- Page 1 PHARE 30/50W Ni-MH Ni-MH LIGHT 30/50W / SCHEINWERFER 30/50W Ni-MH FARO 30/50W Ni-MH Réf. 342 129 ED. 10/2005...
- Page 2 Handle Réflector Charger Bulb Câble of charge Switch...
- Page 3 Index General presentation Technical description Charging Discharge Bulb replacement Maintenance Storage / After sale service / Warranty...
- Page 4 18 > User guide / Presentation General presentation Technical description The “Light Beuchat 30-50 W” has been developed and The “Light Beuchat 30-50 W” is composed of : made with the most sophisticated techniques and mate- • a body cavity which contains the batteries and the elec-...
- Page 5 Technical description / User guide > 19 Light with 30 W bulb Main-body : Anodized aluminium structure. Bulb : High luminosity 30 W Halogen G. 6,35. Reflector : Anodized aluminium multifaceted. Ref : 42305 Color Temperature : 3200°K Lens : Toughened glass with thermic quality. Luminous flow : 750 lumens Range of utilization : 30 W / 1H 40mn.
- Page 6 20 > User guide / Use To turn on and turn off, use the rotating switch placed on the rear flange. This rotating switch works on a magnetic system placed Red indicator Lock button of discharge inside the main-body, without soaking through the case, providing for complete life time waterproof seal.
- Page 7 Technical features of the fast battery charger / automatic. Red indicator The battery charger is specifically designed for the ”Power supply” “Beuchat 30 - 50 W Ni-MH Light”. Specific features allow the Light charger to obtain best Orange performances with maximum safety.
- Page 8 22 > User guide / Charging Power selector CAUTION : Before using the power, check the “voltage” posi- tion 115 V / 230 V , according to supply voltage. The use of this charger is limited (see waranty) to the connection on power supply with the specifications as below : Type : Sinusoïdal alternative...
- Page 9 Charging / User guide > 23 How to proceed the charging of Light Check for proper position of the button “Charge - OFF”. Open the Light by unscrewing the reflector. Connect the charger plug with the “charge” outlet pla- ced beside the bulb. Plug the charger plug.
- Page 10 Discharge not proceed to any charge if the temperature of the light The life of the “Light Beuchat 30-50 W” is based on the func- is over 30°C (88 °F) or lower 10°C (36°F). tion of the bulb used (see technical features).
- Page 11 Discharge / User guide > 25 During diving : When the red indicator, placed at the rear, begins to flash the light is ending and the internal electronic protective circuit shuts off automatically the light to prevent any Red indicator of discharge damage to the batteries.
- Page 12 26 > User guide / Bulb replacement Control before diving : Bulb replacement The reflector must be completely secured (without exces- How to proceed with the replacement of the bulb : sive screwing). The safety button must be on its locked position (left). Make sure the rotating switch is in the off position Turning on the Light a few seconds, the red indicator “Charge - OFF”.
- Page 13 Maintenance / User guide > 27 CAUTION : Do not touch the bulb with fingers. If so, clean it with a an alcohol soaked cloth and allow it to eva- waterproof porate, before trying the bulb. Maintenance After each dive, rinse the Light with fresh water and clean it with a soft cloth, before opening to charging.
- Page 14 To benefit from the present warranty, the pro- Contact BEUCHAT Dealer or Service Center prior to ship- duct must be returned along with proof of purchase. ping, to optain a return authorization number.
- Page 15 Notes .........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 16 Notes .........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 18 BEUCHAT INTERNATIONAL S.A. - 34, Av. Boisbaudran 13015 Marseille - FRANCE Tél. : +(33) (0)4 91 09 44 60 / Fax : +(33) (0)4 91 60 70 00 e-mail : info@beuchat.fr - Web : www.beuchat.fr Réf. 43406...
