MIURA EX BOILER
170/250 PSI Designs
ENGINEERING
ENGINEERING
&
&
INSTALLATION
INSTALLATION
C
®
®
MANUAL
MANUAL
APPROVED
®
EX - HIGH EFFICIENCY SERIES
MIURA BOILER WEST, INC.
* IN OUR CONTINUING EFFORT TO IMPROVE OUR PRODUCT,
INFORMATION IN THIS MANUAL MAY BE CHANGED WITHOUT NOTICE
OWNER SHALL MAINTAIN THIS MANUAL IN LEGIBLE CONDITION FOR FUTURE REFERENCE
PUBLICATION REVISED MARCH 2000
ENGINEERING REVISED FEBRUARY 2000
