MICRO COMPONENT SYSTEM UX-S59 —Consists of CA-UXS59 and SP-UXS59 INSTRUCTIONS LVT1358-001A... - Page 2 IMPORTANT for the U.K. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer.
- Page 3 Caution: Proper Ventilation To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows: 1. Front: No obstructions and open spacing. 2. Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below. 3.
-
Page 4: Safety Instructions
“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT” This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. Do read the operating instructions before you attempt to use the equipment. -
Page 5: Table Of Contents
Contents Introduction... 2 Precautions... 2 How to Read This Manual... 2 Getting Started ... 3 Step 1: Unpack... 3 Step 2: Prepare the Remote Control ... 3 Step 3: Hook Up ... 4 Before Operating the System ... 7 Daily Operations—Playback... 8 Listening to the Radio... -
Page 6: Introduction
Precautions Installation • Install in a place which is level, dry and neither too hot nor too cold—between 5°C and 35°C. • Install the System in a location with adequate ventilation to prevent internal heat buildup inside the System. DO NOT install the System in a location near heat sources, or in a place subject to direct sunlight, excessive dust or vibration. -
Page 7: Getting Started
Step 1 :Unpack the package and check the accessories. Step 2 : Prepare the remote control. Step 3 : Hook up the components such as AM/FM antennas, speakers, etc. (see pages 4 to 6). L O O Finally plug the AC power cord. Now you can operate the System. -
Page 8: Step 3: Hook Up
Step : Hook Up If you need more detailed information, see page 6. Illustrations of the input/output terminals below are typical examples. When you connect other components, refer also to their manuals since the terminal names actually printed on the rear may vary. - Page 9 FM antenna (supplied) Extend it so that you can obtain the best reception. E X T L O O P G N D AM loop antenna (supplied) Turn it until the best reception is obtained. Black striped Non-striped...
- Page 10 To assemble and connect the AM loop antenna To assemble the AM loop antenna To connect the AM loop antenna Make sure to connect the wire correctly: The white end to AM EXT, the black end to GND. 1 Hold 2 Insert •...
-
Page 11: Before Operating The System
Before Operating the System The indications on the display teach you a lot of things while you are operating the System. Before operating the System, be familiar with when and how the indicator illuminates on the display. SOUND TURBO AHB PRO PRGM RANDOM TA News Info... -
Page 12: Daily Operations-Playback
Daily Operations Numeric buttons 4/1, 7,¡/¢ Disc selection buttons FM MODE/ STANDBY/ON VOLUME —Playback Turn on the power. The STANDBY lamp on the main unit turns off. • Without pressing STANDBY/ON turns on by pressing one of the source selecting buttons in the next step. -
Page 13: Listening To The Radio
Listening to the Radio To select the band (FM or AM) To tune in to a station While FM or AM is selected... Remote control: Main unit: sec. DOWN Frequency starts changing on the display. When a station (frequency) with sufficient signal strength is tuned in, the frequency stops changing. -
Page 14: Playing Back A Disc
To tune in to a preset station Select a band (FM or AM). Select a preset number for the station you store. • You can also use the PRESET UP or PRESET DOWN. Playing Back a Disc This System can play back the following discs—regular CD and CD-R/CD-RW (recorded either in the audio CD or MP3 format). -
Page 15: Playing Back Other Equipment
For MP3 playback According to the MP3 playback mode, 4/1 / ¡/¢ or number buttons work for the group selection or the track selection. Examples: When the MP3 play back mode is “GROUP.” GR. (Group) indicator Total group number Total track number You can change the MP3 playback mode by pressing FM MODE/MP3. -
Page 16: Daily Operations
Daily Operations Remote control CLOCK/ TIMER 4/1, 7,¡/¢ DIMMER A.STANDBY SLEEP SOUND TURBO AHB PRO Main unit 4/¢ Adjusting the Volume —Sound & Other Adjustments Adjusting the Volume You can adjust the volume level from level 0 (VOL-MIN) to level 31 (VOL-MAX). Remote control: CANCEL VOLUME... -
Page 17: Changing The Display Brightness-Dimmer
Changing the Display Brightness You can dim the display window. DIMMER DIMMER-1 DIMMER-2 DIM OFF (Canceled) DIMMER-1 Dims the display illumination. DIMMER-2 Erases the display illumination. Setting the Clock Remote ONLY Without setting the built-in clock, you cannot use the Daily Timer (see page 19). -
Page 18: Advanced Radio Operations
Advanced Radio Operations Remote control SELECT +/– Receiving FM Stations with RDS Radio Data System (RDS) allows FM stations to send an additional signal along with their regular program signals. • When tuned to an FM station which provides the RDS service, the RDS indicator lights on the display. -
Page 19: Switching Temporarily To A Program Of Your Choice Automatically
Start searching. SEARCH Ex.: When “NEWS” is selected The receiver searches 30 preset FM stations, stops when it finds the one you have selected, and tunes in to that station. • If no program is found, “NOT” and “FOUND” appear alternately on the display. -
Page 20: Advanced Disc Operations
Advanced Disc Operations Remote control Numeric buttons CD 6 Disc selection buttons Main unit CD 1 / 0 Programming the Playing Order— Program Play You can arrange the playing order of the tracks (up to 32) before you start playback. •... -
Page 21: Playing At Random-Random Play
To check the programmed contents While the PRGM indicator is shown on the display and before playback... In the programmed order. In the reverse order. To modify the program While the PRGM indicator is shown on the display and before playback... To erase the last step: To erase the entire program:... -
Page 22: Playing Repeatedly-Repeat Play
Playing Repeatedly—Repeat Play You can repeat playback. For CD: REPEAT Canceled (No indication) For MP3 (Track mode): REPEAT Canceled (No indication) For MP3 (Group mode): REPEAT Canceled (No indication) Repeats the current track. Repeats all the tracks on the current disc. -
Page 23: Timer Operations
Remote control PRESET UP, PRESET DOWN Timer Operations Setting the Timer Using Daily Timer, you can wake up with music, etc. • You can store three Daily Timer settings; however, you can activate only one of Daily Timers at the same time. •... - Page 24 Make the timer setting as you want. 1 Set the hour then the minute for on-time. PRESET UP PRESET DOWN 2 Select the playback source—“TUNER FM,” “TUNER AM,” “CD,” or “AUX IN.” PRESET UP PRESET DOWN 3 For “TUNER FM” and “TUNER AM”: Select a preset number or “P –...
-
Page 25: Additional Information
Additional Information Learning More about This System Daily Operations—Playback Listening to the Radio: • If you store a new station into an occupied preset number, the previously stored station in that number will be erased. • When you unplug the AC power cord or if a power failure occurs, the preset stations will be erased in a few days. -
Page 26: Troubleshooting
Troubleshooting If you are having a problem with your System, check this list for a possible solution before calling for service. General: Adjustments or settings are suddenly canceled before you finish. There is a time limit. Repeat the procedure again. Operations are disabled. -
Page 27: Specifications
Specifications Amplifier section 120 W (60 W + 60 W) at 6 Ω Output Power: (10% THD) 6 Ω – 16 Ω Speakers/Impedance: Audio Input AUX: 400 mV/50 kΩ Tuner section FM tuning range: 87.50 MHz – 108.00 MHz AM (MW) tuning range: 522 kHz – 1 629 kHz CD player section Dynamic range: 85 dB... - Page 28 Main unit 9, 10, 16, 17 10, 16 8, 20 Remote sensor 8–10 DOWN DIMMER SOUND TURBO FM/AM STANDBY 5-CD 5-CD CHANGER, PLAY&EXCHANGE PHONES VOLUME 8, 12...
