Summary of Contents for ELSA Ecomo 750

  • Page 1 ELSA ECOMO ELSA ECOMO 750...
  • Page 2 ELSA. ELSA AG is a DIN EN ISO 9001 certified company. With the certificate of June 15, 1998, the authorized certification institute TÜV-CERT has confirmed the conformity of ELSA AG with the worldwide quality standard DIN EN ISO 9001.
  • Page 3 Thank you for placing your trust in this product. Thank you for placing your trust in this product. With the ELSA ECOMO 750 you have sel- ected one of ELSA's high-end monitors. ELSA products are subject to the highest of stan- dards in production and quality control which are the foundation for consistently high product quality.
  • Page 4 Preface ELSA ECOMO 750...
  • Page 5: Table Of Contents

    After switching on ....................19 Plug&play ......................19 Language......................19 Reset functions ..................... 20 An overview of all functions................. 22 An optimized working environment ................25 Monitor picture quality ..................25 Tips for an ergonomic working environment............25 ELSA ECOMO 750...
  • Page 6 Troubleshooting ......................31 Problem solving..................... 31 Restraining wires....................32 Appendix ........................33 TCO ’99 ........................33 Advice and help ....................36 Software updates .................... 36 Who to contact?....................36 ELSA-ServiceDirect for ELSA ECOMO monitors........... 38 Warranty conditions ..................... 39 ELSA ECOMO 750...
  • Page 7: Introduction

    (OSD) present all of the functions for setup and adjust- ment. The monitor complies with the safety standards UL 1950, CSA C22.2 No. 950 and EN60950, FCC Class-B, VCCI Class-B and EN55022 Class-B for EMI, MPR II, and with ELSA ECOMO 750...
  • Page 8: Package Contents

    Power cord and monitor cord CD including additional software and electronical documentation Please contact your dealer if any part is missing or damaged. ELSA reserves the right to make changes to the package contents without prior notice. ELSA ECOMO 750...
  • Page 9: Ce Conformity And Fcc Radiation Standard

    Caution to the user: The Federal Communications Commission warns the user that changes or modifications to the unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. ELSA ECOMO 750...
  • Page 10 Introduction ELSA ECOMO 750...
  • Page 11: Installation

    Do not on any account open up the appliance to carry out your own repairs. Very high voltages exist within the appliance, even when disconnected from the mains. Repairs should only be made by trained technicians. Please contact ELSA Services for any repairs.
  • Page 12: Connecting To The Computer

    With the monitor switched off connect the power cord supplied to the monitor and to the mains. The monitor automatically adjusts itself to the rated voltage (110V–230 V). Switch on The monitor is now connected to your computer and the mains. First switch on your mon- itor, then the computer. ELSA ECOMO 750...
  • Page 13: Connecting The Monitor To A Macintosh Computer

    Installation Connecting the monitor to a Macintosh computer Your dealer can supply you with a special adapter for connecting your ELSA monitor to Macintosh computers. The adapter is to be located between the computer's graphics output and the VGA connector cable. The DIP switches on the upper side of the adapter should be set according to the resolution with which your monitor will be operating.
  • Page 14: What Next

    The manual is supplied in printed form in the English and German languages. The versions in French and Italian are available in PDF-format on the CD. The Spanish/Dutch translation describes the installation only. If you require more infor- mation, please refer to the documentation in the other languages. ELSA ECOMO 750...
  • Page 15: Aspects Of Your Monitor

    Press this key to select the group icon in the main menu. Enter key Press this key to fix or to unfix the item icon. Setting keys The keys are used to move the cursor in the submenu and adjust the desired menu setting. ELSA ECOMO 750...
  • Page 16: Rear Connectors Panel

    Plug the cable carrying the signal from the graphics board to the monitor into this socket (second computer). Upstream ports To connect to USB equipped computers, please use the enclosed USB cable. Downstream ports To connect to USB equipped peripherals, e.g. USB camera, keyboard, printer, etc. ELSA ECOMO 750...
  • Page 17: Monitor Setup

