- Page 1 Installation and operating manual Refrigerators, freezers and wine storage appliances Rev 082023 Rev 062023...
-
Page 3: Table Of Contents
Table of contents Table of contents Intended use Models Acceptance Before using the appliance Precautions Installation Operation principle of the appliance Switches and thermostats: refrigerator and freezer Switches and thermostats: wine storage appliance Switching on Switching off Temperature adjustment: refrigerator and freezer Button lock and unlock Freezing Temperature adjustment: wine storage appliance... -
Page 4: Intended Use
Festivo refrigeration appliances have been designed and tested in accordance with the rules and regulations in force. Festivo refrigeration appliances can be serviced only by an authorized service center. Repairs by unqualified persons can endanger the user of the appliance or the environment. -
Page 5: Precautions
• turn off power to the appliance from the main switch • unplug the appliance from the socket • air the room for several minutes • contact the Festivo service center Note! Keep the air circulation vents free of obstacles both up and down. -
Page 6: Installation
Installation PLACEMENT The intended environmental temperature classification has been indicated on the appliance nameplate. The nameplate is situated on the right inner wall of the refrigerator. +10 ... +32 °C +16 ... +32 °C +18 ... +32 °C +18 ... +43 °C Place the appliance in a dry and well ventilated room with a size of at least 8 m². - Page 7 The refrigerator freezer can be placed touching the surfaces on the back and sides. In case the Festivo appliance’s side surface is next to another cooling unit or outer wall, a ventilation gap of 10 mm width should be left in between the surfaces.
- Page 8 120 cm wide appliances: Turn the adjusting foot in the middle in such a way that it touches the floor. INSTALLING FRONT PANEL OF THE PLINTH Mount the front panel of the plinth to its place.
- Page 9 CONNECTING APPLIANCE COMBINATIONS OF 100 CFM AND 120 CFM TO EACH OTHER EXTENSION ACCESSORY PACKAGE INCLUDES: (additional equipment to individually sold modules of 55 CM, 75 CM, 45 FM and 45 VLM) 1. Aluminum profile for in between the frames 2.
- Page 10 BALANCING AND LOCKING THE WHEELS Adjust the appliances to the same level with adjustment screws A and fasten the wheel locking screws C. The work requires a 10 mm spanner. FRONT PLINTH FASTENER (4) Mount the plinth fastener to the lower edge of the plinth.
- Page 11 MOUNTING SHELVES (DOUBLE DOOR REFRIGERATOR MODELS 90, 100 AND 120 CM) Adjust shelve brackets to desired height. Slide the flanges of the back side bracket (A) to the pin slots at the back of the cabinet. Shelf bracket Lower flanges of the front side bracket (B) to the pin slots at the middle of the cabinet.
- Page 12 MOUNTING SHELVES RIGHT RIGHT WRONG WRONG...
- Page 13 DOOR ADJUSTMENT: REFRIGERATOR, FREEZER, AND WINE STORAGE APPLIANCE 45 VLM During the initial installation of a new device, there is usually no need to adjust the doors, because the doors are adjusted at the factory. If the doors need to be adjusted when connecting the devices, it may be due to the unevenness of the floor.
-
Page 14: Operation Principle Of The Appliance
Switches and thermostats: refrigerator and freezer The refrigerator CM and freezer FM have one temperature controller. Freezer cabinet CFM has two temperature controllers; one for the refrigerator and the other for the freezer. Main switch (switches the voltage for the appliance) -
Page 15: Switches And Thermostats: Wine Storage Appliance
Switches and thermostats: wine storage appliance Main switch (switches the voltage for the appliance) Light switch Cabinet temperature controller Switching on Do not start to use the appliance immediately after transportation or after it has been kept in a cold place, but let it stand in its final location for a few hours so that the oil has time to flow down into the compressor. -
Page 16: Switching Off
Switching off Switch off the appliance using the main switch (1) The appliance compressor can be switched off separately. Press display power button until the display switches off. Temperature adjustment: refrigerator and freezer FACTORY SET RECOMMENDED TEMPERATURE VALUES • refrigerator +5 °C •... -
Page 17: Button Lock And Unlock
Button lock and unlock • Press simultaneously buttons at least for three seconds. The text ‘PoF’ will display when the keys are locked. If the keyboard is locked it is impossible to adjust the temperature or switch of the power of the unit. •... - Page 18 CABINET LOWER PART TEMPERATURE (ONLY VLM 45) The temperature in the cabinet’s lower part cannot be adjusted separately with the temperature controller but the temperature of the lower part will be adjusted by plastic adjustment sheets (A) under the shelve. The adjustment sheets you can adjust the temperature difference between the top and lower parts at a maximum of approx.
