Spearhead Compact Flail Mowers
Compact Flail Mowers
R130 & R150
Handbook & Parts
Please ensure that this manual is handed to the operator before using the
machine for the first time. The operator must fully understand the contents
(If the machine is resold the Manual must be given to the new owner.)
The information contained in this manual is correct at the time of
publication. However, in the course of constant development, changes in
specification are inevitable. Should you find the information given in this
book different to the machine it relates to please contact the "After Sales
Spearhead
Manual
Part No: 8999046 – REV A
of this manual before using this machine.
Important Note
Department" for advice.
Spearhead Machinery
Green View
Salford Priors
Worcestershire
WR11 8SW
Tel: 01789 491860
Fax: 01789 778683
www.spearheadmachinery.com
enquiries@spearheadmachinery.com
1
R130 & R150
Evesham
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spearhead R130
Summary of Contents for Spearhead R130
- Page 1 R130 & R150 Spearhead Compact Flail Mowers Spearhead Compact Flail Mowers R130 & R150 Handbook & Parts Manual Part No: 8999046 – REV A Please ensure that this manual is handed to the operator before using the machine for the first time. The operator must fully understand the contents of this manual before using this machine.
-
Page 2: Ec Declaration Of Conformity
Spearhead Compact Flail Mowers EC Declaration of Conformity, Conforming to EEC Directive 89/392/EEC, 98/37/EC & 98/38/EC We, Spearhead Machinery Ltd, Green View, Salford Priors, Evesham, Worcestershire, WR11 8SW declare under our sole responsibility that the : Product …………………………………………………………… Product Code ……………………………………………………………... -
Page 3: Table Of Contents
R130 & R150 Spearhead Compact Flail Mowers Contents Operator Section General Information Machine Description & Purpose of Use Machine Identification Technical Data Technical Specifications Safety Features Safety Information Safety Decals Vehicle/Tractor Preparation Machine Attachment PTO Shaft Setting Up and Adjustment... -
Page 4: General Information
Spearhead Compact Flail Mowers General Information Always read this manual before fitting or operating the machine – whenever any doubt exists contact your dealer or the Spearhead Service Department for advice and assistance. Use only Spearhead Genuine Service Parts on Spearhead Equipment &... -
Page 5: Machine Description & Purpose Of Use
Spearhead Compact Flail Mowers Machine Description & Purpose of Use The Compact R130 & R150 series of machines are ‘3-point linkage’ tractor mounted flail mowers designed primarily for the mulching of grasses, brambles, small bushes, branches, vines, and general crop residues. Their tough construction and working widths of 1.3 and 1.5m make them ideal for... -
Page 6: Technical Data
R130 & R150 Spearhead Compact Flail Mowers Technical Data Component Identification 1. Frame 2. Gearbox 3. Belt Drive 4. 3-Point Linkage 5. Rear Roller 6. Skid Technical Specifications SPECIFICATION COMPACT COMPACT R130 R150 Working Width (mm) 1290mm 1450mm Tractor Power Requirement (kW / HP) -
Page 7: Safety Features
R130 & R150 Spearhead Compact Flail Mowers Noise Level The sound level of this machine, as measured at the operator’s ear, is within the range of 70 to 90 dB when the rear window of the tractor is open. We recommend that ear protectors are worn and the tractor windows kept closed at all times when operating this machine. -
Page 8: Safety Information
R130 & R150 Spearhead Compact Flail Mowers Safety Information General safety rules: ▲ Always read and follow the instructions for the use and maintenance of the machine before carrying out any work operations or servicing tasks. ▲ Improper use of the machine is both highly dangerous to persons and damaging to the machine components –... - Page 9 R130 & R150 Spearhead Compact Flail Mowers ▲ Before leaving the tractor with the machine attached, proceed as follows: 1. Disconnect the power takeoff. 2. Put the machine steadily on the ground using the tractor’s hydraulic lift. 3. Apply the hand brake and, if the ground is steeply sloping, wedge the tractor.
-
Page 10: Safety Decals
R130 & R150 Spearhead Compact Flail Mowers Safety Decals 1. Always switch machine off, remove starting key and read instruction manual before performing service or maintenance work on the machine. 2. Keep a safe distance from the machine at all times - risk from projection of objects. -
Page 11: Vehicle/Tractor Preparation
R130 & R150 Spearhead Compact Flail Mowers Vehicle / Tractor Preparation We recommend vehicles are fitted with cabs using ‘safety glass’ windows and protective guarding when used with our machines. Fit Operator Guard (part no. OPT0603) using the hooks provided. Shape the mesh to cover all vulnerable areas. - Page 12 R130 & R150 Spearhead Compact Flail Mowers Suggestions to increase stability: Increasing rear wheel track - a vehicle with a wider wheel track is more stable. Ballasting the wheel; it is preferable to use external weights but liquid can be added to around 75% of the tyre volume –...
