- Page 1 Cooling Cabinet / Freezer Combination INSTRUCTIONS FOR INSTALLATION AND USE This instruction for installation and use must be read before starting to install and use the appliance...
-
Page 2: Table Of Contents
Table of Contents SAFETY PRECAUTIONS ............ 3 STIPULATIONS FOR USE..........3 SAFETY INFORMATION ............. 4 INSTALLATION ..............4 Location ................ 4 Electric connection ............5 Balancing and locking the castors ....... 6 Prevention of tilting............6 Fitting the bottom front plate ........6 Fitting the cooling cabinet shelves ....... -
Page 3: Safety Precautions
Safety precautions Stipulations for use In connection with installation, it is essen- The regrigerator-freezer combination is tial to fix a tilting guard also. suitable for cooling and freezing of food- stuffs. When cleaning the appliance, switch off the voltage using the main switch and re- It is intended for use in households. -
Page 4: Safety Information
Situate the appliance to a dry, very well the electric socket ventilated room. • ventilate the room for several minutes Do not situate the cabinet in the imme- • contact the Festivo-service organi- diate vicinity of a radiator, stove or other zation. heat source. -
Page 5: Electric Connection
A suitable place for the socket is in the The floor cover can also be ordered from back wall at the location of the refrigera- Festivo-service. tor, at a height of 2060 mm from the floor to the lower edge of the socket. The... -
Page 6: Balancing And Locking The Castors
BALANCING, AND LOCKING THE FITTING THE BOTTOM FRONT PLATE CASTORS Fix the bottom front plate in place. The Push the appliance into place. The front plate sticks onto the bottom part appliance must be installed at the same by means of clamps (B). level as the surrounding floor surface. -
Page 7: Fitting The Cooling Cabinet Shelves
FITTING THE SHELVES If the seal has become pressed down, warm it CAREFULLY with a hot-air blower The cooling cabinet has 4 shelves as (hair dryer) and mould it with the fingers standard equipment. Put the left-hand to make it higher. edge of the shelf into the groove provided for it. -
Page 8: Functional Description
In the cooling cabinet, ice formed on the Functional description expansion coil melts automatically and the resulting water is conducted to the evaporation trough in the compressor FUNCTIONING OF THE COOLING area, from which it evaporates auto- MECHANISM matically. The cooling mechanism consists of the compressor, the condenser and the ex- AIR CIRCULATION pansion coil;... -
Page 9: Switches And Thermostats
Switches and thermostats Main switch ( I ) This switches on the voltage for the appliance. Red indicator expresses wich C -button Guide Display Main switch (I) compartment is in refrigerator (not buttons) the display F -button freezer Adjusting the fresh storage temperature If it is desired to alter the temperature, this can be done by turning the thermostat... -
Page 10: Using The Appliance
Using the appliance Switching off Before using the appliance, clean its inte- Switch off the appliance using main rior parts, following the instructions on p. switch (I). Do not start to use the appliance imme- If the appliance remains unused during a diately after transportation or after it has long period, then take the plug out of the been kept in a cold place, but let it stand in... -
Page 11: Adjusting The Temperature
Adjusting temperature Speedy cooling Actual temperature in the refrigerator/ ACTIVATION OF SPEEDY COOLING freezer = display doesn't flash (refrigerator) Set point in the display = display flashes The refrigerator can be activated to Factory set point: operate for 4 hours at a temperature Refrigerator +5°C colder than the set value (at about +2...+3... -
Page 12: Sounds Produced During Operation
Activating the function: Storage of foodstuffs Press the F-button of the display enough times so that the text SF appears on the COOL STORAGE screen; this text stays on the screen The internal temperature of the cooling throughout the speedy freezing period. cabinet has been adjusted at the factory During speedy freezing, neither the set to +5 ºC. -
Page 13: Frozen Storage
FROZEN STORAGE Frozen foods can be stored at all levels of the freezer. The length of time that they will keep depends on the type of foodstuff. (If frozen foods are kept for longer than the maximum period allo- wed, their quality will deteriorate.) PUTTING FOODS IN THE COOLING CABINET / FREEZER Allow warm foods and drinks to go cold... -
Page 14: Example Of Arrangement
EXAMPLE OF ARRANGEMENT Freezer: Cooling cabinet: Temperature -16 ... -24 ºC. Temperature +2 ... +7 ºC. The upper three shelves of the free- The upper two shelf levels of the cooling zer are intended for freezing of cabinet are, for instance, suitable for sto- foodstuffs. -
Page 15: Freezing
2 If the quantity to be frozen is the same Freezing as that stated as the freezing efficiency per day (max. 18 kg at a time), then Freezing takes place on the top three allow the mechanism to go through one shelves of the freezer compartment. -
Page 16: Cleaning
Cleaning CLEANING THE COOLING CABINET Stop the mechanism of the cooling cabi- net using the operating switch ( C ), for the period during which the interior surfa- ces are being cleaned. Press the C-button until the display flas- hes. Then press enough times until the text OFF appears on the display. -
Page 17: Cleaning The Freezer
CLEANING THE FREEZER • Because the freezer door is open a little during defrosting, ice melting from It is advisable to always do the cleaning of the evaporator may cause splashes the freezer part in connection with onto the floor in front of the freezer. For defrosting. -
Page 18: Functional Disorders
CORRECTING MINOR DISORDERS long-life 3 W LED-light. If the light doesn't work, please contact All functional disorders do not necessarily the Festivo-service organization. require the help of service personnel. So check first whether you can eliminate the The freezer displays excess tempera-... -
Page 19: Error Messages
Cooling cabinet You can try to stop the appliance for a while. E1 + sound signal = sensor fault Please contact the Festivo-service Acknowledge and stop the sound signal organization. by pressing the C-button of the display. E1 will remain on the display. -
Page 20: Disposal Of The Appliance
Disposal of the appliance DISCARDED COLD STORAGE APPLIANCES ARE HAZARDOUS WASTE By a law amendment that came into force on 1st January 2002, discarded cold storage appliances are classed in the whole EU area as hazardous waste. Warning! Do not damage the cooling unit! Especially the pipes are not allowed to da- mage because otherwise the refrigerant and oil of the cooling unit will get to the... - Page 22 Suomen Kotikylmiö Oy, Ravitie 3, 15860 Hollola, FINLAND Tel. +358 (0)3 553 8600, fax +358 (0)3 553 8668 www.festivo.fi...