-
Page 19: Normal Sounds Of The Appliance
Normal sounds of the appliance The appliance acquires its coldness from the compressor operated cooling system. The system makes sounds of varying levels and they can increase especially during the defrosting phase. The volume of the noise is also affected i.e. by the materials in the environment where it is placed (e.g. stone floors), the manner of positioning the appliance, the way it is used and its age. -
Page 20: Storing Goods
Storing goods COLD STORAGE (CM AND CFM MODELS) The factory setting of the refrigerator inside temperature has been set to +5 °C. The temperature may vary by several degrees from the set value in different parts of the refrigerator. The relative air humidity in the cabinet is about 70-90%. - Page 21 Adjustment of NOLLA box temperature: Above the NOLLA box, at the rear edge of the intermediate bottom, is a control valve (A) that is closed (B) at the factory. When you move the valve control plate (C) to the left, the valve opens and the NOLLA box temperature drops.
- Page 22 Door lockers: Door Door lockers are best suited for storing products that are Freezer Refrigerator lockers light and used daily. Keeping heavy products in the door lockers will strain the hinges. Refrigerator: Temperature can be adjusted to +2 ... +7°C. The temperature set in the refrigerator thermostat is the average temperature of the cabinet.
- Page 23 FREEZING Note! Before the freezing process is started, the foods already in the freezer are cooled down further to prevent them warming up too much, due to the effect of the products being frozen. The freezer may be set to operate in freezing mode for six hours. The function is used when over 2kg of goods are frozen.
-
Page 24: Cleaning
Cleaning REFRIGERATOR AND WINE STORAGE APPLIANCE CLEANING Clean inside the refrigerator and wine storage parts at least once a year. Clean also the condenser at the back. Switch off refrigerator engine for the cleaning of inside surfaces. Press display power switch . - Page 25 To remove the freezer basket, first pull it to its outer position, then lift the front edge upward, and pull the basket out. Leave the freezer door 1 cm open. You can place for example a towel onto the bottom of the freezer to absorb any water dripping down the walls.
- Page 26 DOOR LOCKER AND DRAWER REMOVAL AND CLEANING The door lockers can be removed for cleaning by lifting them upwards, causing it to detach. The door compartments can withstand machine washing. You can remove the HEVI, KYLMÄ and NOLLA drawers for cleaning. First pull out the drawer completely. Remove the covering plugs A carefully with a chisel like object (e.g.
- Page 27 REMOVAL OF INSERT TRAYS (55 CM, 75 CM) You can remove the bottom insert trays in the 55 CM and 75 CM refrigerators when cleaning. Lift the insert trays upwards from the back edge. Pull the shelve out carefully. Warning! Do not pull the shelve from the front edge because the back edge can distort.
-
Page 28: User Maintenance
User maintenance Note! Empty out the cooling appliance, switch it off from the power switch and unplug it from the socket during cleaning and other maintenance operations. Appliance combinations have separate power switches and plugs. ENGINE CLEANING Remove the front panel of the plinth and open the wheel locks. -
Page 29: Malfunctions And Repairing Small Faults
Refrigerator inside light: The refrigerator has a long life led lighting. In the event of a failure please contact Festivo service. The freezer notifies of excess heat (HA). Check first if: • The freezer has een filled with too many products to freeze without freezer function Freezing goods temporarily rises the temperature inside the freezer, which may trigger the temperature alarm. -
Page 30: Error Messages
Please contact Festivo service HA = high temperature alarm Please see first chapter ‘Malfunctions’. Please contact the Festivo service in case the above mentioned points are in good order and the appliance does not begin to cool within two hours. -
Page 31: Service
SERVICE CALLS IN FINLAND Service of products manufactured by Suomen Kotikylmiö Oy in Finland is done by Festivo Service Tel. (03) 553 8681 huolto@festivo.fi A service call to that number by a client of Suomen Kotikylmiö Oy will be connected to a service center closest to... -
Page 32: Warranty Conditions
Warranty conditions The warranty period of our domestic appliances is two years starting from the purchase or delivery date. The warranty includes repairs reported to an authorized service center within the warranty period and confirmed by the warranty provider to faults due to structural, manufacturing and raw material failures and damages caused by those to the actual appliance free of charge. -
Page 33: Notes
Notes... - Page 34 Notes...
- Page 35 Notes...
- Page 36 Festivo is a genuine Finnish Key Flag product. The Festivo logo on the front panel of your refrigerator is, therefore, a promise of Finnish quality that is generated by decades of experience, strong materials and the structures and solutions found to work over time.