    Monitor setup Monitor setup The ELSA ECOMO 750 supports USB and is provided with special software. In this chap- ter you will learn more about USB and how to set up the monitor under your operating system. The USB function under Windows What does USB stand for? USB stands for “Universal Serial Bus“...
  • Page 18: Checking For Usb Support

    System. In the Device Manager, view the list of devices available in the system. The Windows system Device Man- ager shows you whether the USB controller is installed or not. For further information on USB please refer to www.usb.org. ELSA ECOMO 750...
  • Page 19: The Usb Connection

    Digital camera Keyboard If you use the supplied USB cable to connect your computer and ELSA monitor, it is rec- ommended that you place the accompanying ferrous core around the cable. This core reduces the electromagnetic interference from the monitor which would otherwise det- rimentally effect the signal transmission.
  • Page 20: All Under Control

    ELSA monitor. USB monitor installation When you insert the supplied CD, the ELSA setup program usually starts up automati- cally. After you have specified the monitor type, you can select the component to be installed in the list and click on Install.
  • Page 21 An overview of the possible settings Brightness Contrast Position and size Display geometry and distortions – Parallelogram effect – Trapeze effect – Rotation (tilt) – Pincushion balance Press the Degauss button to remove magnetic distortions from the display. ELSA ECOMO 750...
  • Page 22 Monitor setup ELSA ECOMO 750...
  • Page 23: Operating The Monitor

    Press any button to display the OSD screen. Select the group icon within the main menu by pressing this but- ton . Select the item within the sub menu by pressing the button. To change the direction press the /– buttons simultaneously. ELSA ECOMO 750...
  • Page 24 Operating the monitor Adjust values and functions by pressing the +/– buttons. – After ten seconds of inactivity, the OSD screen automatically disappears. Press the OSD OFF button to switch the OSD off immediately. Signal A/B OSD OFF ELSA ECOMO 750...
  • Page 25: Monitor Settings

    Modern graphics boards and the ELSA ECOMO 750 can communicate using the DDC (Dis- play Data Channel). The ELSA ECOMO 750 can send its parameters to the graphics board and, in turn, the graphics board ensures that the monitor operates at the highest possible refresh rate for the resolution selected.
  • Page 26: Reset Functions

    H-SIZE Adjusts the horizontal size. H-PHASE Adjusts the horizontal position. V-SIZE Adjusts the vertical size. V-POSITION Adjusts the vertical position. PCC-AMP Straightens the left and right sides. PCC-PHASE Adjusts the parallelism of the left and right sides. ELSA ECOMO 750...
  • Page 27 VIDEO LEVEL Selects video level 1.0V or 0.7V. DEGAUSS Eliminates possible color shading – or impurity. POWER-SAVE Activates the power save mode. OSD CONTROL LOCK Locks the OSD function to prevent unwanted changes to your monitor settings. ELSA ECOMO 750...
  • Page 28: An Overview Of All Functions

    To narrow the width of the To expand the width of the image on the screen. image on the screen. H-PHASE To move the image on the To move the image on the screen to the left. screen to the right. ELSA ECOMO 750...
  • Page 29 V-CONVERGENCE To move the red down and To move the red up and the the blue up. blue down. MOIRE CANCEL To select the moiré cancel To select the moiré cancel mode off. mode on. ELSA ECOMO 750...
  • Page 30 ³ This locks the OSD function to prevent changes being made to your settings. Press the plus button to lock the OSD function. You can adjust only BRIGHTNESS and CONTRAST in this state. Press minus button to unlock the OSD. ELSA ECOMO 750...
  • Page 31: An Optimized Working Environment

    Equally important is the overall arrangement of your working environment, which includes some basic rules about working with a monitor. The ELSA ELSA ECOMO 750 complies with the latest EU ergonomics guidelines (90/270/ EEC) for work places with monitors, which came into effect on the 1.1.97.
  • Page 32: The Seating Position

    ”dynamic sitting”—and that you stand up once in a while. The monitor position The ELSA ECOMO 750 can be tilted and swiveled so that you can set up the monitor position to your liking. When swiveling or tilting, please support the monitor...
  • Page 33: Technical Data

