Samsung RS2555SL Service Manual page 5

4. Specifications
ELECTRICAL SPECIFICATIONS
Defrost Control
Thermo-Bimetal
Defrost Thermistor(502AT)
Electrical Rating
Maximum Current Leakage
Maximum Ground Path Resistance 0.1 Ohm
Energy Consumption
NO LOAD PERFORMANCE
Ambient Temperature
Refrigerator,℉
Freezer,℉
Run Time,%
REFRIGERATION SYSTEM
Refrigerant Charge (R134a)
Compressor(MK183C-L2U)
Compressor oil
Capillary tube(Dia, Length)
Dryer
Dryer
Compressor
INSTALLATION
Clearance must be provided for air circulation
AT TOP
AT SIDES
AT REAR
From 24 to 32 hrs
54℉(off)/23℉(on)
50℉(off)
AC115V 60Hz, 4.8 Amps
0.25 mA
KWH/mo.
70℉ 90℉
34∼46 34∼46
-14∼8 -14∼8
40
7.76 oz
532.3 Btu/hr
Freol α-15
0.033＂ ＂ ,130＂ ＂
Molecular Sieve XH-9
C-Fan
Electric box
Sub-condenser
1＂ ＂
0.1＂ ＂
1＂ ＂
Freezer
Fan Fan Fan
60
Heat exchanger Heat exchanger Heat exchanger Heat exchanger
(Air inlet) (Air inlet) (Air inlet)
MODELS
RS2533(Good), RS2555(Better), RS2577(Best)
REPLACEMENT PARTS
Main Board(RS2533)
Main Board(RS2555,2577)
Thermistor(Freezer)
Thermistor(Freezer Evaporator)
Thermistor(Refrigerator)
Thermistor(Refrigerator Evaporator) DA32-00006B
Thermistor(Ambient)
Thermistor(CoolSelect Zone
Thermistor(Ice-Maker)
Thermo-Bimetal
Relay
Overload Relay
Run Capacitor (12㎌)
Fan-Motor(FRE)
Fan-Motor(REF)
Fan-Motor(REF)
Fan-Motor(Condenser)
Thermal Fuse
5
Refrigerator
Fan Fan Fan
(Air inlet) (Air inlet) (Air inlet)
DA41-00139A
DA41-00107A
DA32-10109W
DA32-00006A
DA32-10105U
DA32-10109V
TM ) DA32-10109X
DA32-10108B
DA47-10160E
DA35-10013Q
DA34-10003D
2501-001045
DA31-00020E
DA31-00002S(RS2533)
DA31-00020E(RS2555/2577)
DA31-00020H
DA47-00095C
