Installation and operation manual
CITYCOLD
Rev 072023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CITYCOLD 072023 and is the answer not in the manual?

Questions and answers

Related Manuals for Festivo CITYCOLD 072023

Summary of Contents for Festivo CITYCOLD 072023

  • Page 1 Installation and operation manual CITYCOLD Rev 072023...

  • Page 3: Table Of Contents

    Contents Intended use Models Reception Before using the appliance Precautions Installation Buttons on the control panel and indicator lights on the display screen Switching on Switching off Review of temperature setting values Temperature control: C refrigerator drawer Temperature control: F freezer drawer Automatic defrosting Additional manual defrosting Interior light...

  • Page 4: Intended Use

    Festivo refrigeration equipment has been designed and tested in accordance with current regulations and regulations. Festivo refrigerator may only be serviced by an authorized service company. Unqualified repairs can be a danger to the user or environment of the device.

  • Page 5: Before Using The Appliance

    • turn off power to the appliance from the main switch • unplug the appliance from the socket • air the room for several minutes • contact the Festivo service center Note! Keep the air circulation vents free of obstacles both up and down.

  • Page 6: Installation

    In the case of a malfunction of the unit some water can be spilled onto the floor. We recommend installing a protective basin, which is available at Festivo service. Alternatively, the location of the appliance can be made watertight in other ways. A watertight base will be raised up onto the wall so that the possible leakage water cannot enter the structure via the floor or wall joints.
  • Page 7 Plinth vent installed in the kitchen plinth Ensure sufficient condensing air circulation if the Festivo appliance vent is replaced with a separate plinth vent. I install a separate plinth vent on the upper left edge of the kitchen plinth, so that the air circulation is as unobstructed as possible.
  • Page 8 ATTACHING THE DEVICE TO THE BOTTOM SURFACE OF THE TABLE TOP OR TO AN ADJACENT FURNITURE The device comes with mounting angles for the front edge. Attach the device with a screw from both upper corners to the underside of the work surface or to the adjacent piece of furniture. ADJUSTING AND FIXING THE FRONT PLATE OF THE DRAWERS PICTURE 1 PICTURE 2...
  • Page 9 574 (Citycold 600) / 774 (Citycold 800) PICTURE 5 APPLIANCE PROTECTIVE BASIN Note! Always install a protective basin under the appliance. Alternatively, the location of the appliance can be made watertight in other ways. A watertight base will be raised up onto the wall so that the possible leakage water cannot enter the structure via the floor or wall joints.

  • Page 10: Buttons On The Control Panel And Indicator Lights On The Display Screen

    POWER CONNECTION Connect the refrigerator-freezer power cord to a single-phase 230 V 50 Hz socket. The fuse size of the socket is 10 A. Only an electrician may make changes to the connection method or change the connection lead. Note! The socket must be positioned in such a way that it is possible to pull the appliance’s plug from the socket without having to move the appliance.

  • Page 11: Switching On

    INDICATOR LIGHTS ON THE DISPLAY SCREEN On the screen The indicator light is on The indicator light is flashing The operating terminal is in OFF mode. The indicator light flashes briefly when the operating terminal is switched on or off by pressing its own power button Displays the temperature of the C refrigerator drawer.

  • Page 12: Switching Off

    Switching off Switch off the appliance using the main switch The appliance refrigeration circuit can be switched off separately. Push the display main switch until the display turns off. Review of temperature setting values RECOMMENDED FACTORY SET TEMPERATURE VALUES: C refrigerator drawer +5 °C, the temperature may be set to +4...+8 °C F freezer drawer -18 °C, the temperature may be set to -18...-20 °C The key lock is automatically activated if the buttons on the screen are not touched for 30 seconds.

  • Page 13: Temperature Control: C Refrigerator Drawer

    Temperature control: C refrigerator drawer When the controller is in the temperature set value review phase for the refrigerator drawer, press , and the set value will start flashing, and you can adjust the temperature by pressing Press the button to confirm the change.

  • Page 14: Storing Foodstuffs

    Storing foodstuffs Note! There is a fan behind both the refrigerator and freezer drawers on the rear interior wall. Please ensure the unobstructed operation of fans. C REFRIGERATOR DRAWER AND INNER DRAWER +4...+8 °C Inner drawer The internal temperature of the refrigerator drawer has been set at the factory to +5 °C.

  • Page 15: Cleaning

    Cleaning CLEANING THE REFRIGERATOR AND FREEZER DRAWERS The insides of the refrigerator-freezer should be cleaned and defrosted approximately once every six months. Turn off the main power switch for cleaning. Where necessary, store food supplies in another cold storage space. Note! The main power switch switches off both the refrigerator and the freezer drawer.

  • Page 16: Normal Sounds Of The Appliance

    Normal sounds of the appliance The appliance uses the compressor-operated refrigeration system for cooling. The system makes sounds of varying levels and they can increase especially during the defrosting phase. The volume of the noise is also affected i.e. by the materials in the environment where it is placed (e.g.

  • Page 17: Malfunctions And Repairing Small Faults

    When defrosting large amounts it should be ensured that the evaporator dishes at the appliance base will not overflow onto the floor. Refrigerator-freezer LED lights: The appliance has LED lighting with a long life cycle. In the event of a failure please contact Festivo service.
  • Page 18 • The freezer drawer has been left open. Switch on the additional defrosting function (where necessary, 2 times in succession). If the appliance capacity remains low even after this and the temperature is still high after 24 h of defrosting, please contact the Festivo service. Alarms...

  • Page 19: Service

    SERVICE CALLS IN FINLAND Service of products manufactured by Suomen Kotikylmiö Oy in Finland is done by Festivo Service Tel. (03) 553 8681 huolto@festivo.fi A service call to that number by a client of Suomen Kotikylmiö Oy will be connected to a service center closest to...

  • Page 20: Warranty Conditions In Finland

    Warranty conditions The export sales warranty period for the raw material and components is one (1) years if not agreed otherwise. The warranty applies to the equipment sold to the first buyer, i e goods have left the factory. The warranty does not cover wear and conditions caused by normal use or the batteries of the appliance.

  • Page 21: Notes

    Notes...
  • Page 22 Notes...
  • Page 23 Notes...
  • Page 24 Festivo is a genuine Finnish Key Flag product. The Festivo logo on the front panel of your refrigerator is, therefore, a promise of Finnish quality that is generated by decades of experience, strong materials and the structures and solutions found to work over time.