    EMC (CE/FCC) EN 55022 Class B, EN 50082-1, EN 60555-2 X-radiation German X-ray regulations dated 1987-01-08 Others TCO ’99, VESA DPMS, EPA Energy Star MPR II, ISO 9241-3 (certified by TÜV Ergonomie) ZHI/618, NUTEK Spec. 803299/94 ELSA ECOMO 750...
  • Page 34: Power Management Function

    Technical data Power management function The ELSA ECOMO 750 complies with the guidelines set by VESA and Energy Star together with the stringent standards of NUTEK. The ELSA ECOMO 750 will automati- cally reduce power consumption if the monitor is connected to a graphics board comply- ing with VESA DPMS.
  • Page 35: Video Input Connection To An Apple Macintosh Computer

    Video input connection to an Apple Macintosh computer Your ELSA monitor can be connected to a Macintosh computer. The graphics output port of the Macintosh has a 15-pin connector. To match up with the monitor’s VGA connector you require a suitable adapter. Contact your retailer for details.
  • Page 36 Technical data ELSA ECOMO 750...
  • Page 37: Troubleshooting

    No operation of the USB devices (Generic USB HUB) is not listed in (Device Manager). On the OSD screen, the upstream port to which the USB device you want to use is connected is not colored by blue. ELSA ECOMO 750...
  • Page 38: Restraining Wires

    This is not a defect, but a phenomenon common to monitors which use the aperture grille CRT technology. These lines are shadows produced by the Restraining wires restraining wires which reduce the aperture grille’s sensitivity to vibration. ELSA ECOMO 750...
  • Page 39: Appendix

    CFCs (freons) and chlorinated solvents, among other things. The product must be prepared for recycling and the manufacturer is obliged to have an environmental policy which must be adhered to in each country where the company implements its operational policy. ELSA ECOMO 750...
  • Page 40 Mercury* * Mercury is sometimes found in batteries, relays and switches. It damages the nervous system and is toxic in high doses. The relevant TCO ’99 requirement states ELSA ECOMO 750...
  • Page 41 TCO ’99 requirement permits the inclusion of lead since no replacement has yet been developed. * Bio-accumulative is defined as substances which accumulate within living organisms ** Lead, cadmium and mercury are heavy metals which are bio-accumulative. ELSA ECOMO 750...
  • Page 42: Advice And Help

    Internet site www.elsa.com and direct via FTP from ftp.elsa.com. You will also find a wealth of information and answers to frequently asked questions (FAQs). Before you con- tact the ELSA Support team, please make sure that you are using the latest ELSA soft- ware (driver, firmware or INF file) versions.
  • Page 43 Appendix ELSA world wide You can contact the ELSA subsidiaries: ELSA, Inc. 1630 Zanker Road Phone: +1-408-961-4600 San Jose, CA 95112 +1-800-272-ELSA Fax: +1-408-895-4700 ELSA Asia, Inc. 7F-11, No. 188, Sec. 5 Phone: +886-2-2768 57 30 Nanking East Road Fax:...
  • Page 44: Elsa-Servicedirect For Elsa Ecomo Monitors

    Federal Republic of Germany (refer to our Internet site: www.elsa.com). If the ELSA service cannot find fault with the unit claimed to be defective, we will invoice you for DM 200 plus V.A.T. to cover inspection costs and replacement of the unit.
  • Page 45: Warranty Conditions

    Appendix Warranty conditions The ELSA AG warranty, valid as of June 01, 1998, is given to purchasers of ELSA products in addition to the warranty conditions provided by law and in accordance with the following conditions: Warranty coverage The warranty covers the equipment delivered and all its parts. Parts will, at our sole discretion, be replaced or repaired free of charge if, despite proven proper handling and adherence to the operat- ing instructions, these parts became defective due to fabrication and/or material defects.
  • Page 46 ELSA monitor, damage to the cathode ray tube (CRT) has been caused especially by mechanical load (e.g. from shock to the pitch mask assembly or damage to the glass tube), by...
