M3 Single-Slot Cradle User Guide Cradle Model: A-1CR-U002-040-R00, A-1CR-U00D-040-R00, A-1CR-US02-110-R00, A-1CR-U0ED-110-R00 Compatible Device: M3 RED, GREEN and SKY Version 2.3 Released in March 2013...
Copyright and Agreement in Usage All contents of this user manual are protected by the Microsoft, Windows, MS Office, Outlook, ActiveSync, copyright laws, and M3 Mobile Co., Ltd. owns all rights Internet Explorer, Windows Logo, and Windows CE, related to them.
Notice – General Notices The contents of this user manual were made based on the M3 Mobile does not guarantee the quality of the programs “current state” of the product, and this manual may produced by third party software companies installed after contain technical and editing errors or omissions.
Page 5
Notice – Revision History Version 2.3 – March, 2013 Change address and M3 Mobile technical support webpage Version 2.2 – Jan 17, 2011 Ethernet Cradle (A-1CR-U0ED-110-R00) manual is merged. Version 2.1 – Jan 14, 2011 Models added: A-1CR-U00D-040-R00, A-1CR-US02-110-R00 ...
If the device is lost or stolen, then immediately report the incident to the service provider. Refrain from using the device while driving. When service for the product is required, request services through the designated service center of M3 Mobile.
Page 7
Warnings and Cautions for Safety – Cntd. Cautions in Carrying and Storing Do not modify the product Do not use the product in high temperature or high Do not try to modify the product by any means. humidity environments as this may quickly cause damage to the product.
Power Supply USB Cable If you don’t have everything, contact your supplier immediately. Note that the power supply connector type may different to the picture depending on the cradle model. Serial cables and Ethernet cables are not provided from M3 Mobile.
(left side of the cradle) feature. RS232 Port will appear here on A-1CR-US02-110-R00 Description 5. USB Port Refer to next images (A-1CR-U002-040-R00) for Single-Slot Standard Cradle parts and descriptions. 6. USB Host/Client 7. Power Connector Toggle Switch (24 Pin shown)
Page 10
2. Usage – Description continued. 1. Device Slot – A PDA slides into the slot for charging, data transfer or ActiveSync Charging LED description connection. LED Color Meaning 2. LED Charging Indicator – Charging status of an spare battery is displayed. Refer to No. The spare battery is being charged.
2. Usage – Specification Model A-1CR-U002-040-R00 A-1CR-U00D-040-R00 A-1CR-US02-110-R00 A-1CR-U0ED-110-R00 Compatible PDA(s) M3 RED, GREEN and SKY Charging LED Red - Charging (Extra battery only) Green - Fully charged Spare Batt. Slot Charging Slot (2200mAh Battery, 4.2V/1A) Adapter Input...
Page 12
2. Usage – Specification Ethernet Specification Ethernet Port LED Description RJ-45 Ethernet Port LED Color Meaning IEEE 802.3/802.3X 10Base-T / 100Base-Tx compliant Flashing GREEN Accessing to the switch/hub. IEEE 802.3x flow control Solid GREEN Connection is established. ...
PDA. Caution 1. Use the correct AC adapter with 5.2V, 3A output provided by M3 Mobile. 2. Incongruent change of battery can cause the explosion. 3. When attached battery is completely discharged, plug charger to main body, then reset the device to check if the...
3. FAQ and Troubleshoot – PC Connection PC Connection Q1. How to connect to PC Q2. PDA is not recognized in ActiveSync or Mobile Device Center. M3 cradle product range support charging and USB connection. You must have Microsoft ActiveSync or A2-1.
3. FAQ and Troubleshoot – Serial Comms. Serial Communication Q1. Cannot use serial communication through Q2. Can Serial communication and ActiveSync be cradle. What should I check? used simultaneously? A1-1. Check if the serial cable is properly connected on A2-1. No.
3. FAQ and Troubleshoot – Ethernet Ethernet Static IP Configuration Q1. Cannot use Ethernet Windows Mobile A1-1. Check if the LAN cable is properly connected to the cradle and LAN output port AND AC power supply is connected. A1-2. Check if the E/U toggle switch is switched to E (left). A1-3.
Page 17
3. FAQ and Troubleshoot – Ethernet Ethernet Continued. Note Ethernet connection is only available in A-1CR-U0ED-110-R00 model. Q2. Can Wi-Fi be used after the PDA is taken from the cradle? A2-1. Yes, Wi-Fi can be used if WLAN is turned on and correctly, configured.
Services and Support Should you require any services or technical support on M3 Mobile’s products, contact your supplier or visit M3 Mobile technical support webpage http://itc.m3mobile.net. Desired or relevant manuals can be downloaded from Knowledge Center or FAQ in technical support webpage.