-
Page 13: Machine Attachment
R130 & R150 Spearhead Compact Flail Mowers Attaching The Machine To The Tractor Attachment of the machine to the tractor should always be performed on a firm level site. Before attachment always ensure: The machine is in good condition. - Page 14 R130 & R150 Spearhead Compact Flail Mowers Top Linkage The machines top linkage point (B) has two working modes; floating and fixed – refer to photo below. Floating position (B1) should always be used when working on hilly or uneven terrain to protect the machine and linkage from damage.
-
Page 15: Pto Shaft
R130 & R150 Spearhead Compact Flail Mowers PTO Shaft PTO Shaft Measurement Measure the PTO shaft and cut to the dimension shown – the finished length of the PTO shaft should be 75mm (3”) less than the measured distance ‘A’ - between tractor shaft and gearbox stub shaft - to enable fitting. -
Page 16: Setting Up And Adjustment
R130 & R150 Spearhead Compact Flail Mowers Approximate overlap length of PTO shaft with machine lowered to the ground ▲ Approximate gap length of PTO protection tube with machine in working position ▲ Fit torque chains to shaft guards to prevent rotation ►... -
Page 17: Flails
R130 & R150 Spearhead Compact Flail Mowers Flails As standard, the machine is equipped with Hammer type flails, but as an option can be fitted with Y-blade flails. The hammer type flails are more suited to harder working with the ability to cut materials up to 45mm (1¾”) diameter. -
Page 18: Drive Belts
R130 & R150 Spearhead Compact Flail Mowers Drive Belts Belt Tension It is important for both optimal machine performance and long lasting belt life that the belts are correctly tensioned at all times. Tension is correct when a force of 10 kg exerted on the belts at their mid-point between the upper and lower pulleys deviates the belts by 15mm. -
Page 19: Pre-Operational Checks
R130 & R150 Spearhead Compact Flail Mowers Pre-Operational Checks Before commencing work with the machine the following checks should be performed: Make a visual inspection of the machine to ensure it is in good operational condition. Check all safety guarding is in position and in full working order. -
Page 20: Operation
R130 & R150 Spearhead Compact Flail Mowers Operation Ensure that the operator is suitably qualified to use a machine of this nature and that they have fully read and understood this manual - they should be aware of all safety aspects relating to the safe use of the machine. -
Page 21: Detachment And Storage
R130 & R150 Spearhead Compact Flail Mowers Detachment & Storage Detaching The Machine Removal of the machine should be performed on a firm level site. The procedure for detachment is as follows: Gently lower the machine fully to the ground. -
Page 22: Maintenance
R130 & R150 Spearhead Compact Flail Mowers Maintenance All maintenance, cleaning and repair operations must be performed with the machine firmly lowered to the ground and detached from the tractor or with the PTO disconnected, engine switched off and starting key removed. For any repairs or maintenance that requires access from underneath, the machine should be firmly and safely raised and propped using suitable purpose designed supports capable of bearing the machines full weight. -
Page 23: Gearbox Lubrication
R130 & R150 Spearhead Compact Flail Mowers Gearbox Lubrication The photo opposite shows the lubrication access point for the gearbox – this access point is used for both filling and lubricant level checking. Lubricant level should be checked on a daily basis during work and topped up only if required. -
Page 24: Troubleshooting
R130 & R150 Spearhead Compact Flail Mowers Troubleshooting PROBLEM POSSIBLE CAUSES REMEDIES Irregular Cut Worn, bent or broken flails Replace flails RPM too low Increase RPM Machine not level to the Correct mounting on ground tractor Clogged material caused by... -
Page 25: Warranty
Should you have a problem within 12 months from the date of sale please contact your original Spearhead dealer, or Spearhead’s Service Department. Any part found to be defective during this period will be replaced or repaired, at Spearhead’s discretion, by the dealer or a Spearhead Service Engineer. - Page 26 The Spearhead warranty may be transferred to a subsequent owner of the machinery (for use within the UK) for the balance of the warranty period subject to all of the warranty conditions and provided that the Change of Owner form is completed and sent to Spearhead within 14 days of change of ownership.
-
Page 27: Parts Manual
R130 & R150 Spearhead Compact Flail Mowers Spearhead Compact Fail Mowers R130 & R150 Parts Manual... -
Page 28: Mower Assembly
R130 & R150 Spearhead Compact Flail Mowers Mower Assembly... - Page 29 R130 & R150 Spearhead Compact Flail Mowers DESCRIPTION PART No. QUANTITY FRAME - 130 1061585 FRAME - 150 1061586 LINKAGE 1061001 ROTOR - 130 (HAMMER FLAILS) 1061587 ROTOR - 130 (Y-BLADE FLAILS) 1061588 ROTOR - 150 (HAMMER FLAILS) 1061589 ROTOR - 150 (Y-BLADE FLAILS)
- Page 30 R130 & R150 Spearhead Compact Flail Mowers Mower Assembly...
- Page 31 R130 & R150 Spearhead Compact Flail Mowers DESCRIPTION PART No. QUANTITY 1061097 BEARING & CASING 1061610 BEARING & CASING 1061611 BEARING 1061040 BOLT 9313034 BOLT 9213045 BOLT 9213055 BOLT 9213065 BOLT 9213075 BOLT 9213125 BOLT 9313076 BOLT 1061132 9143004 WASHER...
