2 The remote car starter will be installed in a conventional manner even if the car is equipped with the Smart Key “Push-to-Start” system. 3.01 Main Ignition Harness Connection: Most of the connections will be done behind the Fuse box. This fuse box is located under the driver side underdash.
- Page 3 3.02 Wiring location for the Bypasskit XK‐05 PKT2: The connection for the XK05-PKT2 will be done on the driver side under dash. The wires required are from a 5 wires harness coming from behind the heater module, high above the gas pedal near the firewall. The five wires in this harness are as follows: Blue: transponder IMI (Immobilizer in) wire, which gets cut in two and wired in series.
- Page 4 3.03 Wiring location for door locks and factory alarm control: The wires to control the factory alarm and the door locks are located behind the driver’s kick panel. These wires must receive negative pulses. It is mandatory to disarm the OEM alarm system before remote start sequence Grey Unlock Wire: A double pulse unlock (-) output is required to disarm and unlock all doors.
- Page 5 The wires to control the parking lights and the Auto lamp circuit are located at the light switch on the steering column. Parking Lights (-): Black Auto Lamp Circuit (+): GREEN - With the use of a relay, opening the AUTO LAMP circuit momentarily ensures the vehicle’s head lamps do not stay on after remote start shut- down sequence.
- Page 6 3.05 Final Connections: You now have to hook up all of the remaining wires required for the remote start. -Brake input -Ground wire -The antenna 4.00 Programming of the PKT2: 1- Connect the module 2- Turn the vehicle to the ignition position 3- The LED flash once 4- Start the vehicle.
